Invacare® LiNX
WARNING!
Risk of Injury or Damage due to Electrical Shorts
Continuous contact between user and cable can result in
frayed cable jacket. This increases risk of electric shorts.
— Avoid routing the cable where it will come into
continuous contact with the end user.
When installing the bus cable, avoid undue straining of the cable and
connection points. Flexing of the cable should be minimised wherever
possible, to extend service life and minimize the risk of accidental
damage.
NOTICE!
Regular bending can damage bus cable
— Use of a cable chain to support the bus cable, where the
cable is subject to regular cyclic bending, is
recommended. The maximum stretch of the chain
should be less than the length of the bus cable. The
force applied to flex the cable should never exceed 10 N.
Appropriate life testing should be carried out to determine /
confirm the expected service life and inspection and
maintenance schedule.
2.3 Connecting the Remote
CAUTION!
Risk of Unintended Stops
If the plug of the remote cable is broken, the remote cable
may come loose while driving. The remote could suddenly
8
power down when losing power. This forces an unintended
stop.
— Always check the plug of the remote for damage.
Contact your provider immediately in case of a damaged
plug.
NOTICE!
The remote plug and connector socket fit together in one
way only.
— Do not force them together.
1. Lightly push to connect the plug of the remote cable and the
connector socket. The plug must lock in place with an audible
click.
2.4 Adjusting Manual Chin Control
WARNING!
Risk of Injury or Death
Small parts can lead to choking hazard that may r esult in
injury or death.
— Do not remove any small parts.
— Closely supervise children, pets or people with p hysical /
mental disabilities.
