Invacare® LiNX
Moving Controls Inwards / Outwards
A
3.2 Using Powered Swing-Away Chin Control
Driving
This proportional joystick needs less force to be deflected than a
standard joystick.
A
B
1. Deflect joystick A from neutral position in
desired direction.
For more information about driving, refer to user manual of
the main remote.
14
1. Press locking device A
(behind headrest) and swivel
joystick or egg switch inwards
or outwards until it clicks in
place.
By default, two Piko buttons are mounted to the chin beam.
A B
Powering Remote Up / Down
1. Press red Piko button A to
power remote up or down.
For operating the powered seating functions and for the
difference between function card and profile, refer to user
manual of the main remote.
Changing Function Cards
1. Short press black Piko
button B to change function
card.
2. Long press black Piko button
B to change profile.
1662641-C
