Invacare LiNX Chin Control User Manual page 13

3 Usage
WARNING!
Risk of Injury or Death
Small parts can lead to choking hazard that may r esult in
injury or death.
— Do not remove any small parts.
— Closely supervise children, pets or people with p hysical /
mental disabilities.
CAUTION!
Risk of Injury or Damage
Clothes or personal accessories can restrict or prohibit
correct function of Chin Control.
— Check correct wiring of cables before first use.
— Ensure that no clothes or accessories are in range of u se
at any time.
NOTICE!
Additional items not belonging to Chin Control can damage
it.
— Do not hang items, such as clothes or accessories, on a ny
parts of Chin Control.
1662641-C
3.1 Using Manual Swing-Away Chin Control
Driving
This proportional joystick needs less force to be deflected than a
standard joystick.
A
1. Deflect joystick A from neutral position in
B
desired direction.
You can use wing bolt B to adjust the
joystick to your needs.
For more information about driving, refer to user manual of
the main remote.
Changing Function Cards
By default an egg switch, used for function or profile changes, is
mounted to the headrest.
For operating the powered seating functions and for the
difference between function card and profile, refer to user
manual of the main remote.
1. Short press egg switch to change function card.
2. Long press egg switch to change profile.
3 Usage
13
