Invacare LiNX Chin Control User Manual page 15

Moving Chin Control Inwards and Outwards Electrically
The linkage joystick controls the movement of the Chin Control.
See table for possible movements:
A
B
Joystick Position Movement
up (A) Chin Control moves upwards and outwards
down (B) Chin Control moves downwards and inwards
1. Move linkage joystick in desired direction until Chin Control is in
desired position.
1662641-C
3 Usage
15
