Daikin EWYA006D2V3P Installer's Reference Manual page 85

EWAA004~008D + EWYA004~008D
Packaged air-cooled water chillers
and packaged air to water heat pumps
4P688013-1C – 2023.05
Capacity – Power
supply
6 kW 3N~ 400 V
9 kW 3N~ 400 V
3 Fix the cable with cable ties to the cable tie mountings.
During connection of the backup heater, miswiring is possible. To detect possible
miswiring, it is highly recommended to measure the resistance value of the heater
elements. Depending on the capacity and power supply, following resistance
values (see table below) should be measured. ALWAYS measure the resistance on
the contactor clamps K1M, K2M, and K5M.
K1M/1 K5M/13
K1M/3
K1M/5
K1M/3 K1M/5
K2M/1 K5M/13
K2M/3
K2M/5
K2M/3 K2M/5
K1M/5 K2M/1
Example measure resistance between K1M/1 and K5M/13:
Ω
Ω
F1B
F1B
L1 L2 L3 N
Q3DI
L1 L2 L3 N
3N~ , 50 Hz
400 V AC
3 kW 6 kW
1N~ 230 V 1N~ 230 V
52.9Ω 52.9Ω
∞ 105.8Ω
∞ 158.7Ω
26.5Ω 52.9Ω
∞ 26.5Ω
∞ ∞
∞ ∞
52.9Ω 52.9Ω
∞ 132.3Ω
K1M K2M K2M
1 3 5 13 1 3 5 13
2 4 6 14 2 4 6 14
K5M
1 3 5 13
2 4 6 14
9 Electrical installation
|
X14M
X14M
1 2 3 4 5 6
6 kW 9 kW
3N~ 400 V 3N~ 400 V
∞ ∞
105.8Ω 105.8Ω
105.8Ω 105.8Ω
105.8Ω 105.8Ω
∞ ∞
52.9Ω 52.9Ω
52.9Ω 52.9Ω
52.9Ω 52.9Ω
∞ ∞
Installer reference guide
85
