10 | Configuration
10.1.2 To connect the PC cable to the switch box
Installer reference guide
106
5 Turn the right dial to modify the value from 15 to 20.
00 05
01 20
06
1
02 07
03 08
04 09
6 Press the left dial to confirm the new setting.
7 Press the center button to go back to the home screen.
INFORMATION
When you change the overview settings and you go back to the home screen, the
user interface will show a popup screen and request to restart the system.
When confirmed, the system will restart and recent changes will be applied.
Prerequisite: The EKPCCAB4 kit is required.
1 Connect the USB connector of the cable to your PC.
2 Connect the plug of the cable to X10A on A1P (hydro PCB).
X10A
A1P
3 Pay special attention to the position of the plug!
2
3
4
5
0A
0B
0C
0D
0E
EWAA004~008D + EWYA004~008D
Packaged air-cooled water chillers
and packaged air to water heat pumps
4P688013-1C – 2023.05
