Daikin EWYA006D2V3P Installer's Reference Manual page 19

EWAA004~008D + EWYA004~008D
Packaged air-cooled water chillers
and packaged air to water heat pumps
4P688013-1C – 2023.05
a General safety precautions
b Operation manual
c Installation manual
d Addendum book for optional equipment
e Energy label
f User interface (front plate, rear plate, screws, and wall plugs)
g Unit mounting plate
h Vibration dampers
i Cable tie
j Bolts, nuts, washers, and spring washers
2 After opening the unit (see
the accessory inside the unit.
a Shutoff valve
a b c d e
1× 1× 1× 1×
f
1×
g h i
2× 4× 3×
j
4× 8× 4× 8×
"7.3.2 To open the outdoor
a
4 About the box
|
1×
unit" [ 4 56]), remove
Installer reference guide
