Daikin EWYA006D2V3P Installer's Reference Manual page 215

EWAA004~008D + EWYA004~008D
Packaged air-cooled water chillers
and packaged air to water heat pumps
4P688013-1C – 2023.05
English
M1F
MR*
N
PCB1
PS
Q1L
Q1DI
Q*
R1T
R2T
R3T
RTH2
S
S1PH
S2~80
SA1
SHM
U, V, W
V3, V4, V401
X*A
X*M
Y1E
Y1S
Z*C
Z*F
NOTES:
1 When operating, do not short-circuit protection device(s) S1PH and Q1L.
2 Colours: BLK: black; RED: red; BLU: blue; WHT: white; GRN: green; YLW:
yellow
16
Translation
Fan motor
Magnetic relay
Connector
Printed circuit board (main)
Switching power supply
Thermal protector
# Earth leakage circuit breaker
Insulated gate bipolar transistor (IGBT)
Thermistor (air)
Thermistor (heat exchanger)
Thermistor (discharge)
Resistor
Connector
High pressure switch
Connector
Surge arrestor
Terminal strip fixed plate
Connector
Varistor
Connector
Terminal strip
Electronic expansion valve
Solenoid valve (4-way valve)
Noise filter (ferrite core)
Noise filter
Technical data
|
Installer reference guide
215
