SECTION 10: MAINTENANCE
table 46 - Serial Communication Analog Input Data (cont'd)
AI BACNET NAME
11 S1_DEF_TEMP
12 S1_EEV_OUT
13 S1_AR_TIMER
14 AC_TIMER
15 S2_SUCT_TEMP
16 S2_RUN_TIME
17 S2_SUCT_PR
18 S2_DSCH_PR
19 S2_CIR_TEMP
20 S2_DEF_TEMP
21 S2_SUCT_SH
22 S2_AR_TIMER
23 S2_EEV_OUT
24 NUM_COMPS
25 S1_OP_CODE
26 S1_FLT_CODE
27 S2_OP_CODE
28 S2_FLT_CODE
29 S1_DBG_CODE
30 S1_FAN_STAGE
31 S2_DBG_CODE
32 S2_FAN_STAGE
33 CONTROL_M0DE
34 AR_TIME
35 LCHLT_CUT
36 LOW_AMB_CUT
37 SUCT_P_CO_HT
38 L_SUCT_P_CO
39 H_DSCH_P_CO
40 COOL_SETP
41 SP_SETP_S1
42 CONTROL_RG
43 SP_CTL_RG_S1
44 SP_SETP_S2
45 HEAT_SETP
46 SP_CTL_RG_S2
47 HEAT_RANGE
48 S1_DSCH_TEMP
49 S1_DSCH_SH
50 S2_DSCH_TEMP
51 S2_DSCH_SH
172
ANALOG INPUT DESCRIPTION
SYS 1 Defrost Temperature (HP Only)
SYS 1 EEV Output % (EEV Only)
SYS 1 Anti-Recycle Timer
Anti-Coincident Timer
SYS 2 Suction Temperature (EEV and cond unit only)
SYS 2 Run Time (Seconds)
SYS 2 Suction Pressure
SYS 2 Discharge Pressure
SYS 2 Cooler Inlet Refrigerant Temperature (R407C Only)
SYS 2 Defrost Temperature (HP ONLY)
SYS 2 SUCTION SUPERHEAT (EEV Only)
SYS 2 Anti-Recycle Timer
SYS 2 EEV Output % (EEV Only)
Number Of Compressors
SYS 1 Operational Code
SYS 1 Fault Code
SYS 2 Operational Code
SYS 2 Fault Code
SYS 1 Debug Code
SYS 1 Condenser Fan Stage
SYS 2 Debug Code
SYS 2 Condenser Fan Stage
Unit Control Mode (1=Leaving Water, 2=Return Water. 3=Discharge Air,
4=Suction Press, 5=Cooling, 6=Heating)
Anti-Recycle Time (Programmed)
Leaving Chilled Liquid Temp Cutout
Low Ambient Temperature Cutout
Low Suction Pressure Cutout Heating (HP Only)
Low Suction Pressure Cutout (Cooling On HP Units)
High Discharge Pressure Cutout
Setpoint
Setpoint 1 (SP Control)
Cooling Range
Cooling Range 1 (SP Control)
Setpoint 2 (SP Control)
Heating Setpoint (HP Only)
Cooling Range 2 (SP Control)
Heating Range (HP Only)
SYS 1 Discharge Temperature (EEV Only)
SYS 1 Discharge Superheat (EEV Only)
SYS 2 Discharge Temperature (EEV Only)
SYS 2 Discharge Superheat (EEV Only)
