Misuse of equipment
Suitability for application
The unit is intended for DX cooling applications and is
not suitable for purposes other than those specified in
these instructions. Any use of the equipment other than
its intended use, or operation of the equipment contrary
to the relevant procedures may result in injury to the
operator, or damage to the equipment.
The unit must not be operated outside the design pa-
rameters specified in this manual.
Structural support
Structural support of the unit must be provided as in-
dicated in these instructions. Failure to provide proper
support may result in injury to the operator, or damage
to the equipment and/or building.
Mechanical strength
The unit is not designed to withstand loads or stresses
from adjacent equipment, pipework or structures. Ad-
ditional components must not be mounted on the unit.
Any such extraneous loads may cause structural failure
and may result in injury to the operator, or damage to
the equipment.
General access
There are a number of areas and features, which may
be a hazard and potentially cause injury when working
on the unit unless suitable safety precautions are taken.
It is important to ensure that the chiller is installed in a
secure area and access to the unit is restricted to suit-
ably qualified persons who are familiar with the po-
tential hazards and precautions necessary for safe op-
eration and maintenance of equipment containing high
temperatures, pressures and voltages. To further tighten
security, ensure that the control panel is mechanically
locked. Remove the keys to the control panel and store
them in a secure location
Pressure systems
The unit contains refrigerant vapor and liquid under
pressure, release of which can be a danger and cause
injury. The user should ensure that care is taken during
installation, operation and maintenance to avoid dam-
age to the pressure system. No attempt should be made
to gain access to the component parts of the pressure
system other than by suitably trained and qualified per-
sonnel.
JOHNSON CONTROLS
SECTION 1: GENERAL EQUIPMENT INFORMATION AND SAFETY
Electrical
The unit must be grounded. No installation or main-
tenance work should be attempted on the electrical
equipment without first switching power OFF, isolat-
ing and locking-off the power supply. Servicing and
maintenance on live equipment must only be per-
formed by suitably trained and qualified personnel. No
attempt should be made to gain access to the control
panel or electrical enclosures during normal operation
of the unit.
Rotating parts
Fan guards must be fitted at all times and not removed
unless the power supply has been isolated. If ductwork
is to be fitted, requiring the wire fan guards to be re-
moved, alternative safety measures must be taken to
protect against the risk of injury from rotating fans.
Sharp edges
The fins on the air-cooled condenser coils have sharp
metal edges. Take care when working in contact with
the coils to avoid the risk of minor abrasions and lac-
erations. The use of gloves is recommended.
Frame rails, brakes, and other components may also
have sharp edges. Reasonable care should be taken
when working in contact with any components to avoid
risk of minor abrasions and lacerations.
Refrigerants and oils
Refrigerants and oils used in the unit are generally non-
toxic, non-flammable and non-corrosive, and pose no
special safety hazards. Use of gloves and safety glasses
is, however, recommended when working on the unit.
The build up of refrigerant vapor, from a leak for ex-
ample, does pose a risk of asphyxiation in confined or
enclosed spaces and attention should be given to good
ventilation.
Refrigerants classified as A2L refrigerant must be han-
dled in accordance with all governing regulations. Fail-
ure to meet this requirement can result in damage to
equipment, release of refrigerant into the environment,
contamination of the operating space for the equip-
ment, and pose a risk of personal injury or death. It is
the responsibility of any service technician or operator
to adhere to these requirements. For details, refer to ac-
cess Chiller A2L Refrigerant Application Data, Form
160.00-AD10.
