HARVEY ALPHA HW110S Instruction Manual

Dovetail cabinet table saw
Hide thumbs

Advertisement

Quick Links

Download this manual
Revision E 2023-09-14
INSTRUCTION MANUAL
Original Instructions
Dovetail Cabinet Table Saw
MODEL : HW110S
298001410

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALPHA HW110S and is the answer not in the manual?

Questions and answers

Related Manuals for HARVEY ALPHA HW110S

Summary of Contents for HARVEY ALPHA HW110S

  • Page 1 Revision E 2023-09-14 INSTRUCTION MANUAL Original Instructions Dovetail Cabinet Table Saw MODEL : HW110S 298001410...
  • Page 2 Contents 1. Foreword............................... 1 2. Warranty Information.........................1 3. Machine Description.......................... 2 3.1 Technical Parameters......................... 2 3.2 Feature Identification........................5 3.3 Optional Equipment........................5 3.4 Intended Use..........................6 3.5 Electrical Power Requirements....................6 4. Safety Regulations..........................7 4.1. General Safety Instructions.......................7 4.2. Table Saw Safety Instructions....................7 4.3.
  • Page 3 1. Foreword 2. Warranty Information This manual contains basic information Limited Warranty qualified operators and describes the normal Two year. usage this machine typical shop Proof of Purchase environment. Please keep your dated proof of purchase for This machine is equipped with various safety warranty and servicing purposes.
  • Page 4 3. Machine Description 3.1 Technical Parameters For North American Market： ITEM HW110S-36(P) HW110S-52(P) Weight 582 lbs (Approx.) 623 lbs (Approx.) Product 69” x 44” x 48” 85” x 44” x 48” Length/Width/Height Dimensions (1752x1120x1220mm) 2160x1120x1220mm Footprint 21” x 23-5/8”（533 x 600 mm） Switch type Magnetic with Thermal Overload Protection Switch...
  • Page 5 For European Market： ITEM HW110S-36 HW110S-52 Weight 264 kg (Approx.) 283 kg (Approx.) Product Dimensions Length/Width/Height (mm) 1752x1120x1220mm 2160x1220x1220mm Footprint 533 x 560 mm Switch type Magnetic with Thermal Overload Protection Switch Standard Type TEFC, Capacitor Start, Induction 4kW, 380 V, 3PH, 8.3 A Horsepower, Voltage, Phase, Amps 2.2kW, 230 V, 1PH, 12 A Motor...
  • Page 6 For Asian Market： ITEM HW110S-36 HW110S-52 Weight 264 kg (Approx.) 283 kg (Approx.) Product 69” x 44” x 48” 85” x 44” x 48” Length/Width/Height Dimensions (1752x1120x1220mm) 2160x1120x1220mm Footprint 21” x 22”（533 x 560 mm） Switch type Magnetic with Thermal Overload Protection Switch Standard Type...
  • Page 7 3.2 Feature Identification 3.3 Optional Equipment Fig. 1. Refer to Sliding table Model: ST-1400S Fig. 1-1 Universal Overhead Guard Fig. 1 Model: S-12S Left Extension Wing Blade Guard Main Table Fig. 1-2 Right Extension Wing Fence Assembly Extension Table Rail Assembly Support Leg Motor Cover Cabinet...
  • Page 8 3.4 Intended Use This table saw and the workpiece guide equipment supplied with it are intended to be used exclusively The machine is prohibited from being used in a potentially explosive atmosphere! for the following purposes: Laminated and unlaminated board materials (e.g. ●...
  • Page 9 4. Safety Regulations 14. DISCONNECT MACHINES. Before servicing, when changing accessories or attachments; 4.1 General Safety Instructions 15. AVOID ACCIDENTAL STARTING. 1. KNOW YOUR MACHINE. Make sure the switch is in the “OFF” position Read and understand the owner’s manual and before plugging in;...
  • Page 10 4.3 Residual Risks 5. STAND TO THE SIDE WHEN FEEDING MATERIAL. Take precautions to reduce the hazard of Never stand or have any part of your body in line inhalation of harmful dust (e.g. wearing a dust with the path of the saw blade; mask);...
  • Page 11 5. Installation of the Machine 5.2 Unpacking Your machine was carefully packaged for safe 5.1 Transportation of Machines transportation. Remove the packaging materials from around your machine and inspect it. If you 5.1.1 Transportation and store discover that the machine is damaged, please This machine has been well packaged and rust immediately call Customer Service for advice.
  • Page 12 5.3 Contents The product is packed by four individual boxes as follows: Main machine box contents: (Fig. 5-1-----Fig. 5-5) A. Main table saw unit……..………………1 B. Motor cover……….……..……..………1 C. Left extension wing……..………………1 D. Right extension wing…...……..………1 Fig. 5-2 E. Extension table (width 365 mm)………1 (Only for HW110S-52) Extension table (width 505 mm)………1 G.
  • Page 13 Fence box contents: (Fig. 5-6) Over arm box contents: (Fig. 5-8) A. Fence body…..…..…………..……..……1 A. Over arm..…………..……………..……1 B. Fe n c e … ..… … … … … … … … . . … . . 1 B.
  • Page 14 5.4 Installation 5.4.2 Hand-wheel handle installation Before beginning assembly, take note of the Install the handle into the Blade Tilt hand-wheel as shown in Fig. 7. following precautions and suggestions: FLOOR: This tool distributes a large amount of weight over a small area. Make certain that the floor is capable of supporting both the weight of the machine and the operator.
  • Page 15 fence and the blade, at the rear of the blade, to 5.4.4 Install the rail & extension table reduce the risk of workpiece binding or burning as 1. Install the rail and extension table as breakdown it is fed through the cut. shows.
  • Page 16 5.4.5. Post the tape scale use the pointer 5.4.6 Install the switch （ Fig.14 ） The switch is mounted on the lower right side of the window (Fig.13) guide tube by using two sets of bolts which are pre-installed on the guide tube. The machine features a Hi-Low fence with two pointer windows.
  • Page 17 5.4.9 Extraction system 5.4.8 Install the blade guard 1. Slide the knurled knob out (refer to Fig. 16) and A dust collection device should be used by the rotate it forward so it engages the upper bracket. customer，the dust extraction equipment must be switched on before commencing machining.
  • Page 18 5.4.10 Motor cover installation 5.4.12 Electrical installation Install the motor cover by inserting the door pins into the hinge sockets on the cabinet as shown in Wiring should only be done by professional Fig. 20. electricians. Always make sure the machine is properly grounded.
  • Page 19 ELECTRICAL DIAGRAM 4HP/230V/60Hz/1PH Remark: 1. The colour of single core may differ with the illustration above in different areas. 2. Single-phase power supply range: 200-240 V. 3. Meeting the standard of UL62841, this electrical diagram is designed for North-American areas. 3HP/230V/50Hz/1PH Remark: 1.
  • Page 20 4kW/380V/50(60)Hz/3PH Remark: 1. The colour of single core may differ with the illustration above in different areas. 2. Three-phase power supply range: 380-415 V. 3. Meeting the CE standard, this electrical diagram is designed for European and Asian areas. 4.There is no plug involved for three-phase electric equipment. Customers need to configure the plug that m eets local standard or directly connect the equipment to the electrical box.
  • Page 21 6. Adjustment Before operation, Please make adjustments as followings: 6.1 Adjusting the Rip Fence Before using the rip fence, the parallelism and perpendicularity must be aligned correctly. Please refer to chapter 5.4.4 Install the rail & fence. Fig. 22 6.2 Aligning the Table T-slot Parallel with 6.3 Adjusting the 45°...
  • Page 22 6.4 Aligning the Riving Knife with Blade 0.2mm greater than the saw blade plate. As shown in Fig. 26. The riving knife must be aligned with the blade. If not properly aligned, the riving knife will force the workpiece sideways during the cut, increasing the risk of kickback.
  • Page 23 7.3 Crosscutting 7. Operations "Crosscutting" means cutting across the grain of 7.1 Electrical Operation a natural wood workpiece. In other man-made materials, such as MDF or plywood, crosscutting The actual object shall prevail. Refer to Fig.28 means cutting across the width of the workpiece. “ON”...
  • Page 24 7.4 Ripping 8. Maintenance "Ripping" means cutting with the grain of a natural This table saw has TEFC motor and sealed wood workpiece. In other man-made materials lubricated bearings, which requires very little such as MDF or plywood, ripping simply means maintenance other than minor lubrication and cutting lengthwise.
  • Page 25 9. Trouble Shooting PROBLEM SOLUTION SAW WILL NOT START 1. Saw not plugged in. 1. Plug in saw. 2. Fuse blown or circuit breaker tripped. 2. Replace fuse or reset circuit breaker. 3. Cord damaged. 3. Have cord replaced by a certified electrician. OVERLOAD KICKS OUT FREQUENTLY 1.
  • Page 26 10. Exploded View and Parts List Table Saw Body Exploded View...
  • Page 27 Body Assembly Parts List DESCRIPTION DESCRIPTION Cabinet Set screw M5-0.8x12 Rivet nut M5-0.8x12 Key 5x40 Hook Hex bolt M8-1.25x40 Rivet nut M6-1x13.5 Nut M8-1.25 Side cover Cap screw M6-1x16 Flat washer 5 Motor cover Lock washer 5 Barrier chip Pan HD screw M5-0.8x12 Main table Dust cover Limit plate...
  • Page 28 Trunnion Assembly Exploded View...
  • Page 29 Trunnion Assembly Parts List REF DESCRIPTION DESCRIPTION DESCRIPTION 201 Cap screw M6-1x20 202 Lock washer 6 Bracket for riving knife Worm 203 Flat washer 6 Flat washer 8 Copper backing 204 Point bracket Cap screw M8x16 205 Cap screw M8-1.25x25 Knurled knob Hex bolt M6-1x25 206 Lock washer 8...
  • Page 30 Blade Guard Exploded View GLIDER Saw Blade Guard (UL62841) DESCRIPTION DESCRIPTION Pan HD screw M4-0.7x12 Nickel Pan HD screw M4-0.7x28 Nickel Plastic spacer Spreader Left guard Right guide block Guard support Left guide block Left cover Roller Plastic liner Bearing 689ZZ Front guard Right cover Cap screw M3-0.5x8 Nickel...
  • Page 31 Fence Exploded View DESCRIPTION DESCRIPTION Glide pad Lock knob for Low Fence Special locking nut M12-1.75 Lock knob for High Fence Set screw M12-1.75x16 Window fixing block Set screw M12-1.75x10 Window Hex bolt M6-1x40 Window bracket Cam foot Fence end cap Lock nut M6-1 Set screw M12-1.75x30 Hex bolt M10-1.5x45...
  • Page 32 36″Rail & Extension Table Exploded View DESCRIPTION DESCRIPTION Tube cover 612-1 Rear rail (36") 602-1 Tube (36") Cap screw M8-1.25x35 603-1 Front rail (36") Cap screw M6-1x16 604-1 Scale(36”) Flat washer 6 Pan HD screw M8-1.25x35 Lock washer 6 Support leg Cap screw M6-1x16 Foot Hex bolt M8-1.25x35...
  • Page 33 52″Rail & Extension Table Exploded View DESCRIPTION DESCRIPTION Tube cover 612-2 Rear rail (52") 602-2 Tube (52") Cap screw M8-1.25x35 603-2 Front rail (52") Cap screw M6-1x16 604-2 Scale Flat washer 6 Pan HD screw M8-1.25x35 Lock washer 6 Support leg Cap screw M6-1x16 Foot Hex bolt M8-1.25x35...
  • Page 34 Switch Exploded View DESCRIPTION DESCRIPTION Switch Lock washer 5 Switch bracket Flat washer 5 Chain Cable for power supply Safety pin Cable for motor Pan HD screw M5-0.8x16...
  • Page 35 Over Arm Exploded View DESCRIPTION DESCRIPTION Flexible hose (1-1/2” 0.6m) Lock washer 6 Hose Connector 1-1/2" Bracket Over arm Flexible hose (1-1/2” 1m) Cap screw M6-1x16 Clamp Flat washer 6 Cap screw M6-1x12...
  • Page 36 11. Certificates...
  • Page 40 Harvey Industries Co., Ltd 68-10 Suyuan Avenue, Jiangning District, Nanjing 211100, China www. harveywoodworking. com Harvey Industries International Inc. 10832 Ada Ave. Montclair, CA 91763, United States TEL: 1-888-211-0397 E- mail: info@ harveywoodworking. com 南京海威机械有限公司 中国南京江宁经济开发区苏源大道68-10 www.harvey.cn...
