Revision B 2024-05-28

INSTRUCTION MANUAL

Original Instructions

Dovetail Cabinet Table Saw

MODEL : HW110S-36Pro

HW110S-52Pro

10" 4HP Industrial

298007501

Need help?

Do you have a question about the ALPHA HW110S-36Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for HARVEY ALPHA HW110S-36Pro

Page 1 Revision B 2024-05-28 INSTRUCTION MANUAL Original Instructions 10" 4HP Industrial Dovetail Cabinet Table Saw MODEL : HW110S-36Pro HW110S-52Pro 298007501...
Page 2 Contents 1. Foreword............................... 1 2. Warranty Information.........................1 3. Machine Description.......................... 2 3.1 Technical Parameters......................... 2 3.2 Feature Identification........................3 3.3 Optional Equipment........................3 3.4 Intended Use..........................4 3.5 Electrical Power Requirements....................4 4. Safety Regulations..........................5 4.1. General Safety Instructions.......................5 4.2. Table Saw Safety Instructions....................5 4.3.
Page 3 1. Foreword 2. Warranty Information This manual contains basic information Limited Warranty qualified operators and describes the normal Two years. usage this machine typical shop Proof of Purchase environment. Please keep your dated proof of purchase for This machine is equipped with various safety warranty and servicing purposes.
Page 4 3. Machine Description 3.1 Technical Parameters ITEM HW110S-36Pro HW110S-52Pro Weight 578 lbs (Approx.) 610 lbs (Approx.) Product 69” x 41” x 48” 85” x 41” x 48” Length/Width/Height Dimensions (1760x1050x1220mm) 2165x1050x1220mm Footprint 21” x 23-5/8”（533 x 600 mm） Switch type Magnetic with Thermal Overload Protection Switch Standard...
Page 5 3.2 Feature Identification 3.3 Optional Equipment Refer to Fig.1. Sliding table Model: ST-1500 Fig.1-1 Universal Overhead Guard Fig.1 Model: S-12S Left Extension Wing Blade Guard Main Table Fig.1-2 Right Extension Wing Fence Assembly Extension Table Rail Assembly Support Leg Motor Cover Cabinet Universal Mobile Base Blade Elevation Hand Wheel...
Page 6 3.4 Intended Use This table saw and the workpiece guide equipment supplied with it are intended to be used exclusively The machine is prohibited from being used in a potentially explosive atmosphere! for the following purposes: Laminated and unlaminated board materials (e.g. ●...
Page 7 4. Safety Regulations 14. DISCONNECT MACHINES. Before servicing, when changing accessories or attachments; 4.1 General Safety Instructions 15. AVOID ACCIDENTAL STARTING. 1. KNOW YOUR MACHINE. Make sure the switch is in the “OFF” position Read and understand the owner’s manual and before plugging in;...
Page 8 4.3 Residual Risks 5. STAND TO THE SIDE WHEN FEEDING MATERIAL. Take precautions to reduce the hazard of Never stand or have any part of your body in line inhalation of harmful dust (e.g. wearing a dust with the path of the saw blade; mask);...
Page 9 5. Installation of the Machine 5.2 Unpacking Your machine was carefully packaged for safe 5.1 Transportation of Machines transportation. Remove the packaging materials from around your machine and inspect it. If you 5.1.1 Transportation and store discover that the machine is damaged, please This machine has been well packaged and rust immediately call Customer Service for advice.
Page 10 5.3 Contents The product is packed by four individual boxes as follows: Main machine box contents: (Fig.5-1-----Fig.5-6) Main table saw unit……..………………1 Motor cover……….……..…...…..………1 Left extension wing……..……..…………1 Right extension wing…...…..…..………1 Fig.5-2 Extension table (width 365 mm)…..……1 (Only for HW110S-52) Extension table (width 505 mm) ……… 1 Saw blade…………..……………………1 Wrench open-ends 22-24 mm…...……1 Wrench open-end 18-27 mm…....……1...
Page 11 Note： There are two types of the guide rails, please have a check according to the name plate of the machine: 1. 36” guide rail is for HW110S-36. 2. 52” guide rail is for HW110S-52. Over arm box contents: (Fig.5-9) Fig.5-6 A.
Page 12 5.4 Installation 5.4.2 Hand-wheel handle installation Before beginning assembly, take note of the Install the handle into the Blade Tilt hand-wheel as shown in Fig.7. following precautions and suggestions: FLOOR: This tool distributes a large amount of weight over a small area. Make certain that the floor is capable of supporting both the weight of the machine and the operator.
Page 13 5.4.7 Install the blade guard 5.4.5 Install the switch （ Fig.9 ） The switch is mounted on the lower left side of the 1. Slide the knurled knob out (refer to Fig.11) and guide rail by using two sets of bolts which placed in rotate it forward so it engages the upper bracket.
Page 14 Install the motor cover by inserting the door pins 5.4.8 Extraction system into the hinge sockets on the cabinet as shown in Fig.15. A dust collection device should be used by the customer，the dust extraction equipment must be switched on before commencing machining. 1.
Page 15 ELECTRICAL DIAGRAM 4HP/230V/60Hz/1PH Remark: 1. The colour of single core may differ with the illustration above in different areas. 2. Single-phase power supply range: 200-240 V. 3. Meeting the standard of UL62841, this electrical diagram is designed for North-American areas.
Page 16 6. Adjustment Before operation, Please make adjustments as followings: 6.1 Adjusting the Rip Fence Before using the rip fence, the parallelism and perpendicularity must be aligned correctly. Please refer to the Instruction Manual of BIG EYE RIP FENCE SYSTEM for detailed operation. Fig.17 6.2 Aligning the Table T-slot Parallel with 6.3 Adjusting the 45°...
Page 17 6.4 Aligning the Riving Knife with Blade 0.2mm greater than the saw blade plate. As shown in Fig.21. The riving knife must be aligned with the blade. If not properly aligned, the riving knife will force the workpiece sideways during the cut, increasing the risk of kickback.
Page 18 materials, such as MDF or plywood, crosscutting 7. Operations means cutting across the width of the workpiece. Crosscutting requires the use of the miter gauge to 7.1 Electrical Operation position and guide the work. Place the work against the miter gauge and advance both the The actual object shall prevail.
Page 19 7.4 Ripping 8. Maintenance "Ripping" means cutting with the grain of a natural This table saw has TEFC motor and sealed wood workpiece. In other man-made materials lubricated bearings, which requires very little such as MDF or plywood, ripping simply means maintenance other than minor lubrication and cutting lengthwise.
Page 20 9. Trouble Shooting PROBLEM SOLUTION SAW WILL NOT START 1. Saw not plugged in. 1. Plug in saw. 2. Fuse blown or circuit breaker tripped. 2. Replace fuse or reset circuit breaker. 3. Cord damaged. 3. Have cord replaced by a certified electrician. OVERLOAD KICKS OUT FREQUENTLY 1.
Page 21 10. Exploded View and Parts List Table Saw Body Exploded View...
Page 22 Body Assembly Parts List DESCRIPTION DESCRIPTION Cabinet 140-2 Shoulder Bolt φ8x8 Rivet nut M5-0.8x12 Lock knob Hook Set screw M5-0.8x12 Rivet nut M6-1x13.5 Key 5x40 Side cover Hex bolt M8-1.25x40 Flat washer 5 Nut M8-1.25 Lock washer 5 Cap screw M6-1x16 Pan HD screw M5-0.8x12 Motor cover Dust cover...
Page 23 Trunnion Assembly Exploded View...
Page 24 Trunnion Assembly Parts List REF DESCRIPTION DESCRIPTION DESCRIPTION 201 Cap screw M6-1x20 202 Lock washer 6 Bracket for riving knife Worm 203 Flat washer 6 Flat washer 8 Copper backing 204 Point bracket Cap screw M8x16 205 Cap screw M8-1.25x25 Knurled knob Hex bolt M6-1x25 206 Lock washer 8...
Page 25 Blade Guard Exploded View GLIDER Saw Blade Guard (UL62841) DESCRIPTION DESCRIPTION Pan HD screw M4-0.7x12 Nickel Pan HD screw M4-0.7x28 Nickel Plastic spacer Spreader Left guard Right guide block Guard support Left guide block Left cover Roller Plastic liner Bearing 689ZZ Front guard Right cover Cap screw M3-0.5x8 Nickel...
Page 26 36″ Extension Table Exploded View DESCRIPTION DESCRIPTION Hex bolt M8-1.25x35 Pan HD screw M8-1.25x35 Flat washer 8 Support leg Lock washer 8 Foot Hex nut M8-1.25 Extension Table (width 505mm)
Page 27 52″Extension Table Exploded View DESCRIPTION DESCRIPTION Hex bolt M8-1.25x35 Support leg Flat washer 8 Foot Lock washer 8 Extension Table (width 505mm) Hex nut M8-1.25 Extension Table (width 365mm) Pan HD screw M8-1.25x35...
Page 28 Switch Exploded View DESCRIPTION DESCRIPTION Plastic panel Switch bracket Switch panel Flat washer 6 Electromagnetic switch Spring washer 6 Switch box Button HD screw M6X16 Knurling pin Power line Overload protection switch Single core wire Silicone foam round strip Power line Nut M6 Sealing gasket Switch box rear cover...
Page 29 Switch Exploded View DESCRIPTION DESCRIPTION Switch Lock washer 5 Switch bracket Flat washer 5 Chain Cable for power supply Safety pin Cable for motor Pan HD screw M5-0.8x16...
Page 30 Over Arm Exploded View DESCRIPTION DESCRIPTION Flexible hose (1-1/2” 0.6m) Lock washer 6 Hose Connector 1-1/2" Bracket Over arm Flexible hose (1-1/2” 1m) Cap screw M6-1x16 Clamp Flat washer 6 Cap screw M6-1x12...
