Summary of Contents for BluStream HMXL66ARC
- Page 1 HMXL88ARC User Manual REVA2_HMXL88ARC_User_Manual...
- Page 2 CEC Control Audio Return Channel Web GUI Control 08-16 Remote Control Description IR Commands 17-18 Specifications Package Contents Maintenance RS-232 Config & Telnet Commands 20-22 Web-GUI Firmware Update 23-24 Schematic Certifications www.blustream.com.au www.blustream-us.com www.blustream.co.uk...
- Page 3 Control via front panel, IR, iOS / Android App, RS-232 and TCP/IP • Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers • Supplied with Blustream IR receivers and emitters • Advanced EDID management and HDCP 2.2 compliant *CSC & ARC feature compatible with RX70CS only Contact: support@blustream.com.au...
- Page 4 IR Inputs - 3.5mm stereo connector to receiver for IR control of the Matrix HDMI Output - Connect to display connect to Blustream 5V IR receiver or TCP/IP - RJ45 connector for TCP/IP and device Control Processor. Used to extend IR Web GUI control of the Matrix HDBaseT™...
- Page 5 19 : DVI 1920x1080@60Hz, Audio None DVI 1920x1080@60Hz 20 : DVI 1920x1200@60Hz, Audio None DVI 1920x1200@60Hz 21 : HDMI 1920x1200@60Hz, Audio 2CH PCM/6CH PCM Software EDID 22 : User EDID 1 23 : User EDID 2 Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 6 Please note PoC (Power over Cable) has been disabled on this product by default to reduce the risk of damaging incompatible HDBaseT™ receiver products. Please check your HDBaseT™ receiver supports 24V PoC before enabling PoC on this Matrix. The Blustream RX70CS HDBaseT™ receiver is recommended for use with this Matrix as it supports all features of this Matrix.
- Page 7 When installing CAT cables it is advised that you use the best possible CAT cable quality. HDMI distribution products will only work if used with CAT5e standard cable or above. Blustream recommends using a CAT6 cable (or better) for installations, especially when running longer distances, in areas of high EMI, or for 4K signal distribution. It is advised that using any method of patch panel, wall plate, or join within the CAT cable is avoided as these can add degradation to the signal.
- Page 8 The Blustream range of matrix products include Matrix control via IR. IMPORTANT: Blustream Infrared products are all 5V and NOT compatible with alternative manufacturers Infrared solutions. When using third party 12V IR control solutions please use the Blustream IRCAB cable for IR conversion.
- Page 9 The Guest Control Page allows a guest to change inputs for each zone without needing to be logged into the matrix. Simply select the square that corresponds with the input and zone you wish to change. There is also a power button on the lower right corner to turn the Matrix on or off. Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 10 On the right side you can recall a preset, or save the current input/output configuration into a specified preset. There is also a power button on the lower right corner to turn the Matrix on or off. www.blustream.com.au www.blustream-us.com www.blustream.co.uk...
- Page 11 The Configuration Video Input Page allows users to change settings specific to the inputs of the matrix. You can adjust the name of each input, the EDID of each input as well as enable or disable CEC to the input. Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 12 • Enable or disable PoC (Power over Cable) to power connected HDBT receiver. It is recommended to use the Blustream RX70CS HDBT Receiver to support all features of this Matrix • Enable or disable IR being transmitted out to a zone or from that zone output •...
- Page 13 On the CEC Output Page, you must specify a specific output to send the CEC command out of. Press the icon of the command you wish to send and it will be transmitted to the display device connected to the specified output. Note CEC is subject to the support of the sources and displays connected to the matrix. Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 14 DB9 serial port at the rear of the matrix to a connected device. Baud rate and terminator command as well as Hex or ASCII can be selected. Sending an RS-232 command out via the Matrix can be useful in assisting with debugging and fault finding an RS-232 device connected to the matrix. www.blustream.com.au www.blustream-us.com www.blustream.co.uk...
- Page 15 The Network Page allows you to specify the TCP/IP network port settings. You can choose from Static IP or DHCP, as well as specify a fixed IP Address, Subnet Mask and Gateway. It is also possible to change or disable the Telnet port. Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 16 Ensure that the User Authorization button is set to On for User 2 Select the User 2 radio button Enter Name as User2 (or the user’s name) Enter Current Password as user2 Enter New password and Confirm New Password as 12345 Select the ‘Save’ button at the bottom www.blustream.com.au www.blustream-us.com www.blustream.co.uk...
- Page 17 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 003F OUTPUT 8 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689 Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 18 0016 0016 0016 0016 0016 0016 0016 0041 0016 0041 0016 0016 0016 0016 0016 0041 0016 0041 0016 0016 0016 0041 MUTE 0016 0041 0016 0041 0016 0016 0016 0041 0016 0041 0016 0016 0016 0041 0016 0016 0016 0016 0016 0016 0016 0041 0016 0016 0016 0016 0016 0679 www.blustream.com.au www.blustream-us.com www.blustream.co.uk...
- Page 19 • 1 x IR Control Cable - 3.5mm to 3.5mm • 1 x Quick Reference Guide • IEC Power Cable(s) Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit. Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 20 \r or 0D (in hex) • Spaces – Blustream commands do not require space between commands unless specified. There may be some programs that require spacing in order to work. - How the string should look is as follows OUT01ON - How the string may look if spaces are required: OUT{Space}01{Space}ON •...
- Page 21 Confirm Operation (Enter) On Output xx VOL xx TX yy xx = -: Volume Level Decreases yy = 00: Select All Output Ports OUTxx CEC UP UP On Output xx yy = [01...08]: Select Single Output Port 01 To 08 Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 22 POWER ON On Input xx INxx CEC PON xx= 00: All Output Port NET SM Set Subnet Mask Address xxx.xxx.xxx.xxx xx= [01-08]: Output 1 - 8 NET RB Set Network Reboot And Apply New Config!!! NET TN xxxx Set Telnet Port www.blustream.com.au www.blustream-us.com www.blustream.co.uk...
- Page 23 1) Login to the web-GUI update menu: Default IP Address is: 192.168.0.200:100 Default Username is: blustream Default Password is: 1234 Please note: the IP address may differ if default network settings have been updated. If this is the case, please replace the following with the products current IP address: XXX.XXX.XXX.XXX:100...
- Page 24 HMXL88ARC USER MANUAL 4) Click 'Choose File' and select the web-GUI/MediaTek firmware file downloaded from the Blustream website. This will be a .bin file: 5) Press 'Apply' to begin the firmware update process. The update process will take up to 1 minute to complete. Do not refresh or navigate away from this page until the update process has completed.
- Page 25 HMXL88ARC USER MANUAL Schematic Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
- Page 26 To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmentally safe recycling. www.blustream.com.au www.blustream-us.com www.blustream.co.uk...
- Page 27 HMXL88ARC USER MANUAL www.blustream.com.au www.blustream-us.com www.blustream.co.uk Contact: support@blustream.com.au support@blustream-us.com support@blustream.co.uk...
