Summary of Contents for Boulevard VFSL30FP7010-1

Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. White Mountain Hearth VFSL30FP70N-1 Owner's Manual Shop genuine replacement parts for White Mountain Hearth VFSL30FP70N-1 Find Your White Mountain Hearth Fireplace Parts - Select From 539 Models -------- Manual continues below --------...
Page 2 INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL CONTEMPORARY LINEAR Installer: Leave this manual with the appliance. VENT-FREE GAS Consumer: Retain this manual for future FIREPLACE MODELS GAS-FIRED reference. VFSL30FP7010(N,P)-1 VFSL30FP70(N,P)-1 DANGER If not installed, operated and maintained in accordance with the manufacturer's instructions, this product could expose you to substances in fuel or from fuel combustion which can cause death or...
Page 3 TABLE OF CONTENTS SECTION PAGE BEFORE YOU START ....................... 3 HOMEOWNER REFERENCE INFORMATION ..............4 CARTON CONTENTS ....................... 4 HARDWARE PACK CONTENTS ..................5 IMPORTANT SOOT PREVENTION STEPS ..............6 PRODUCT SPECIFICATIONS ................... 6 INTRODUCTION ....................... 7 ACCESSORIES ......................... 8 IMPORTANT SAFETY INFORMATION ..............9 - 10 SAFETY INFORMATION FOR USERS OF LP GAS ............
Page 4 BEFORE YOU START Record serial number, model number, etc. on the next page INSTALLATION TYPE and page 56. SURFACE MOUNTED INSTALLATION Read the soot-prevention information on page 6. Pages 15 - 21 Read the safety information on pages 9 - 11. Determine type of installation.
Page 5 HOMEOWNER REFERENCE INFORMATION We recommend that you record the following information about your fireplace. Model Number: _____________________________ Date purchased: ________________________ Serial Number: _____________________________ Location of fireplace: _____________________ Dealer Name: ______________________________ Dealer Phone: _________________________ Notes: ______________________________________________________________________________ ____________________________________________________________________________________ CARTON CONTENTS Items not shown to scale. Index No. Description Quantity Used On Installation Type: Surface Mounted Partially Recessed Recessed Fireplace...
Page 6 HARDWARE PACK CONTENTS VFSL30\CDR\Hardware Pack Contents -111815 SWITCH EXTENSION WIRE KIT SWITCH AND COVER CORD GRIP BATTERY PACK EXTENSION WIRE KIT WIRE NUT SNAP-IN RECEPTACLE POWER ADAPTER FLEX LINE 1-1/4” PHILLIPS DRYWALL SCREW BATTERY PACK AA BATTERY #10-32 X ½” HEX HEAD SCREW NAILING FLANGES Items not shown to scale.
Page 7 IMPORTANT SOOT PREVENTION STEPS IMPORTANT NOTICE INSTALLER - SERVICE PERSON - HOMEOWNER SOOT MAY BE CREATED IF THE FOLLOWING DIRECTIONS ARE NOT FOLLOWED. • Ensure burner and primary air holes are free of dust, CAUTION lint, animal hair (i.e. cat and dog) or anything that may Failure to keep the primary air openings of the burner block the needed air flow. See Cleaning and Servicing, clean may result in sooting and property damage.
Page 8 INTRODUCTION Important Sample Warnings and Definitions: All correspondence should refer to complete Model Number and DANGER Serial Number. Indicates a hazardous situation which, if not avoided, will result Notice: During initial firing of this fireplace, its paint will bake out, in death or serious injury. and smoke will occur. To prevent triggering of smoke alarms, ventilate the room in which the unit is installed.
Page 9 ACCESSORIES Mitered Front Dimensions Required Accessories for Surface Mounted Installation 37-13/16” 1-13/16” Decorative Front (One Required) Part Number Description DFSL30MBL Decorative Front - Mitered, Black Decorative Wrap (One Required) DCSL30LBL Decorative Wrap - Black Required Accessories for Partially Recessed Installation Decorative Front (One Required) Part Number Description...
Page 10 IMPORTANT SAFETY INFORMATION WARNING DANGER When used without adequate combustion and ventilation air, The installer of this product is responsible for testing all appliance may give off CARBON MONOXIDE, an odorless, connections for gas leaks. A gas leak will create a situation poisonous gas. where a fire, explosion, or production of carbon monoxide may result causing property damage, personal injury or loss of life. Do not install appliance until all necessary provisions are made for combustion and ventilation air.
Page 11 IMPORTANT SAFETY INFORMATION • Do not use scented air fresheners (plug in type air • Sooting: A vent-free fireplace or burner draws room air to fresheners, etc. ) while the fireplace is in operation. Air support combustion. Lightweight particles suspended in the fresheners produce a residue in the air similar to candles air – including dust, carpet fibers, candle or tobacco smoke, and may produce soot. and pet hair – will be drawn toward the fireplace. These can lead to soot build up on fireplace walls and even walls of the • Do not use scented or decorative candles while the fireplace room. To prevent malfunctions and sooting, have your dealer is in operation.
Page 12 SAFETY INFORMATION FOR USERS OF LP GAS Propane (LP Gas) is a flammable gas which can cause fires LP Gas may stratify in a closed area, and the odor intensity could and explosions. In its natural state, propane is odorless vary at different levels.
Page 13 IMPORTANT INSTALLATION GUIDELINES Fans and Cold Air Returns Near the Fireplace Any draft created around a vent-free fireplace can cause the flame to create soot. Upon installation, be aware of any cold air returns or vents in the proximity of the fireplace. Ceiling fans and floor type fans need to be monitored during the operation of this vent-free fireplace. If the air flow disrupts the flame, the source of air flow should be turned off or redirected. Reversing the blade direction ceiling fans may possibly eliminate flame impingement. Floor fans should be redirected. WARNING Do not allow fans to blow directly into or at the fireplace. Avoid any drafts that alter burner flame patterns. NOTICE: No part of the fireplace, gas line, or wiring may be installed in a wall cavity serving as a cold air return. Candles Avoid the use of scented or decorative candles while the fireplace is in operation.
Page 14 WATER VAPOR: A BY-PRODUCT OF UNVENTED ROOM HEATERS Water vapor is a by-product of gas combustion. An unvented The following steps will help insure that water vapor does not room heater produces approximately one (1) ounce (30ml) of become a problem. water for every 1,000 BTU's (.3KW's) of gas input per hour.
Page 15 PROVISIONS FOR ADEQUATE COMBUSTION & VENTILATION AIR (continued) The space in the example on page 12 is a confined space Ventilation Air From Outdoors because the actual BTU/hr used is more than the maximum BTU/ Provide extra fresh air by using ventilation grills or ducts. You hr the space can support. You must provide additional fresh air. must provide two permanent openings: one within 12 inches of Your options are as follows: the ceiling and one with 12 inches of the floor. Connect these...
Page 16 SURFACE MOUNTED FIREPLACE 35775-3-1016 Page 15...
Page 17 SURFACE MOUNTED FIREPLACE DIMENSIONS DECORATIVE WRAP FRONT VIEW SIDE VIEW FIREPLACE GAS LINE TOP VIEW SIDE VIEW ACCESS 120 V FRONT VIEW REAR VIEW GAS LINE ACCESS OPTIMUM ELECTRIC LINE ACCESS Page 16 35775-3-1016...
Page 18 SURFACE MOUNTED FIREPLACE DIMENSIONS INDEX VFSL30FP DIMENSION DESCRIPTION LETTER Dimensions in Inches The maximum height of fireplace face 17-7/8 The maximum height of decorative wrap The maximum width of the fireplace face 30-1/4 The maximum width of decorative wrap The maximum depth of the fireplace 5-1/2 The maximum depth decorative wrap 4-1/2 The height of the fireplace opening 11-3/4 The width of the fireplace opening 28-3/8 The interior depth of the fireplace (not shown) 4-3/16 Height from the bottom of the fireplace to the gas line access...
Page 19 SURFACE MOUNTED FIREPLACE INSTALLATION Provided Materials: Step 1: Find location for fireplace and install decorative Fireplace wrap. Battery Pack with 10-ft extension wire 1. Surface-mounted installation means that the fireplace will (4) AA Batteries be completely outside of the wall. In selecting a location, be AC Power Adaptor cautious of electrical wires, air ducts, water pipes, cold air Gas Flexline returns, etc.
Page 20 SURFACE MOUNTED FIREPLACE INSTALLATION Run extension wire harness(es) from opening to junction box(es) (not provided) outside of the fireplace. One junction box is for the switch (or other control). The other junction box is for the battery pack and will require a cover. Extension wires are 10-ft in length and must connect to battery pack using the connector end with side walls. Do not extend wires beyond the 10 feet provided as this will cause the controls to malfunction.
Page 21 SURFACE MOUNTED FIREPLACE INSTALLATION Step 2: Prepare Fireplace 7. Remove the knockouts in the back of the fireplace only. If Remove the screw securing the standoff on top of the using battery pack inside of decorative wrapper, open top fireplace. Discard both the screw and the standoff; they are knockout on the side of the fireplace. See Figure 9. not used in this installation. The glass panel is wrapped in cardboard and shipped in the space above the fireplace opening. Locate glass panel, and set aside in a safe location.
Page 22 SURFACE MOUNTED FIREPLACE INSTALLATION Connect battery pack extension wire to connection inside 14. Turn gas on and test for leaks at gas inlet. fireplace. 15. Place burner assembly inside fireplace and replace the two 5. Connect the green and white wires in fireplace to the control truss-head screws ("F" in Figure 7). extension wires. Snap cord grip inside of fireplace. 16. Verify desired pilot selector switch position. See page 48. Place cord grip around both extension wire harnesses.
Page 23 SURFACE MOUNTED FIREPLACE INSTALLATION 24. Install decorative front by inserting hook on the front above the top opening in the fireplace. Verify that the decorative front is level and fully seated. See Figure 16. Note: Miter Decorative Front Shown Figure 16 Notice for Finishing with Paint Use a coating designed for 300°F environments and follow the manufacturer's instructions for surface preparation, application and curing. Heat from the fireplace may cause incorrectly applied coatings to fail or discolor.
Page 24 PARTIALLY RECESSED FIREPLACE 35775-3-1016 Page 23...
Page 25 PARTIALLY RECESSED FIREPLACE DIMENSIONS VIEW RIGHT SIDE VIEW SIDE 120 V SIDE ELECTRIC LINE SIDE ACCESS ACCESS BOTTOM VIEW Page 24 35775-3-1016...
Page 26 PARTIALLY RECESSED FIREPLACE DIMENSIONS INDEX DIMENSION DESCRIPTION DIMENSIONS LETTER IN INCHES The maximum height of the fireplace face 17-7/8 The maximum width of the fireplace face (excluding nailing flanges) 30-1/4 The maximum depth of the fireplace 5-1/2 The height of the fireplace opening 11-3/4 The width of the fireplace opening 28-3/8 The interior depth of the fireplace (not shown) 4-3/16 Height from bottom of the fireplace to the side gas line access 2-1/16 Distance from side of fireplace to bottom gas line access 2-11/16 Depth from front of the fireplace to side gas line access 3-5/16 Depth from front of the fireplace to bottom gas line access 3-5/16 Depth from rear of fireplace to side gas line access 2-3/16 Depth from rear of fireplace to bottom gas line access 2-3/16 Glass panel height (not shown) in fireplace Glass panel width (not shown) in fireplace 27-1/2 Distance from fireplace bottom to fireplace access 4-1/16 Overall height to top plate 17-7/8 Opening lip of fireplace...
Page 27 PARTIALLY RECESSED FIREPLACE INSTALLATION STEP 1: Determine location for fireplace and prepare Provided Materials: Fireplace wall. Glass Panel 1. Partially recessed installation means that the fireplace will Battery Pack with 10-ft extension wire be both inside the wall and extend from the wall at least Top Non-Combustible Board 2 inches.
Page 28 PARTIALLY RECESSED FIREPLACE INSTALLATION 3. Once you determine the location, and have verified the wall cavity is free of ducts, pipes, and wires, cut an opening in the 28 3/4 wall for framing the fireplace. See Figure 18. 2 X 4 STUD NON-COMBUSTIBLE BOARD 2 X 4 TOP PLATE 2 X 4 Figure 20 - Corner Clearances Illustration BOTTOM PLATE 4. Place a 2 x 4 top plate over where the fireplace will sit and a 120V...
Page 29 PARTIALLY RECESSED FIREPLACE INSTALLATION 4. Nailing flanges are provided. Bend nailing flanges to form Remove internal junction box by removing single screw. See right angles. Locate the pairs of holes on the side of the Figure 25. fireplace that will allow the face to be 1-1/2 inches plus the thickness of the finishing material. For example, if using a 1/2-inch board without tile or other facing material covering the board, the distance from the front of the fireplace will be 2 inches.
Page 30 PARTIALLY RECESSED FIREPLACE INSTALLATION STEP 3: Install the fireplace 1. Install fireplace into wall. Secure to studs with four drywall screws. Have the gas tech run gas supply to the desired gas access location. See Figure 17, Page 26. Have the electrician run the 120V wiring to the 120V access location.
Page 31 PARTIALLY RECESSED FIREPLACE INSTALLATION 13. Plug power adaptor into plug in junction box on right of 18. Install glass panel in front of burner as shown in Figures 32 fireplace. Connect other end of power adaptor terminal into and 33. Place one end into slot inside the fireplace as shown its receiver on the right of the burner assembly. See Figure in Figure 32. Move other end of glass into fireplace opening and into slot on other side of fireplace. Move glass panel from side to side until it falls in place.
Page 32 PARTIALLY RECESSED FIREPLACE INSTALLATION 26. Install decorative front by inserting hook on the front above Notice for Finishing Materials the top opening in the fireplace. Verify that the decorative The wall above the fireplace will become hot. Install the non- front is level and fully seated. See Figure 34. combustible board supplied with the fireplace before adding paint, tile or stone.
Page 33 This page intentionally blank. Page 32 35775-3-1016...
Page 34 RECESSED FIREPLACE 35775-3-1016 Page 33...
Page 35 RECESSED FIREPLACE DIMENSIONS VIEW RIGHT SIDE VIEW SIDE 120 V SIDE ELECTRIC LINE SIDE ACCESS ACCESS BOTTOM VIEW Page 34 35775-3-1016...
Page 36 RECESSED FIREPLACE DIMENSIONS INDEX DIMENSION DESCRIPTION DIMENSIONS LETTER (IN INCHES) The maximum height of fireplace face (excluding standoffs) 17-7/8 The maximum width of the fireplace face (excluding nailing flanges) 30-1/4 The maximum depth of the fireplace 5-1/2 The height of the fireplace opening 11-3/4 The width of the fireplace opening 28-3/8 The interior depth of the fireplace (not shown) 4-3/16 Height from bottom of the fireplace to the side gas line access 2-1/16 Distance from side of fireplace to bottom gas line access 2-11/16 Depth from front of the fireplace to side gas line access 3-5/16 Depth from front of the fireplace to bottom gas line access 3-5/16 Depth from rear of fireplace to side gas line access 2-3/16 Depth from rear of fireplace to bottom gas line access 2-3/16 Glass panel height in fireplace (not shown) Glass panel width in fireplace (not shown) 27-1/2 Distance from fireplace bottom to fireplace opening 4-1/16 Overall height to top plate 29-1/8 Opening lip of fireplace 9/16...
Page 37 RECESSED FIREPLACE INSTALLATION Provided Materials: Attention: Directions are for non-load bearing walls. For load Fireplace bearing walls, consult local codes. Glass Panel (2) Side Non-Combustible Board STEP 1: Find location for fireplace and prepare wall. Top Non-Combustible Board 1. Recessed installation means that the fireplace will be inside (4) AA Batteries the wall.
Page 38 RECESSED FIREPLACE INSTALLATION See Clearances to Combustibles on pages 43 - 44. 3. Once you determine the location, and have verified the wall 28 3/4 cavity is free of ducts, pipes, and wires, cut an opening in the wall for framing the fireplace. See Figure 36. 4. The framing must support the fireplace. Place a 2 x 6 bottom plate that will support the fireplace. Verify the plate is level. Place a 2 x 6 top plate that will support the top of the non-combustible board.
Page 39 RECESSED FIREPLACE INSTALLATION 4. Nailing flanges are provided. The flanges included are flat Remove junction box on right by removing single screw. See but easily bend to form a right angle. Locate the pairs of Figure 43. holes on the side of the fireplace that will place the outside of the wall covering at the 1/16-inch past the fireplace opening. See Figure 40. Figure 43 Figure 40 9. Using back and forth action, open the knockouts required for 5. Screw nailing flanges into the fireplace with hex screws installation.
Page 40 RECESSED FIREPLACE INSTALLATION STEP 3: Install the fireplace 1. Install the fireplace into the cutout in the wall. Attach to side studs with drywall screws. Attach the top standoff to the top plate with a drywall screw. Have the gas technician run gas supply to the desired gas access location. See Figure 36, Page 36. Have the electrician run the 120V wiring to the 120V access location.
Page 41 RECESSED FIREPLACE INSTALLATION 11. Connect the 120V power line to receptacle in internal 17. Install glass panel in front of burner as shown in Figures 50 junction box. See Figure 66, page 50. Re-attach junction and 51. Place one end into slot inside the fireplace as shown box inside of fireplace. in Figure 50. Move other end of glass into fireplace opening 12.
Page 42 RECESSED FIREPLACE INSTALLATION 25. Install optional decorative trim by inserting tabs into the Notice for Finishing Materials small slots to the left and right of the opening in the fireplace. The wall above the fireplace will become hot. Install the non- Insert screw from decorative trim kit into sides of fireplace. combustible board supplied with the fireplace before adding Screws will go through slots in the decorative trim tabs. paint, tile or stone.
Page 43 GAS SUPPLY CAUTION VALVE Two gas line installations at the same time are prohibited. The access plate to the switching means shall not be opened while the heater is in operation. GAS SUPPLY PIPING The gas pipeline can be brought in through the left side or bottom of the fireplace. A flexline is provided connected to the valve on the left side of the fireplace. See Figure 4, 17, &...
Page 44 GAS SUPPLY Checking Manifold Pressure OUTLET INLET Natural gas will have a manifold pressure of approximately PRESSURE PRESSURE 3.5 inches w.c. at the pressure regulator outlet with the inlet pressure to the pressure regulator from a minimum of GAS VALVE 5.0 inches w.c.
Page 45 MANTEL CLEARANCES 12” CEILING 10” 8” 18” MIN 6” 4” SIDE WALL 2” 6” FLOOR Figure 57 - Ceiling Clearance Illustration OPENING 28 3/4 Dimension Index Letter (in inches) Figure 58 - Corner Clearances Illustration Attention: Surface mounted installation shown. Mantel clearances are the same for recessed, partially recessed, and surface mounted installations.
Page 46 CLEANING AND SERVICING Annual inspection and cleaning by your dealer or qualified service technician is recommended to prevent malfunction and/or sooting. WARNING To avoid burns, turn off fireplace and allow to cool before cleaning. INTAKE PERIODIC CLEANING - Refer to parts diagram for location of items discussed below. PILOT SUPPLY Always turn off gas to the pilot before cleaning.
Page 47 LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which can be lighted with the C. Use only the remote control or manual remote receiver manual on/off switch, a remote control, or by switching switch to operate the gas valve.
Page 48 PILOT FLAME CHARACTERISTICS Figure 63 shows a correct pilot flame pattern. The correct flame will be blue and will extend beyond the flame sensor. The flame will surround the flame sensor just below the tip. A slight yellow flame may occur where the pilot flame and main burner flame meet. Figure 64 shows an incorrect pilot flame pattern. The incorrect pilot flame is not touching the flame sensor. This will cause the flame sensor to cool. When the flame sensor cools, the fireplace will shut down. IGNITOR IGNITOR FLAME SENSOR FLAME SENSOR PILOT PILOT Correct Pilot Flame Pattern - Figure 63 Incorrect Pilot Flame Pattern - Figure 64 If pilot flame pattern is incorrect, as shown in Figure 64: • See IP Troubleshooting, pages 51 - 53. OPERATING INSTRUCTIONS/FLAME APPEARANCE Flames from the pilot as well as the main flame should be visually During manufacturing, fabricating and shipping, various...
Page 49 IP OPERATING INSTRUCTIONS 5.25 VDC ELECTRONIC CONTROL VALVE Follow the SAFETY and LIGHTING INSTRUCTIONS for Intermittent Pilot controls found in this manual, and on labels The electronic control valve system includes the ability to switch found in the control compartment located in the lower cavity the pilot from a standing pilot mode to an intermittent pilot mode.
Page 50 IP WIRING WIRING DIAGRAM CPI/IPI PILOT SWITCH GREEN BLUE BLUE ORANGE WHITE WHITE REMOTE RECEIVER (OPTIONAL) YELLOW + ON REMOTE - OFF BLACK BLACK ON/OFF SWITCH GAS CONTROL VALVE (GND) AC/DC POWER ADAPTOR BLACK BLACK ELECTRONIC CONTROL MODULE BATTERY HOLDER If any of the original wire as supplied with this unit must be replaced, it must be replaced with equivalent gauge and temperature rated wire.
Page 51 ELECTRICAL CONSIDERATIONS CAUTION All wiring should be done by a qualified electrician and shall be in compliance with all local, city and state building codes. Before making the electrical connection, make sure that the main power supply is disconnected. The appliance, when installed, must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National Electrical Code ANSI/NFPA 70 (Latest Edition).
Page 52 IP TROUBLESHOOTING • The control module is an automatic gas ignition system based on a single micro-controller core. This control manages all functions related to ignition, flame sensing. • The control module can be set to provide continuous or intermittent ignition control sequences and flame monitoring with safety shutdown in case of failure. •...
Page 53 INTERMITTENT PILOT CONTROL SYSTEM TROUBLESHOOTING PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURE See “What to do if you smell gas” Pages 1 and 46. Gas odor during setup Gas Leak Check all gas connections. Tighten all loose connections. See “What to do if you smell gas” Pages 1 and 46.
Page 54 INTERMITTENT PILOT CONTROL SYSTEM TROUBLESHOOTING PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURE Low gas pressure Check gas supply pressure Loose sensor wire Check wire connection Faulty valve Replace valve Faulty pilot or thermocouple Replace Safety pilot Burner lights but does not stay Clogged or dirty burner ports Clean burner ports lit while pilot remains on...
Page 55 PARTS LIST Index Part Number Description Number VFSL30FP70(N,P) VFSL30FP7010(N,P) 35700 35351 Burner Plate Assembly, Black 35699 35699 Screen Assembly, Black 35551 35551 Valve Bracket 35552 35552 Control Module Bracket 35547 35547 Junction Box 35555 35555 Nailing Flange (4 supplied) R11232 R11232 Glass Panel 35548...
Page 56 EXPLODED VIEW WARNING Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. 35775-3-1016 Page 55...
Page 57 Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing Victor Division of F. W. Webb Company 1401 Willow Lake Boulevard 200 Locust Street Vadnais Heights, MN 55101 Hartford, CT 06114 Phone: 651-490-9191...
Page 58 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 35775-3-1016 Page 57...
Page 59 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 58 35775-3-1016...
Page 60 Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual. Empire will not warranty any Boulevard fireplace that is not installed by the selling dealer or that dealer’s direct contract agents. This warranty applies to the original purchaser only and is not transferable. All warranty repairs must be accomplished by a qualified gas appliance technician.
Page 61 Empire Comfort Systems Inc. EMPIRE Belleville, Illinois EMPIRE If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 60 35775-3-1016...
