FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Leave the building immediately.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
If not installed, operated and maintained
in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
WARNING
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk
individuals.
Note: Barrier required, may be sold separately.

INSTALLATION INSTRUCTIONS

AND OWNER'S MANUAL
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING
WARNING
HOT GLASS
CAUSE BURNS.
DO NOT TOUCH
UNTIL COOLED.
NEVER
ALLOW CHILDREN
TO TOUCH GLASS.
DIRECT VENT ZERO CLEARANCE
GAS FIREPLACE HEATER
MULTIFUNCTION REMOTE (MF)
UL FILE NO. MH30033
This appliance may be installed in
an aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases, unless a certified kit is
used.
WILL
GLASS
MODEL SERIES:
DVLL60BP90N-1
DVLL60BP90P-1
GAS-FIRED
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVLL60BP90N-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Boulevard DVLL60BP90N-1

Summary of Contents for Boulevard DVLL60BP90N-1

  • Page 1: Installation Instructions

    MODEL SERIES: Failure to follow safety warnings exactly could result in serious injury, death or MULTIFUNCTION REMOTE (MF) property damage. DVLL60BP90N-1 — Do not store or use gasoline or other DVLL60BP90P-1 flammable vapors and liquids in the GAS-FIRED vicinity of this or any other appliance.
  • Page 2 BEFORE YOU START Sample Warnings and Definitions: Unpacking the fireplace Cut binding straps and shrink wrap. DANGER Remove top board and corner posts. Indicates a hazardous situation which, if not avoided, will result 3. Lift fireplace off of the pallet. in death or serious injury. Remove non-combustible boards from pallet and set aside.

  • Page 3: Aaa Battery

    CARTON CONTENTS & HARDWARE PACK #10 X ½” HEX HEAD SCREW 1” PHILLIPS SELF DRILLING SCREW NAILING FLANGES Items not shown to scale. INDEX QUANTITY DESCRIPTION NUMBER SUPPLIED Door Removal Tool (attached to fireplace) Product Registration Card AA Battery AAA Battery Wall Thimble Spacer (attached to fireplace) Cover Plate, Battery Box Remote Junction Box Cover Duplex Receptacle...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE INTRODUCTION ......................5 SPECIFICATIONS ....................6 ACCESSORIES .......................7 FBB20 BLOWER INSTALLATION ..............8 - 10 FIREPLACE DIMENSIONS ................... 11 CLEARANCES .......................12 LOCATING FIREPLACE ..................13 VENT TERMINATION CLEARANCES ............14 - 15 GAS SUPPLY ....................16 - 17 ELECTRICAL CONNECTIONS ...............18 - 19 INSTALLATION ....................20 - 23 VENT SYSTEM IDENTIFICATION .................24 VENT SYSTEMS ....................24 VENTING FIREPLACE - TOP .................25 - 27 TOP VENT - HORIZONTAL TERMINATION ............28...

  • Page 5: Introduction

    INTRODUCTION Instructions to Installer The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code ANSI Z223.1/ Leave instruction manual with owner. NFPA 54* Natural Gas and Propane Installation Code, or CSA 2. Have owner fill out and mail Product Registration Card B149.1 in Canada.

  • Page 6: Specifications

    SPECIFICATIONS DVLL60BP90 Input BTU/Hr Maximum 46,000 42,500 Input BTU/Hr Minimum 31,000 32,500 KWH (Maximum) 13.34 12.33 KWH (Minimum) 9.00 9.43 Orifice #29 (P280) #48 (P300) Air Shutter Opening 1/16in Fully Open Height without standoff 36-5/16in 36-5/16in Width 73in 73in Depth 18-5/8in 18-5/8in Gas Inlet Shutoff Valve (pipe) 1/2in NPT 1/2in NPT Vent Size 5 x 8 5 x 8 NOTE: Air shutter settings are factory minimum settings. Some venting configurations may require minor air shutter adjustments for optimum performance.

  • Page 7: Accessories

    ACCESSORIES The following accessory parts can be obtained from your Empire Comfort Systems dealer. Contact your Empire Dealer for more accessory options. If you need additional information beyond what your dealer can furnish, contact Empire Comfort Systems Inc., 918 Freeburg Ave., Belleville, Illinois 62220-2623. Model Number Description DVP60LPZ* Ridgeback Liner (bronze painted) DVP60LKR* Porcelain liner (black) FBB20** Blower Kit (dual) 35470 Conversion Kit - LP to Nat 35469 Conversion Kit - Nat to LP DF60BL Beveled Finishing Trim (Black) - Adjustable (1/2in to 1-1/2in finish materials) DF60HP Beveled Finishing Trim (Hammered Pewter) - Adjustable 1/2in to 1-1/2in (finish materials) LS60THF Rustic Contemporary Logs, Stones, and Metal Curls *Note: The fireplace is shipped without a liner installed. However, a liner must be installed at the time of fireplace installation or prior to its operation. **Note: If the optional blower kit is desired, installation into the fireplace through the rear access panel is easier, prior to placing the fireplace into the framed out location.

  • Page 8: Fbb20 Blower Installation

    FBB20 BLOWER INSTALLATION 3. Use a rag to wipe the inside bottom of the fireplace (where the blowers will be placed) to remove dirt or construction dust. 4. Place blowers on the floor behind the fireplace. Position the blowers with the two black connecting wires and green ground wire towards the left hand side when facing the back of the fireplace. See Figure 2. BLOWER ASSEMBLY PARTS LIST INDEX PART DESCRIPTION 35727 Blower Assembly - Single R11788...
  • Page 9 FBB20 BLOWER INSTALLATION Begin installing the left blower assembly into the bottom of Next, install the right hand blower assembly towards the the fireplace. Once the blower is about half way in, secure right side of the access opening. The right hand edge of the wiring within the white plastic wire retention clips provided in blower base bracket should be about even with the right the fireplace. See Figure 4.
  • Page 10 FBB20 BLOWER INSTALLATION 10. Make sure the blower base brackets are pulled rearward against the bottom flange of the fireplace. The magnets on the blower base bracket will keep the blowers in place. See Figure 8. Figure 8 11. Re-attach the Blower Access Panel with the 11 screws removed in step 2. See Figure 1. 12.

  • Page 11: Fireplace Dimensions

    FIREPLACE DIMENSIONS DVLL60BP90 INDEX DIMENSION DESCRIPTION LETTER Dimensions in Inches The maximum height of firebox face (excluding standoffs) 36-1/4 The maximum width of the firebox face (excluding nailing flanges) The maximum depth of the firebox 19-1/2 The height of the firebox opening The width of the firebox opening 64-1/4 The interior depth of the firebox (not shown) The rear exterior width of the firebox The height to the firebox standoffs 49-1/4 Width from the left side of the box to the centerline of vent 36-9/16 Depth from back of box to centerline of top vent 7-1/8 Height from the bottom of the box to the gas line opening 14-3/4...

  • Page 12: Clearances

    CLEARANCES Mantel Chart Clearance to Combustibles 12” Back Side Floor Top Stand-off Bracket Top Framing Edge 13in SEE MANTEL CHART FOR MAXIMUM MANTEL DEPTH 3” MINIMUM 34” 2” X 4” HEADER FINISHED WALL (COMBUSTIBLE) 22” SEE MANTEL CHART TOP FRAMING LEDGE FOR MINIMUM HEIGHT STAND-OFF 13”...

  • Page 13: Locating Fireplace

    LOCATING FIREPLACE CORNER CABINET INSTALLATION INSTALLATION FLUSH WALL ISLAND INSTALLATION INSTALLATION ANGLED CORNER INSTALLATION ROOM DIVIDER INSTALLATION Note: Island and Room Divider installation is possible as long as the horizontal portion of the vent system does not exceed 20 feet with a minimum vertical run of 8 feet. See details in Venting Section.

  • Page 14: Vent Termination Clearances

    VENT TERMINATION CLEARANCES Termination clearance for buildings with combustible and noncombustible exteriors. Figure 14 Vertical Sidewall Installations Important! Minimum clearance between vent pipes and The graph showing the relationship between vertical and combustible materials is 3 inch (76 mm) on top, and 1 horizontal side wall venting will help to determine the various vent inch(25 mm) on bottom and sides.
  • Page 15 VENT TERMINATION CLEARANCES Canadian Installations1 US Installations2 Canadian Installations1 US Installations2 A= Clearance above grade, I= Clearance to service veranda, porch, deck, or 12 in (30 cm) 12 in (30cm) 3 ft (91 cm) 6 ft (1.83 m) Minimum regulator vent outlet balcony J= Clearance to nonme- 12 in (30 cm) for appli- 9 in (23 cm) for appli- 12 in (30 cm) for appli- 9 in (23 cm) for appli- chanical air supply B= Clearance to window or ances >...

  • Page 16: Gas Supply

    GAS SUPPLY The gas pipeline can be brought in through the right side of the A gas valve and ground joint union should be installed in the gas fireplace. Consult the current National Fuel Gas Code, ANSI line upstream of the gas control to aid in servicing. It is required Z223.1 CAN/CGA-B149 (.1 or .2) installation code.
  • Page 17 GAS SUPPLY Checking Manifold Pressures Gas Line Connection Both Propane and Natural gas valves have a built-in pressure Remove the access panel from the right side of the fireplace regulator in the gas valve. Natural gas models will have a shown in Figure 18 to access the gas valve, gas flex line, junction manifold pressure of approximately 3.5in w.c. (.871 kPa) at the box, and system wiring. valve outlet with the inlet pressure to the valve from a minimum Attach the gas flex line to the pre-installed gas line. Refer to the of 4.5in w.c. (1.120 kPa) for the purpose of input adjustment to Gas Supply section in this manual for details on the installation...

  • Page 18: Electrical Connections

    ELECTRICAL CONNECTIONS CAUTION All wiring should be done by a qualified electrician and shall be in compliance with all local, city and state building codes. Before making the electrical connection, make sure that the main power supply is disconnected. The fireplace, when installed, must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National Electrical Code ANSI/NFPA 70 (Latest Edition).

  • Page 19: Battery Box

    ELECTRICAL CONNECTIONS Once the Junction box has been installed with the receptacle outlets facing inward towards the fireplace, locate the 3-prong power cord from the control module and plug into the receptical. The fireplace is supplied with a User Interface wall box that must be installed in a standard plastic outlet box (not provided). A low voltage orange or blue box is recommended. The user interface wall box must be placed in the wall within ten feet from the right side of the fireplace. A 10ft. battery and user interface extension wire harness is supplied.

  • Page 20: Installation

    INSTALLATION Framing To further prevent drafts, the wall shield and ceiling firestops This fireplace can be elevated off the floor provided that the should be caulked with caulk rated for a minimum of 300°F fireplace is properly supported by framing materials and the continuous exposure rating to seal gaps. Gas line holes and ceiling clearances are maintained. other openings should be caulked or stuffed with unfaced Fireplace framing can be built before or after the fireplace is set insulation. If the fireplace is being installed on a cement surface, in place.
  • Page 21 INSTALLATION 5. Secure fireplace to framing with nailing flanges. Preset depth Vent Pipe Clearance to suit facing material (flush or 1/2in set back depths). See Note: Maintain one inch of clearance around vertical vent pipe. Figure 25. See Figure 27. For horizontal vent, maintain a minimum 1 inch clearance to the bottom and sides of the vent, and 3 inch clearance to combustibles above the vent pipe.
  • Page 22 INSTALLATION Finishing Methods Vent Runs In planning the installation for the fireplace, it is necessary to install certain components before the fireplace is completely 2” X 4” HEADER positioned and installed. These include the direct vent system, gas piping and electrical wiring. FINISHED WALL (COMBUSTIBLE) The fireplace can be mounted on any of the following surfaces: 1. A flat, hard combustible surface. A raised wooden platform. TOP FRAMING LEDGE VERTICAL, 90-DEGREE ELBOW WITH HORIZONTAL NON-COMBUSTIBLE BOARD TERMINATION...
  • Page 23 INSTALLATION CORNER INSTALLATION - VERTICAL, 90 DEGREE ELBOW VERTICAL, 90 DEGREE ELBOW TO HORIZONTAL OUT THE TO HORIZONTAL OUT THE WALL WALL (12in minimum rise before elbow) (12in minimum rise before elbow) FIRESTOP SPACER (INCLUDED) “A” PIPE 90° ELBOW LENGTH 31 5/8”...

  • Page 24: Vent System Identification

    VENT SYSTEM IDENTIFICATION Begin the vent system installation by selecting the type of venting what systems are acceptable. Check all clearances and venting components. Identify if any problems exist in the vent system. to be installed and the path it will take. Verify clearances are met throughout the path of the venting system.

  • Page 25: Venting Fireplace - Top

    VENTING FIREPLACE - TOP WARNING Use flue restrictor for vertically terminated fireplaces only. Do not use for horizontally terminated fireplaces. Figures 37 to 40 show the location and recommended opening for the flue restrictor. Installation of restrictor before venting is attached. See Figure 37. Figure 40 Figure 37 Note: When installing flue restrictor, install with screw pointing downward. For installation of the restrictor after the venting is installed, see Figures 38 & 39. FLUE RESTRICTOR REMOVE BAFFLE TO INSTALL...
  • Page 26 VENTING FIREPLACE - TOP Positioning the Fireplace Below Grade Installation Determine the exact position of the fireplace so the direct-vent When it is not possible to meet the required vent termination termination will be centered (if possible) between two studs. clearances of 12 inch (305 mm) above grade level, a snorkel This will avoid any extra framing. All vent kit pipes should be kit is recommended. It allows installation depth down to 7 inch assembled on the fireplace after the fireplace is moved into the (178 mm) below grade level. The 7 inch (178 mm) is measured final position.
  • Page 27 VENTING FIREPLACE - TOP To Use the Vent Graph EXAMPLE C: Determine the height of the center of the horizontal vent If the horizontal run to the outer wall flange is 17 feet, the vertical pipe. Using this dimension on the Sidewall Vent Graph, dimension from the floor of the fireplace to the center of the locate the point it intersects with the slanted graph line. termination must not be less than 7 feet 6 inches. From the point of this intersection, draw a vertical line to the SPECIAL NOTE: For each 45°...

  • Page 28: Top Vent - Horizontal Termination

    TOP VENT - HORIZONTAL TERMINATION One 90° Elbow Two 90° Elbows Note: Subtract 3 feet from the total horizontal measurement for INSTALLED VERTICALLY each 90° elbow installed horizontally. Subtract 1-1/2 feet from the total horizontal measurement for each 45° elbow installed horizontally.

  • Page 29: Top Vent - Vertical Termination

    TOP VENT - VERTICAL TERMINATION No Elbows Three 90° Elbows Note: Subtract 3 feet from the total horizontal measurement for each 90° elbow installed horizontally. Subtract 1-1/2 feet from the total horizontal measurement for each 45° elbow installed horizontally. DIMENSIONS (in inches) MINIMUM MAXIMUM 120 (10ft) 480 (40ft) Figure 49 EXAMPLE VENT RUNS INITIAL PIPE A (Vertical) B (Horizontal) Two 90°...

  • Page 30: Vertical Termination

    VERTICAL TERMINATION Locate and mark the center point of the vent pipe using a nail on CAUTION the underside of the roof. Drive the nail through the center point. Mark the outline of the roof hole around this center point. Treatment of firestop spacers and construction of NOTE: Size of the roof hole dimensions depend on the pitch the chase may vary with the type of building.

  • Page 31: Vertical Termination

    VERTICAL TERMINATION Vertical Through-the-Roof Applications General Maintenance Your Gas Fireplace has been approved for: Inspect venting system semi-annually as follows: a) Vertical installations up to 40 feet in height. 1. Check for corrosion areas of the venting system exposed b) Two sets of 45 degree elbow offsets within these vertical to the elements. These will appear as rust spots or streaks installations. From 0 to a maximum of 8 ft. a vent pipe can be and, in extreme cases, holes.

  • Page 32: Dvvk-5F Flex Vent Instructions

    DVVK-5F FLEX VENT INSTRUCTIONS The DVVK-5F FLEX VENT KIT includes the following components: • (1) Horizontal Termination Cap • (1) 4-foot section of Flex vent with spacers (5-inch flue/ 8-inch outer pipe) with flue adapter collar • (1) Wall Firestop/Thimble Assembly • Hardware pack that includes band clamps and screws Maintain at least ½-inch rise for every 12 inches of vent run. CAUTION • Because of sharp edges, always use gloves when 5”...
  • Page 33 DVVK-5F FLEX VENT INSTRUCTIONS Prior to making the vent connections, apply high temperature sealant (1000°F min.) to the vent connections before securing with the band clamps provided. Note: the flue pipe end without the adapter is to be installed to the Termination Cap. 10. Apply sealant to the outside of the flue pipe adapter and connect to the flex flue pipe.

  • Page 34: Framing And Finishing

    FRAMING AND FINISHING Installing Support Brackets Installing Firestops Install a horizontal pipe support used for each 3 feet of horizontal Firestops are required for safety whenever the vent system run to framing members. Allow 3 inch clearance to combustibles passes through an interior wall, an exterior wall, or a ceiling. above 8-inch diameter pipe and elbows, and 1 inch clearance to These firestops act as a firebreak heat shield and as a means both sides and bottom.
  • Page 35 FRAMING AND FINISHING Vertical Firestops Vertical runs of this system which pass through ceilings require the use of ONE ceiling firestop at the hole in each ceiling through which the vent passes. Position a plumb bob directly over the center of the vertical vent component and mark the ceiling to establish the center point of the vent.

  • Page 36: Liner Installation

    LINER INSTALLATION Note: A liner is required for operation of this fireplace. Refer to the instructions that came with your liner for proper installation. DVP60LPZ - Bronze Ridgeback Liner Kit Figure 66 DVP60LKR - Black Porcelain Liner Kit Figure 67 Page 36 35662-3-0216...

  • Page 37: Glass Placement

    GLASS PLACEMENT Preparation of fireplace prior to decorative media placement The accent glass panels are wrapped and secured to the burner cover assembly with a cable tie for shipping purposes. Cut the cable tie, then remove and set aside the accent glass panels.

  • Page 38: Multifunction Remote Operating Instructions

    MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Figure 69 Technical Data Remote Control Supply voltage 4.5 V (three 1.5 V AAA batteries) Ambient temperature ratings 0-50°C (32 - 122°F) Radio frequency 315 MHz WARNING THE TRANSMITTER AND RECEIVER ARE RADIO FREQUENCY DEVICES. PLACING THE RECEIVER IN OR NEAR METAL MAY SEVERELY REDUCE THE SIGNAL RANGE. Figure 70 WARNING TURN OFF THE MAIN GAS SUPPLY AND ELECTRICAL SUPPLY TO THE FIREPLACE DURING INSTALLATION AND/ OR MAINTENANCE OF THE RECEIVER DEVICE. NOTE: This control system includes a Battery Back-up pack that allows the Fireplace to operate in the event of a power WARNING outage.
  • Page 39 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Initializing the System for the First Time With the batteries already installed in the Transmitter, Remove the wall cover. Remove cover on the wall mounted push the On button. The Receiver will beep four times to battery back-up holder.
  • Page 40 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Turn On the Fireplace With the system OFF, press the ON/OFF Button on the Transmitter. The Transmitter display will show some other active Icons on the screen. At the same time the Receiver will activate the fireplace. A single beep from the Receiver will confirm reception of the command.
  • Page 41 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS The Thermostat Feature may be disabled if desired. Smart Thermostat (Transmitter Operation) With all the (3) AAA type batteries installed: The Smart Thermostat function adjusts the flame height in 1. Take out one AAA battery. accordance to the difference between the set point temperature 2. While re-inserting the AAA battery, Push and hold down the and the actual room temperatures.
  • Page 42 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Blower Control (Fan) Remote Dimmer Control (Light) If the fireplace is equipped with a hot air circulating fan, the The auxiliary function controls the AUX power outlet by the speed of the fan can be controlled by the Proflame system. dimmable light control. To activate this function, use the Mode The fan speed can be adjusted through six speeds. To activate Button (Figure 70) to index to the AUX icon. See Figures 87 and this function, use the Mode Button (Figure 70) to index the fan control icon.
  • Page 43 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Split Flow Control (Option not available for the DVLL60BP Remote Auxiliary Relay Control (optional with this fireplace) Series Fireplaces) The auxiliary function controls the AUX relay outlet. To activate this function use the Mode Button (Figure 70) to index to the The secondary burner is controlled by the split flow. To activate this function use the Mode Button (Figure 70) to index to the AUX icon (Figures 91 & 92). Pressing the Up Arrow Button will SPLIT FLOW mode icon. See Figures 89 and 90.
  • Page 44 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Continuous Pilot/Intermittent Pilot (CPI/IPI) Selection Button Lock With the system in OFF position press the Mode Button (Figure This function will lock the Buttons to avoid unsupervised 70) to index to the CPI mode icon. See Figures 93 and 94. operation.

  • Page 45: Multifunction Remote Operating Instructions

    MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Using the Fireplace without a Remote Control Lockout State Definition The fireplace can be turned ON (HI only) and OFF with the wall A lockout state is reached when an ignition error occurs. The switch. The fireplace flame ON/OFF is the only function that will lockout state will remain set in memory as long as the power operate; no flame adjustment, light or blower will work when supplies are applied.

  • Page 46: Control System Troubleshooting

    CONTROL SYSTEM TROUBLESHOOTING If the IFC is signaling lock out: The Verify the electrical connections’ integrity and board should be unlocked to make sure they are in accordance with the relevant reinitiate a pilot flame ignition (for Is the IFC board in system wiring diagram.

  • Page 47: Control System Troubleshooting

    CONTROL SYSTEM TROUBLESHOOTING Replace IFC board. Main burner lights when the pilot only Replace the gas valve. should light. Verify the pilot flame fully engulfs the tip of the sense electrode. If not, replace the pilot assembly. Replace the pilot assembly. Carefully clean the electrical connections of the sense cable and the IFC board sense cable connection.

  • Page 48: Lighting Instructions

    LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INjURY, OR LOSS OF LIFE. A. This appliance must be lighted with the remote control. C. Use only the remote control to operate the valve. When lighting the pilot, follow these instructions Never use tools.
  • Page 49 This page intentionally blank. 35662-3-0216 Page 49...

  • Page 50: Parts View

    PARTS VIEW 43 45 38 44 WARNING Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this fireplace may result in property damage or personal injury. Page 50 35662-3-0216...

  • Page 51: Parts List

    PARTS LIST Index Part Description Index Part Description Number Number Number Number R10918 Pilot - LP 30975 Flue Outlet Assembly 34425 Pilot Bracket M170 Gasket, Flue Outlet R10933 Gasket - Venturi R7567 Inlet Vent Adaptor - 8in R10432 Venturi Tube - 90 Degree R7573 Gasket - Inlet Vent R7624 Air Shutter...

  • Page 52: Component Wiring Diagram

    COMPONENT WIRING DIAGRAM USER INTERFACE/ PILOT TO LIGHTS BATTERY HOLDER GREEN ORANGE YELLOW AUX. WHITE BLACK WHITE GAS CONTROL VALVE LOOP BLOWER BLACK ORANGE WHITE BLACK TO JUNCTION WHITE GREEN ORANGE If any of the original wire as supplied with this fireplace must CAUTION be replaced, it must be replaced with equivalent gauge and Label all wires prior to disconnection when servicing controls.

  • Page 53: Maintenance And Service

    MAINTENANCE AND SERVICE Removing the Barrier Screen Wiring Lift the barrier up approximately 1/4in with one hand under the If any of the original wire supplied with this unit must be replaced, lower barrier frame edge to disengage the lower flange. Grasp it must be replace with 18 GA. 150°C wire or its equivalent. the top of the barrier and pull forward to disengage it. Remove the barrier by pulling straight forward.
  • Page 54 MAINTENANCE AND SERVICE Gas Valve and Control Access Instructions Remove the twelve 5/16in hex-head screws that secure the access cover plate on the right side of the firebox. See CAUTION Figure 102. Sharp Edges! Use gloves and eye protection when servicing the fireplace controls. NOTICE: To service or inspect the gas valve and control system after the fireplace has been installed, or if there is no right side outer accessibility, follow these steps for servicing the fireplace gas control valve.
  • Page 55 MAINTENANCE AND SERVICE Accessing the Control Module SERVICE Always turn off gas and electrical supply to the fireplace before servicing the controls. Do not disassemble the gas control; it contains non-replaceable Remove the barrier screen and glass door assemblies, and components. Attempted disassembly or repair can damage the set them aside in a safe location. control.

  • Page 56: Maintenance And Service

    MAINTENANCE AND SERVICE Glass Door and Barrier Screen Removal and Replacement • Check Vent System Refer to page 53 for removal of the barrier screen and glass door The fireplace and venting system should be inspected before assemblies. initial use and at least annually by a qualified service person. Refer to the Parts View and Parts List on pages 50 and 51 to Inspect the external vent cap on a regular basis to make sure identify replacement parts such as the barrier screen and glass that no debris is interfering with the air flow.

  • Page 57: Important Safety Information

    IMPORTANT SAFETY INFORMATION • DO NOT put anything around the fireplace that will obstruct WARNING the flow of ventilation air. • DO NOT use this fireplace if any part has been under water. Read and follow these safety precautions prior to operating this Immediately call a qualified service technician to inspect the fireplace. Failure to follow these precautions may result in death, fireplace and to replace any part of the control system and injury, or property damage. any gas control which has been under water. • DO keep the fireplace area clear and free from combustible Before enclosing the vent pipe assembly, operate the material, gasoline and other flammable vapors and liquids.

  • Page 58: Safety Information For Users Of Lp Gas

    SAFETY INFORMATION FOR USERS OF LP GAS Propane (LP-Gas) is a flammable gas which can cause fires The odorant in escaped gas can adsorb or absorb onto or into and explosions. In its natural state, propane is odorless walls, masonry and other materials and fabrics in a room. That and colorless.

  • Page 59: Requirements For Massachusetts

    REQUIREMENTS FOR MASSACHUSETTS For all side wall horizontally vented gas fueled equipment 3. SIGNAGE. A metal or plastic identification plate shall be installed in every dwelling, building or structure used in whole permanently mounted to the exterior of the building at a or in part for residential purposes, including those owned or minimum height of eight feet above grade directly in line with operated by the Commonwealth and where the side wall exhaust the exhaust vent termination for the horizontally vented gas...
  • Page 60 FIREPLACE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 60 35662-3-0216...

  • Page 61: Fireplace Service History

    FIREPLACE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 35662-3-0216 Page 61...

  • Page 62: Master Parts Distributor List

    This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing Victor Division of F. W. Webb Company 1401 Willow Lake Boulevard 200 Locust Street Vadnais Heights, MN 55101 Hartford, CT 06114 Phone: 651-490-9191...

  • Page 63: Warranty

    WARRANTY Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual. Empire will not warranty any Château, Boulevard, or Mantis fireplace that is not installed by the selling dealer or that dealer’s direct contract agents. This warranty applies to the original purchaser only and is not transferable. All warranty repairs must be accomplished by a qualified gas appliance technician. Limited Lifetime Parts Warranty – Combustion Chamber, Heat Exchanger, and Factory-Installed Glass If the combustion chamber, heat exchanger (see parts list) or factory-installed glass fails because of defective workmanship or material, Empire will repair or replace at Empire’s option. Limited Three-Year Parts Warranty – All Other Components (Except Remote Controls, Thermostats, Accessories and Replacement Parts) Should any part fail because of defective workmanship or material within three years from the date of purchase, Empire will repair or replace at Empire’s option.
  • Page 64 Empire Comfort Systems Inc. 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com Page 64 35662-3-0216...
