PEERLESS Mounts Smartmount D-FPT2-320 Installation And Assembly Manual

Installation and Assembly:
Smartmount
(94 - 152 cm) LCD and Plasma Flat Panel Screens
Models: D-FPT2-320, D-FPT-320S,DFPT-420, DFPT-420S, ST660, ST660-S, ST660P,
ST660P-S, RTFPT2-320, RTFPT2-320I, RTFPT2-320S, RTFPT2-320SI,
SWS420/BK, SWS420/SI
Features:
• Screen held only 2.6" (66 mm) from wall for a discreet installation
• Open wall plate design allows for additional wall access, increasing
electrical access and cable management options
• Universal screen mounting brackets hook onto the wall plate for quick, easy,
and safe installation
• Adjustable up to 15° of forward tilt and up to -5° backward tilt
• One-touch tilt for effortless adjustment
• Pre-tensioned universal tilt bracket allows for tilt angle adjustment in one
easy motion.
• Easy grip handle locks the screens position into place
• Optional IncreLok feature offers fixed tilts at -5°, 0°, 5°, 10° and 15°
increments
• Includes Sorted-For-You™ fastener pack for installation to wood studs,
concrete and cinder block
• Optional horizontal adjustment of up to 8" (203 mm) (depending on screen
model) for perfect screen placement
• Available in Black and Silver
®
Universal Tilt Wall Mount for 37" - 60"
1 of 18
U L
C US
©
Max Load Capacity: 200 lb (91kg)
ISSUED: 03-25-09 SHEET #: 202-9332-1
