PD-LED2052 Microwave Sensor Lamp Instruction
Packing list in
Microwave Sensor Lamp
Φ6
Plastic Expansion
3x30 Screw
Instruction
Name of each part
Microwave sensor
Mounting holes
Threading hole
Lamps and lanterns base
Specifications
Power source: 220-240VAC
Power frequency: 50/60Hz
Rated load: 15W Max.
HF system: 5.8GHz CW electric wave,
ISM wave band
Transmission power: <0.2mW
Time setting: 12s-12min (adjustable)
Light-control: 10LUX-2000LUX (adjustable)
Summary
Quantity
This is a microwave sensor switches controlled LED lights,the microwave sensor was
1X
built into the light ,it has 30pcs high brightness LEDs inside ,with total power of 15 watts.
We adopt this sensitive advanced sensor switchs in lighting control, enabling the light to
3X
turn on automatically when one comes , automatically turn off when one goes out. In
addition to the widely usage in the aisle stairs ,living room and bedrooms , it also can be
3X
installed in the bathroom.
1X
Use high quality White frosted glass chimney.Strengthen the
flexible refraction of light.And its function of anti-ultraviolet
makes the shade not easy to turn yellow and be broken.
Mounting holes
Mounting holes
Unscrew
Detection range: 2-5m(radii.) (adjustable)
Dim time:0s-
Detection angle: 360°
Standby power: < 0.5W
Installation height: 2.5-3.5m (ceiling mount)
Lamp part
LED quantity: 30PCS
LED specifications: 2835
100mm
280mm
White frosted glass chimney
∞
(adjustable)
Advertisement
Related Manuals for pdlux PD-LED2052
Summary of Contents for pdlux PD-LED2052
- Page 1 PD-LED2052 Microwave Sensor Lamp Instruction 100mm 280mm Summary Packing list in Quantity This is a microwave sensor switches controlled LED lights,the microwave sensor was Microwave Sensor Lamp built into the light ,it has 30pcs high brightness LEDs inside ,with total power of 15 watts.
- Page 2 Sensor information 360º Max:5m Max:5m Min:2m Min:2m Height of installation2.5~3.5M Sensing distance adjustment range Sensing angle adjustment range Function Setting manner :potentiometer It may take times to adjust values before they satisfy your need. SENS TIME TIME (1)Detection range setting (sensitivity) Detection range is the term used to describe the radii of the more or less circular detection zone produced on the ground after mounting the sensor light at a height of 2.5m, turn the reach control fully anticlockwise to select minimum reach (approx.2m radii), and fully...
- Page 3 Friendly reminder: when installing two or more microwaves together, you are required to keep 4 meters one from another, otherwise the interference among them will lead to error reaction. • A built-in light sensor to detect the day and night, if can't install the lamp in the natural light environment, the photo will be failure , a direct result of the days are easy to induction lights, lead to unnecessary energy waste.
- Page 4 Warning! The following situations will lead to error reaction. 1、Being installed on the rocking object will lead to error reaction. 2、The shaking curtain blown by wind will lead to error reaction. Please select the suitable place to install. 3、Being installed where the traffic is busy will lead to error reaction. 4、The sparks produced by some equipment nearby will lead to error reaction.
