pdlux PD-LED131-D Instructions

Microwave Sensor Light
PD-LED131-D
Product size
250mm
Summary
This is a new concept design of intelligent wall
installation series LED microwave induction lamp,
additional power failure standby battery power supply
lighting function. The lighting part is automatically
managed by a dual system of municipal power supply
and standby battery power supply. When the power
supply of the power network is interrupted, the
self-provided battery of the system will automatically
assume the follow-up power supply and provide 5W
power to the induction lamp system. The power supply
of the standby battery can last for more than 1 hour and
can also be adjusted according to the customer's
demand. However, the duration of the standby battery
storage is inversely proportional to the brightness. This
product can be widely used in corridors, toilets,
elevator
application Spaces.
The product comes in two configurations: an induction
lamp with dual AC/DC systems for emergency
management; One is a smart sensor lamp without
emergency functions. Customers can choose the
configuration according to their needs. It is necessary
to choose
circumstances. Occasional power outages without
lighting can cause a lot of trouble and even danger, so
this product with emergency lights is a wise choice.
The shell of the product adopts aluminum alloy body,
frosted baking process, and other parts adopt PC
anti-ultraviolet engineering plastics, which greatly
enhances the service life of the product.
Use high quality PC lampshade.Strengthen the flexible
103mm
refraction of light.And its function of anti-ultraviolet makes
the shade not easy to turn yellow and be broken.
LED lamp consumes power 80% less than incandescent
lamp and 50% less than fluorescent lamp.
135mm
Specifications
Power source: 220-240VAC, 50/60Hz
Rated LED: 8W/16W Max.(AC) 5W Max.(DC)
Charging power: 5W Max.
HF system: 5.8GHz
Battery: 3.7V / 1800mAH lithium battery(18650)
Continuous illumination time: ≥60min
Transmission power: <0.2mW
Detection angle: 180°
Time setting: 10sec to 12min (adjustable)
Detection range(22℃): 1-5m (radii.) (adjustable)
Light-control: <10-2000LUX(adjustable)
Installation height: 1.5-3m
entrances and other energy-saving
emergency lights under
LED quantity: 72PCS(2835)
Working temperature: -20~+55℃
Operating Temperature: -10 - +40°C
Probe movement speed: 0.6-1.5m/s
relative Humidity: <93%RH
Static power consumption:＜0.5W
Name of each part
Upper part of the light
most
1 2 3 4 5
The lower part of the light
Battery capacity high,
medium and low indicator
Induction information
Height of installation1.5~3m Detection range（22℃）
Parameter setup Method: potentiometer
The following settings may require multiple adjustments
to meet your requirements.
Aluminium Alloy
1. Sensitivity setting
2. Delay setting
3. Light control settings
4. Low brightness exit
time setting
5. 8W/16W machine
power switch button
180°
5m
Detection angle
