pdlux PD-LED2038 Instruction Manual

PD-LED2038 Microwave Sensor Light Instruction
Packing list in
Quantity
Microwave Sensor Lamp
1X
4X
Φ6 Plastic Expansion
4X
3x30 Screw
1X
Instruction
IP 44
The built-in microwave sensor switch can penetrate plastic, glass, wood . So it can be installed in glass or plastic shell lamp
This allows the application of microwave sensor switch in different styles of lights for energy control. Now, we can provide
a variety of microwave sensor LED lamps to meet the needs of different people with different preferences.
This lamp is designed with several collocations, namely, the pure LED lamp without sensor; the automatic LED lamp with
sensor; the automatic LED lamp with battery backup that is the Emergency Function(PD-LED2038-D).
Use high quality PC lampshade.Strengthen the flexible refraction
of light.And its function of anti-ultraviolet makes the shade not
easy to turn yellow and be broken.
Name of each part
Specifications
Power source: 220-240V/AC 50/60Hz
Rated LED: 26W Max.
HF system: 5.8GHz
Transmission power: <0.2mW
Time setting: 8sec to 12min (adjustable)
Detection range: 1-8m (radii.) (adjustable)
Summary
This is a microwave sensor switches controlled LED lights,the microwave sensor was built
into the lamp ,it has 96pcs high brightness LEDs inside ,with total power of 26 watts. The
microwave sensor switch is a new type automatic switch that comes after voice switch ,and
infrared sensor switch .The detection way has the below advantages compared with other
as follows: 1. non-contact detection, 2. Suitable for bad environment, immune to
temperature, humidity, noise, air, dust, light...3.RF interference ability, 4.
power only 0.2 mW, It will not harm the human body. Simple installation+ easy wiring.
We adopt this sensitive advanced sensor switchs in lighting control, enabling the light to
turn on automatically when one comes , automatically turn off when one goes out In
addition to the widely usage in the aisle stairs ,living room and bedrooms , it also can be
installed in the bathroom.
LED lamp consumes power 80% less
than incandescent lamp and 50% less
than fluorescent lamp.
Lampshade
Light-control: 10-2000LUX(adjustable)
Detection angle: 360°
Installation height: 2.5-3.5m (ceiling mount)
Working Temperature:-20~+55℃
LED quantity: 96PCS
LED specifications: FM-3528WNS
Transmission
