Summary of Contents for German pool GPU-6.5E-V
- Page 1 GPU-6.5E/10E-V Central Storage Electric Water Heater GPU-6.5HE/10HE-V Online Warranty Registration Please read these instructions and warranty information carefully before use and keep them handy for future reference. U S E R M A N U A L...
- Page 2 請即進行保用登記！ 有關保用條款細則，請看說明書最後一頁。 Please register your warranty information now ! For Warranty Terms & Conditions, please refer to the last page of this user manual.
- Page 3 目錄 Table of Contents 警告事項 Warnings 產品特點 Features 產品結構 Product Structure 安裝說明 Installation Instructions 使用說明 Operating Instructions 安裝圖 Installation Diagram 電路圖 Wiring Diagram 產品規格 保用條款 Warranty Terms & Conditions...
- Page 4 30mA. 護裝置的額定動作電流應不大於30mA。 Warning 警告 Please install water heater in accordance to the 若用戶需要安裝任何非隨機配件，必須先與 instructions stated on this booklet. German Pool 本公司認可之技術人員聯絡，否則本公司將 will NOT provide warranty service on any product 有權拒絕提供任何保養服務。 installed with unauthorized components or devices.
- Page 5 * Under normal working conditions, incoming pressure should not exceed 0.6 MPa. Otherwise, a separate pressure control device is necessary. When incoming water pressure exceeds 0.6 MPa, German Pool will not provide any repair service until a pressure control device is installed.
- Page 6 產品結構 Product Structure GPU-6.5E/10E-V 1 防倒流裝置 2 超溫及超壓排放閥 3 發熱線（內部） 4 出水位（熱） 5 排水管 6 入水位（冷） 7 溫度調節/超溫斷路器 Anti Back Siphonage Device Pressure & Temperature Relief Valve (PTV) Heating Element (Inside) Outlet (Hot) Drain Inlet (Cold) Combined Thermostat/Cut-Out GPU-6.5HE/10HE-V 1 防倒流裝置 2 超溫及超壓排放閥...
- Page 7 安裝說明 Installation Instructions Pre-Installation Notice 安裝前注意 Installation should be done by a licensed 安裝必須使用原廠配件。若不按指示方法安 technician using the supplied parts. German Pool 裝及使用而引致任何損壞，本公司概不負責。 is not responsible for any defect or damage 安裝工作應由專業持牌水電技術人員負責。 caused by incorrect or unauthorized installation.
- Page 8 安裝說明 Installation Instructions 接電方法 Electric Wiring Use an independent wire (refer to table below) 由電箱獨立伸延一條適合之電線(見下表)至浴室 leading from the meter box and connect it to an 門外接駁獨立開關掣，再將電線伸延至熱水器 independent on/off switch outside bathroom. 穿進灰色線夾接到電線排上分別接上零線(N)， Extend the wire through the grey wire grip on the 火線(L)，及地線( )等。...
- Page 9 及更換。對於因未考慮維修及更換因素， repair and replacement. If water heater 而造成後期維修及更換熱水器時產生其他 is installed in a location not easily accessible, German Pool will not be 附屬非熱水器損失，本公司概不負責。 held responsible for any damage or loss, peripheral or otherwise, incurred during reparation and replacement.
- Page 10 使用說明 Operating Instructions 預留維修位置 Min. space for maintenance 注：發熱管 3kW NOTE: Heating element 3kW P.10...
- Page 11 使用說明 Operating Instructions P.11...
- Page 12 排水 排水 Drain Drain 出水 排水 安裝圖 Installation Diagram 進水 進水 Outlet Drain Inlet Inlet 出水 Outlet 外碼 Mounting 熱水器 Bracket Water Heater 溫度調節/ 超溫斷路器 Thermostat/ Cut-Out 排水 進水 Drain Inlet 出水 進水 出水 Outlet Inlet Outlet P.12...
- Page 13 電路圖 Wiring Diagram 溫度調節/超溫斷路器 Combined Thermostat/Cut-Out P.13...
- Page 14 產品規格 型號 Model GPU-6.5E-V GPU-10E-V GPU-6.5HE-V GPU-10HE-V 電壓 Voltage (單相 / 1Phase) 220 V 220 V 220 V 220 V 頻率 Frequency 50 Hz 50 Hz 50 Hz 50 Hz 功率 Power (單相 / 1Phase) 容量 Capacity 25 L 40 L...
- Page 15 保用條款 Warranty Terms & Conditions Under normal operations, the product will gurantee a 1-year full 此保用提供德國寶產品之機件在正常使用下壹年保 warranty provided by German Pool (effective from the date of purchase). 用(自購買日起計算)。 This warranty is not valid until customer registration information is *貴戶須在購機十天內，以下列其中一種方式向本公司 received by our Service Centre within 10 days of purchase via 登記資料，保用手續方正式生效﹕...
- Page 16 Fax:+86 757 2219 6809 HONG K ONG TOP BRAND TEN YEAR ACHIEVEMENT AWARD © All rights reserved. Copying, reproducing or using the contents of this manual is not allowed without prior authorization from German Pool, violators will be prosecuted. www.germanpool.com GPU-6.5E-10E-6.5HE-10HE-V-M-24(1)
