Max Trainer M6: My machine is seized, why won't it move?
Follow this troubleshooting guide to help resolve issues involving a seized-up Max Trainer M6.
Some common complaints may include:
Pedals are stuck and won't move
Fan making contact with the motor or frame
Jammed upper or lower belts
Pedals are stuck and won't move
Tools you may need:
Phillips head screwdriver
5mm, 6mm hex/Allen wrenches, or Allen wrenches from the
hardware card included with your machine
14mm socket wrench
Crank puller (if removing crank arms for troubleshooting)
Flashlight
1.
Check that the crank arms are opposite each other 180 degrees (reference 1). If the crank arms are not inline and
opposite each other, reorient the crank arms following the "Replace the Crank Arms" section of the
[11207.A]
manual
2.
Check if the crank arms can be rotated by hand. Applying weight to the raised foot pedal can help with pedals that
have bottomed out
3.
Remove the lower right fan shroud. Watch the video below or follow the instructions starting in the next step.
about:blank
Max Trainer M6:  My machine is seized, why won't it move?
.
Diagram showing how the crank arms should be oriented when properly installed.
[11207.B]
.
(Reference 1)
