Max Trainer M9: Why isn't my speed reading properly?
Follow this troubleshooting guide to help resolve speed issues on the Max Trainer M9.
Some common complaints may include:
Machine goes to sleep while in use
Speed is not registering or not registering properly
Burn Rate Targets in JRNY are maxed out and barely visible
Contents:
Check for updates
Check cable connections:
Behind the console
Bottom of the console mast
Speed sensor and speed sensor cable
Check for updates
Follow the instructions
1.
Once all applicable updates are installed, start a workout and test if the issue
2.
Inspect the cable connections behind the console
Tools you may need:
Phillips head screwdriver
Access the connection
Important: Unplug your machine from power before continuing
1.
Remove the rear console cover from the back side of the console.
2.
Use a Phillips head screwdriver to loosen and remove the four screws on each corner of
the console mounting plate.
3.
Carefully tilt and lift the console to expose the cable connections.
Check the cables
1.
Three cables run from the console through the console mast (one 3-pin, 5-pin, and 14-pin cable).
2.
Unplug all connections behind the console. Check the following items while reconnecting the cables:
Damage - If damaged (cut, crimped, frayed wires, or loose/damaged connectors),
Cables [11766.A]
about:blank
Max Trainer M9:  Why isn't my speed reading properly?
in JRNY Basic App Troubleshooting to check for and install any available updates
persists [FW.A]
order Mid-Mast
