INSTRUCTION MANUAL
For Z2450-Z Zoom Gear for
Nikkor Z 24-50mm f/4-6.3
PN# 19201
FOREWORD
Thank you for your purchase of a NAUTICAM
product.
At NAUTICAM, we pride ourselves in the ability
to recognize the requirements of professional as
well as amateur underwater photographers and
fulfill them through the innovative designs of our
products. We strive to achieve a high level of
user-friendliness
by
installation and easy operation of all important
functions of the camera.
Each product is individually inspected and water
pressure tested to ensure optimum quality.
Please read this manual carefully before using
the product, this will maximize its performance as
well as its lifetime.
allowing
stress-free
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Nauticam Z2450-Z
Summary of Contents for Nauticam Z2450-Z
- Page 1 For Z2450-Z Zoom Gear for Nikkor Z 24-50mm f/4-6.3 PN# 19201 FOREWORD Thank you for your purchase of a NAUTICAM product. At NAUTICAM, we pride ourselves in the ability to recognize the requirements of professional as well as amateur underwater photographers and fulfill them through the innovative designs of our products.
- Page 2 Protect the interior from moisture with and/or placed within our products. and debris in order to prevent malfunction or NAUTICAM accepts no liability for any loss of leakage. captured images or the inability to capture images even if it is due to the malfunctioning of Defective products should be shipped to our our products.
- Page 3 PACKAGE CONTENTS • Make sure that you have all the included items listed below before using this product. • If some items are missing or damaged, contact us and the local Nauticam dealer. Plastic C-ring for Zoom Gear Z2450-Z Zoom Gear...
- Page 4 IDENTIFICATION OF PARTS Plastic C-ring for Zoom Gear Z2450-Z Zoom Gear Preparation of the product 1. After verifying that the sealing O-ring is in good condition, lightly coat it with the lubricant provided and wipe away the excess. 2. Make sure the O-ring groove is free from any foreign material; the groove can be cleaned with the aid of a microfiber cloth.
- Page 5 MOUNT THE GEARS 1. The default position is for directly working 3. Extend the lens gear to the right position with other Z mount housings except NA- to work with different Z mount housings. Z6III. 2. By loosen the three screws, the gear can be extended to work with NA-Z6III housing as marked on the gear.
- Page 6 CONTROL THE GEAR (FOR NA-Z6III) The extended Z2450-Z Zoom Gear is controlled by zoom/focus knob of the NA- Z6III housing. (FOR OTHER Z- MOUNT CAMERA HOUSING) The short version Z2450-Z Zoom Gear is controlled by zoom/focus knob of the other Z mount camera housings, such as NA-Z8/9/7.
- Page 7 SPECIFICATIONS #19201 Z2450-Z Zoom Gear for Nikkor Z 24- 50mm f/4-6.3 Dimensions(mm): DIA102.0X41.60 Type: Zoom Gear Compatible Lens: Nikkor Z 24-50mm f/4-6.3 Remark: Nauticam supports only e-manuals. Please download corresponding product manuals on google drive https://bit.ly/Nauticammanual, or contact us for e-...
- Page 8 A damaged O- ring should be discarded immediately and replaced only with one that is provided by NAUTICAM. • Blow off dust with an air blower or clean antistatic brushes from optical surfaces. • Remove dust and other foreign matter from the dome port cover/cap before attaching them.
