Summary of Contents for Nauticam NA-Z50
-
Page 1: Table Of Contents
NA - Z50 For Nikon Z50 Camera PN 17224 User Manual Housing APS-C-MIL Introduction Package Contents Important Instructions Part Names and Functions Opening the housing Closing the housing Preparation for Use Care/Storage Warranty Specifications... -
Page 2: Introduction
PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. NA-Z50 Padded Travel Case... -
Page 3: Important Instructions
O-ring renewal between the atmosphere and inside the and port change. housing. Only the accesories specified by Use only Nauticam lubricant on silicone Nauticam must be used. Third-party rubber O-ring. accessories may result in malfunctions or damage to the product. -
Page 4: Part Names And Functions
PART NAMES AND FUNCTIONS Rear View Monitor mode button Housing unlock button Multi selector button Menu button Delete button Moisture alarm window Display button Zoom out Zoom in OK button... - Page 5 PART NAMES AND FUNCTIONS Top + Front Views M16 Accessory port Optical cable connector Flash on/off lever Main switch +/- button Photo/movie lever M16 accessory port Main command dial Mode dial Accessory mounting ball Port lock safety button Port locking lever Port index mark Z mount lens release button F mount lens release button...
- Page 6 PART NAMES AND FUNCTIONS Back + Side Views Zinc Anodes 1/4” Threaded tripod holes Playback lever Zoom/Focus dial AE-L/AF-L lever Shutter release lever ISO lever REC lever Sub-command dial...
-
Page 7: Opening The Housing
OPENING THE HOUSING * drawings as illustrations only depress housing unlock button turn housing lock outward lift up the back housing... -
Page 8: Closing The Housing
CLOSING THE HOUSING Housing Lock - Lock before closing the housing, clean and lubricate the main O-ring make sure nothing is caught between front and back housing and that they are fully aligned before locking turn housing lock inward until you hear and feel it click into place housing lockd in place securely... -
Page 9: Preparation For Use
PREPARATION FOR USE Installing the Camera - housing tray attachment unlock camera tray lever and remove the tray from the housing attach the camera tray by tightening the tray screw into the tripod socket of the camera * lift up the Photo/movie lever each time before installing the camera, also pull out the zoom/focus knob if installing the camera with lens and... - Page 10 F mount lens installment Installing the Camera - FTZ adaptor Please replace tripod socket cover of Nikon FTZ Adaptor by Nauticam #25220 Tripod socket replacement cover when using F mount DX/FX lenses with N120 F mount port system.
- Page 11 PREPARATION FOR USE Port Mounting depress safety button and rotate anti-clockwise lubricant the port O-ring before mounting align index mark push port assembly straight in rotate locking lever clockwise to lock...
- Page 12 PREPARATION FOR USE Coating housing O-ring Main O-ring remove the main O-ring using an O-ring remover clean the O-ring groove with a cloth and ensure that it is free from salt or other foreign materials lightly coat it with provided lubricant return the main O-ring by slowly pressing from one corner to the whole perimeter...
- Page 13 PREPARATION FOR USE Setting up moisture alarm CR2032 Battery Alarm ON/OFF remove battery press the battery down until it insulation film click into place switch on the alarm test the alarm - the moisture alarm - connect the wires with a window will flash in dampened cotton bud;...
-
Page 14: Care/Storage
CARE/STORAGE Soak the housing system in fresh water Operate all controls and buttons at after salt water usage least 3 times while immersed in fresh water We recommand cleaning and inspecting Protect the housing with robust and the main O-ring each time after diving for shock-proof travel case during trans- any damage and every time the housing portation. -
Page 15: Warranty
NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/or poor maintenance; it is the responsibility of the own- er to carefully follow the instructions in our manuals. -
Page 16: Specifications
SPECIFICATIONS Construction Wet Lens Compatibility 81301 Compact macro convertor 1 Housing body Hard Anodized Aluminium Alloy Macro (CMC-1, 4.5x magnification) Display window Abrasion Resistant Polycarbonate 81302 Compact macro convertor 2 (CMC-2, 2.8x magnification) Dimensions Wideangle 83201 Wet wide lens 1 (WWL-1) 130⁰... - Page 17 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
