Nauticam 19200 Z105-F Focus Gear Instruction Manual

For n120 gear system for nikon z mount (without ftz adaptor 22225)

Advertisement

Quick Links

Current as of 10/29/2024
INSTRUCTION MANUAL
For N120 Gear System for Nikon
Z Mount (without FTZ adaptor
22225)
PN#
19200 Z105-F Focus Gear
19202 Z1424-Z Zoom Gear
19203 Z1430-Z Zoom Gear
FOREWORD
Thank you for your purchase of a NAUTICAM
product.
At NAUTICAM, we pride ourselves in the ability
to recognize the requirements of professional as
well as amateur underwater photographers and
fulfill them through the innovative designs of our
products. We strive to achieve a high level of
user-friendliness
by
installation and easy operation of all important
functions of the camera.
Each product is individually inspected and water
pressure tested to ensure optimum quality.
Please read this manual carefully before using
the product, this will maximize its performance as
well as its lifetime.
allowing
stress-free

Advertisement

loading
Need help?

Need help?

Do you have a question about the 19200 Z105-F Focus Gear and is the answer not in the manual?

Questions and answers

Summary of Contents for Nauticam 19200 Z105-F Focus Gear

  • Page 1 19200 Z105-F Focus Gear 19202 Z1424-Z Zoom Gear 19203 Z1430-Z Zoom Gear FOREWORD Thank you for your purchase of a NAUTICAM product. At NAUTICAM, we pride ourselves in the ability to recognize the requirements of professional as well as amateur underwater photographers and fulfill them through the innovative designs of our products.
  • Page 2 Protect the interior from moisture with and/or placed within our products. and debris in order to prevent malfunction or NAUTICAM accepts no liability for any loss of leakage. captured images or the inability to capture images even if it is due to the malfunctioning of Defective products should be shipped to our our products.
  • Page 3 PACKAGE CONTENTS • Make sure that you have all the included items listed below before using this product. • If some items are missing or damaged, contact us and the local Nauticam dealer. #19200 Z105-F Focus Gear: Plastic C-ring for Focus Gear Z105-F Focus Gear #19202 Z1424-Z Zoom Gear :...
  • Page 4 IDENTIFICATION OF PARTS Take Z105-F Focus Gear for Example : Plastic C-ring for Focus Gear Z105-F Focus Gear Preparation of the product 1. After verifying that the sealing O-ring is in good condition, lightly coat it with the lubricant provided and wipe away the excess. 2.
  • Page 5 MOUNT THE GEARS 3. Extend the lens gear to the right position 1. The default position is for directly working to work with different Z mount housings. with other Z mount housings except NA- Z6III. 2. By loosen the three screws, the gear can be extended to work with NA-Z6III housing as marked on the gear.
  • Page 6 CONTROL THE GEAR (FOR NA-Z6III) The extended Z105-F Focus Gear is controlled by zoom/focus knob of the NA-Z6III housing. (FOR OTHER Z- MOUNT CAMERA HOUSING) The short version Z105-F Focus Gear is controlled by zoom/focus knob of the other Z mount camera housings, such as NA-Z8/9/7. After mount the camera and lens gear, confirm that the zoom/focus knob operates correctly.
  • Page 7 #19203 Z1430-Z Zoom Gear for Nikkor 14- 30mm f4 S Dimensions(mm): DIA102x44.1 Type: Zoom Gear Compatible Lens: Nikkor 14-30mm f4 S Remark: Nauticam supports only e-manuals. Please download corresponding product manuals on google drive https://bit.ly/Nauticammanual, or contact us for e- manuals.
  • Page 8 A damaged O- ring should be discarded immediately and replaced only with one that is provided by NAUTICAM. • Blow off dust with an air blower or clean antistatic brushes from optical surfaces. • Remove dust and other foreign matter from the dome port cover/cap before attaching them.
