NA - Z6III

August, 2024

For Nikon Z6III Camera

PN 17230

User Manual

Housing

FF- MIL

Need help?

Do you have a question about the NA-Z6III and is the answer not in the manual?

Questions and answers

Summary of Contents for Nauticam NA-Z6III

Page 1 August, 2024 NA - Z6III For Nikon Z6III Camera PN 17230 User Manual Housing FF- MIL Introduction Package Contents Important Instructions Part Names and Functions Housing Mount Opening the housing Closing the housing Preparation for Use Optional Accessories Care/Storage Warranty Specifications...
Page 2 PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. NA-Z6III Padded Travel Case...
Page 3 O-ring renewal between the atmosphere and inside the and port change. housing. Only the accesories specified by Use only Nauticam lubricant on silicone Nauticam must be used. Third-party rubber O-ring. accessories may result in malfunctions or damage to the product.
Page 4 PART NAMES AND FUNCTIONS Rear View Viewfinder Monitor mode lever Release mode/Protect button Delete button Photo/Video lever DISP button Playback zoom in button Multi-selector Playback zoom out/thumbnails button Moisture alarm window Menu button button AE-L/AF-L button Menu/Set button...
Page 5 PART NAMES AND FUNCTIONS Top + Front Views M24 Accessory port Optical fiber cable connection M10 Accessory port Mode dial Main switch M16 Accessory port Exposure compensation button ISO button M16 Accessory port Main command dial Accessory mounting ball Port lock safety button Port locking lever Port index mark Lens release button...
Page 6 PART NAMES AND FUNCTIONS Back + Side Views 1/4” Threaded tripod holes Sacrificial zinc anodes M5 Threaded holes Playback lever Zoom/Focus knob release Zoom/Focus knob AF-ON lever Movie record lever Shutter release lever Sub-command dial...
Page 7 HOUSING MOUNT Housing mount Compatible accessories M16 Accessory port 25625 M16 Vacuum valve II (pushbutton release) M16 Accessory port 25019 M16 to M14 step down adaptor for electrical bulkhead Electrical 25013 M14 Nikonos 5-pin bulkhead with hotshoe connection triggering M10 Accessory port 25221 M10 Strobe mounting ball 25224...
Page 8 OPENING THE HOUSING * drawings as illustrations only depress housing unlock button turn housing lock latch anti-clockwise to open the housing flip open the back housing when lock latch is aligned to ‘open’ position...
Page 9 CLOSING THE HOUSING * drawings as illustrations only before closing the housing, clean and lubricate the main O-ring make sure nothing is caught between front and back housing and that they are fully aligned before locking main O-ring insert the housing shaft into the shaft hole and then rotate the lock latch clockwise until you hear and feel it click into place...
Page 10 PREPARATION FOR USE * drawings as illustrations only Installing the Camera - housing tray attachment unlock camera tray lever and remove the tray from the housing attach the camera tray by tightening the tray screw into the tripod socket of the camera place the actuator on the camera tray in place and make sure it is engaged with the camera...
Page 11 PREPARATION FOR USE * drawings as illustrations only Port Mounting depress safety button and rotate anti-clockwise lubricant the port O-ring before mounting align index mark push port assembly straight in rotate locking lever clockwise to lock Do not operate the red lever with force, make sure the port is aligned correctly and pushed in fully and securely...
Page 12 PREPARATION FOR USE * drawings as illustrations only Coating housing O-ring Main O-ring remove the main O-ring using an O-ring remover clean the O-ring groove with a cloth and ensure that it is free from salt or other foreign materials lightly coat it with provided lubricant return the main O-ring by slowly pressing from one corner to the whole perimeter...
Page 13 PREPARATION FOR USE * drawings as illustrations only Setting up moisture alarm Alarm ON/OFF CR2032 Battery remove battery press the battery down until it insulation film click into place switch on the alarm test the alarm - the moisture alarm - connect the wires with a window will flash in dampened cotton bud;...
Page 14 PREPARATION FOR USE * drawings as illustrations only Changing lens/port without opening the housing If using with vacuum valve : remove the cap from the vacuum valve and press the red button to release pressure before unlocking port lock If using without vacuum valve, please follow from step 2 unlock port lock and remove port assembly...
Page 15 PREPARATION FOR USE ISO & +/- value adjustments - Release button to use dial Please follow the below settings for easy adjustments of ISO & +/- value (without removing hands from handles) while using the housing : In the Custom Settings menu under f6/f7 (Release button to use dial), Select [ON].
Page 16 OPTIONAL ACCESSORIES * drawings as illustrations only Vacuum valve system remove the plug of M16 accessory port from the housing remove the cap from the vacuum valve hand pump slightly lubricate the o-ring and vacuum valve make sure the o-ring is in place accesory port then tighten the vacuum valve to on housing...
Page 17 OPTIONAL ACCESSORIES * drawings as illustrations only Installing Surface USB-PD Power Bank unscrew the M24 accessory port cap from the camera housing and screw the M24-M16 adaptor into M24-M16 Adaptor the housing port plug the USB-C Bulkhead into the accessory port, gently push the connection head into the accessory port until it cannot go further then tighten it by turning the locking nut...
Page 18 OPTIONAL ACCESSORIES * drawings as illustrations only Strobe Mounting Ball Installing M5 Strobe Mounting Ball - RECOMMENDED M5 screw remove M5 screw with the allen key provided in the screw #25228 M5 Strobe mounting ball directing onto housing package the M5 thread * the anti-corrosion screw may also be Anti-corrosion unscrewed while removing M5 screw, if this...
Page 19 OPTIONAL ACCESSORIES Installing Viewfinder firstly remove the pre-installed 0.66x viewfinder gently push the 0.66x viewfinder from the inside of from the housing by removing the retainer o-ring the housing inside rear housing remove the retainer o-ring from the viewfinder align the viewfinder alignment pins with the LCD lightly lubricate the retainer o-ring and place it back display window and push the viewfinder into the from inside the housing...
Page 20 CARE/STORAGE Soak the housing system in fresh water Operate all controls and buttons at after salt water usage least 3 times while immersed in fresh water We recommand cleaning and inspecting Protect the housing with robust and the main O-ring each time after diving for shock-proof travel case during trans- any damage and every time the housing portation.
Page 21 NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/or poor maintenance; it is the responsibility of the own- er to carefully follow the instructions in our manuals.
Page 22 * New version V2 gears are adjustable so that the gears can be used on both Z6III housing and other Z-mount housings 72233 Single Bayonet Holder II for Ø70 Float Arm * please refer to Nauticam port charts for more setup information. 72234 Double Bayonet Holder II for Ø70 Float Arm Port accessories 1 x M24, 2 x M16 ,1 x M10 72243 Single Bayonet Holder II for Ø90 Float Arm...
Page 23 WET LENS COMPATIBILITY * please refer to Nauticam port charts for more setup information Nauticam optical lenses Optional accessories Macro 81201 Super Macro Convertor 1 25101 M67 flip diopter holder for M67 macro ports 81202 Super Macro Convertor 2 25108 M67 Double Flip Holder for M67 Macro Ports Macro 87301 EMWL Set #1 (incl.
Page 24 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
