MAIDESITE T2 Pro, T2 Pro Plus Manual

Congratulations on completing the installation! Please refer to the control panel instructions to complete the initialization operation before use.

Install the Accessories

Install the Casters

1. Rotate counterclockwise to remove the caster.


2. Screw on the caster and finally lock it with a wrench.

3. To lock and unlock the caster by switching the brake on it


Instructions of Control Panel

Please ensure that no objects (walls) will interrupt the movement of the desk, and all cables of relevant devices are sufficiently long.

Please RESET the desk at the first time use

#1 RESET

1. Enter the RST mode:
   Hold the 'DOWN' key for 5s while the desktop is at the lowest position (otherwise lower the desktop first). The digital display shows 'RST'. Now the system enters RST mode.
2. Quit the RST mode:
   Hold the 'DOWN' key again until the desktop moves down slightly and then moves up slightly. The display shows the current height. The system quits RST mode.

The control panel must be fixed horizontally under the desktop before use. Please set the sensitivity of the Anti-collision function according to your usage habits.

The next parts can be set according to your preference.

Reset Exception Protection:

Condition
The digital display shows error E07/E08/E09 Disconnecting/Reconnect power, the error still remains. Pressing any key has no effect.

Operation
Hold the 'DOWN' key for 5s, the digital display shows RST. Release and hold the 'Down' key again to reset the desk. (Note: This operation is also applicable to forced reset. Please lower the desk to the lowest position first when forced reset.)

Memory Height Setting:

Touch the 'M' key, the display shows 'S-', Touch one number key from 1-4, the current height will be stored to that key. Press that key, your desk will move to the height automatically.

Set the upper limit:

Touch the 'M' key: the display shows'S-'.
Touch the 'UP' key: the display flashes.
Touch and hold the 'M' key for 2s until the display shows '999'. The upper limit is now stored.

Set the lower limit:

Touch the 'M' key: the display shows 'S-'.
Touch the 'DOWN' key: the display flashes.
Touch and hold the 'M' key for 2s until the display shows '000'.
The lower limit is now stored.

Delete height limits:

Touch the 'M' key: the display shows 'S-'.
Touch and hold the 'M' key for 2s until the display shows '555'.
Both upper and lower limits are deleted.

Change the RESET height:

Enter the RST mode (see instructions above).
Touch and hold the 'M' key for 5s: the display shows the reset height, and the screen flashes.
Touch and hold the 'UP' key or 'DOWN' key to change the value.
The display switches back to 'RST' if no operation is detected for 5s, indicating the change is successful.
Quit the RST mode (see instructions above).

Switch the movement mode of the memory height:

Enter the RST mode (see instruction above).
Touch and hold the '1' key for 5s, the display shows one of the following:
'10.1': One-touch movement (Default)
'10.2': Constant-touch movement.

Change height unit(cm/inch):

Enter the RST mode (see instruction above).
Touch and hold the '2' key for 5s, the display shows one of the following:
'10.3': height display in cm (Default),
'10.4': height display in inch

Child Lock:

Touch and hold the Child Lock key for 4s: the displays shows 'LOC', and all keys at front are locked.
Touch and hold the Child Lock key again for 4s to unlock.

Sit-stand Reminder:

First time use: The sit-stand reminder is active by default and the default time is 30 minutes.
Touch the 'ON/OFF' key to turn on or off the sit-stand reminder.
Touch the 'SET' key and then choose one of the reminder time.
Please make sure that the sit-stand reminder is ON before setting the time.
When the reminder time runs out, the hand control vibrates.
Touch any key to stop the vibration and turn off the reminder.
When the height of the desk is greater than 100 cm, the reminder will stop the timing and reset.
When the height of the desk is less than 100 cm, the timing will restart.
Note: When there is no action, the reminder will be turned off after about 30 seconds of vibration

USB Charging port:

Output: DC 5V/0.8A

Q & A

Safety & Warnings

Warm prompt

Make sure no obstacles are in the desk's path. Make sure the desktop is not touching any walls. Make sure all cords are appropriate length to accommodate the change in height.

Keep children away from electric height-adjustable desks, control units and handsets. There is a risk of injury and electric shock.

Keep all electrical components away from liquids.

Do not sit or stand on the desk frame. Do not crawl or lie under the desk frame.

Do not place any objects taller than 20" underneath the desk. Do not open any of the components - the Legs, Control Box, or Switch. There is a danger of electric shock.

This product is designed with a duty cycle of 10% (2 min. on, 18 min. off).

In the event of a power outage or if the power cord is unplugged, a manual reset may be necessary - see USE section.

Pinch Point Keep hands and fingers clear.

USE/ LIABILITY

• This height adjustable desk has electric motors and is designed for use in dry work areas only.
• The desk height is adjustable so that it can be positioned at the most ergonomically suitable height.
• Any other use is at user's risk.
• Under no circumstances does the manufacturer accept warranty claims or liability claims for damages caused from improper use or handling of the desk frame.

Documents / Resources

Download manual

Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.

Download MAIDESITE T2 Pro, T2 Pro Plus Manual
