LateralX LX3: Why is the resistance not changing when adjusted?
Follow this troubleshooting guide to help resolve resistance issues on the BowFlex LateralX LX3.
Some common complaints may include:
Resistance is too low/high
Machine is too difficult/easy to use
Resistance does not change when adjusted
Resistance controls are not working
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
Flathead screwdriver
6mm, 10mm hex/Allen wrench, or the wrench from the
hardware card included with your machine
Lateral link puller (if removing lateral links for
troubleshooting)
1.
Unplug your machine from power, wait a few moments, then plug it back in. Test if the resistance
changes [13291.A]. If the resistance does not change, turn up the volume on the console and start a workou
program. Press the resistance buttons on the console and listen to whether the console beeps. If the console
beeps, skip to Step 3.
2.
If the console does not beep, inspect the cables to the console. Unplug your machine from power, remove
the console mast end cap, and inspect the cables inside for damage (reference 1). One at a time, disconnect
the cables and inspect the connectors and visible cables for damage.
reconnect them, ensuring the connectors are oriented in the proper direction. The tabs should line up and
click into place once secured. Test to see if the issue persists [13291.B]. If the cables coming from the console
are damaged, order a
Static Handlebar
cables, order a Static Handlebar
about:blank
LateralX LX3:  Why is the resistance not changing when adjusted?
Console [13291.C]. If the cables coming from the handlebar are damaged,
[13291.D]. If the cables are not damaged and the issue persists after reconnecting the
[13291.E].
(Reference 1)
If the cables are undamaged, firmly
ID: 13291.1
order a
