LateralX LX5+: Why doesn't the console turn on all the way?
Follow this troubleshooting guide to help resolve issues with the console partially turning on on the BowFlex LateralX
LX5+.
Some common complaints may include:
Console partially lights up
Console only turns on part way
Console does not light up all the way
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver (if removing console from
mast)
1.
If the console does not turn on at all, please visit
console? to continue troubleshooting.
2.
If you did not remove the protective film over the console display during the assembly process, please do so
now. Test to see if the issue is resolved [13299.A].
3.
If the issue persists, disconnect power to your machine and inspect the connections at the console. Remove
the console mast end cap and inspect the cables inside (reference 1). One at a time, disconnect the cables
and inspect the connectors and visible cables for damage. If they are undamaged, firmly reconnect them,
ensuring the connectors are oriented in the proper direction. Test to see if the issue persists [13299.B]. If the
cables coming from the console side are
the mast are damaged,
about:blank
LateralX LX5+:  Why doesn't the console turn on all the way?
damaged, order Mast
order a Mast to Servo
(Reference 1)
LateralX LX5+: Why is there no power to my machine or
Cables [13299
Cable [13299 .D].
ID: 13299.1
.C]. If the cables coming from
