5/22/24, 1:45 PM
LateralX LX3:  Why aren't the buttons/controls working?
Follow this troubleshooting guide to help resolve issues with the buttons on the console and handlebars of the BowFlex
LateralX LX3.
Some common complaints may include:
Console buttons do not work
Handlebar buttons do not work
Buttons aren't responding
Buttons/controls not functioning
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver (if removing console from
mast)
1.
Test the buttons on the console. One at a time, press each button and test for its response. If any (or all) of
the buttons are not responding,
2.
If the console buttons are responding, press each button on the handlebars and test for a response. If the
buttons are not responding on the handlebars, remove the console mast end cap and locate the 6-pin cable
(reference 1). Unplug the connector and inspect for damage. If undamaged, firmly plug the connector ends
back together, ensuring they are oriented in the proper direction. The tabs on the connectors should line up
and make an audible click once secured. Once secured, test to see if the buttons work [13259.B]. If the cable
coming from the handlebar is damaged,
mast is damaged,
about:blank
LateralX LX3:  Why aren't the buttons/controls working?
order a
Console [13259.A].
order a Static
order Mast
Cables [13259.D].
Handlebar [13259.C]. If the cable coming from the
(Reference 1)
ID: 13259.1
1/3
