LateralX LX3: Why is there no power to my machine or console?
Follow this troubleshooting guide to help resolve power issues on the BowFlex LateralX LX3.
Some common complaints may include:
Machine won't turn on
Console does not light up
Console does not turn on
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
6mm, 10mm hex/Allen wrench, or the wrench from the
hardware card included with your machine
24mm box wrench (or adjustable wrench)
17mm open-ended wrench
13mm socket wrench
Rubber mallet
1.
Unplug the power supply from your machine and the wall outlet. Inspect the length of the cord for damage
and make sure you are using the correct power adapter for your model - the LX3 uses a 9V, 1500mAh single-
piece adapter. If damage is present or your power cord does not match this specification,
Adapter [13247.A].
2.
Firmly plug your power cord back into your machine. Plug the opposite end of the cord into the wall outlet
and test if your machine powers on [13247.B].
3.
If the issue persists, test the wall power outlet that your machine uses with another device, such as a lamp, to
ensure it is working. If the power outlet does not provide power to the new device, try plugging your machin
into another outlet and powering on [13247.C].
4.
If the issue persists, disconnect power to your machine and inspect the connections at the console. Remove
the console mast end cap and inspect the cables inside (reference 1). One at a time, disconnect the cables
and inspect the connectors and visible cables for damage. If they are undamaged, firmly reconnect them,
ensuring the connectors are oriented in the proper direction. Test to see if the issue persists [13247.D]. If the
cables coming from the console side are
the mast are damaged,
about:blank
LateralX LX3:  Why is there no power to my machine or console?
damaged, order Mast
order a Mast to Servo
(Reference 1)
Cables [13247.E]. If the cables coming from
Cable [13247.F].
ID: 13247.1
order a Power
