- Page 1 The Stannah Lowriser USER HANDBOOK IMPORTANT Before using your Stannah Lift, please ensure you read and familiarise yourself with these instructions.
-
Page 2: Table Of Contents
The Stannah Lowriser User Handbook Contents Introduction Safety Precautions Standard Features Optional Features Operating Instructions 7-13 Emergency Lowering Manually Releasing the Ramp Manually Releasing the Upper Gate Manually Releasing the Twin Platform Gates Operating Difficulties/Faultfinding Emergency Breakdown Service Service and Inspection... -
Page 3: Introduction
The Stannah Lowriser User Handbook Introduction Thank you for buying this Lowriser Platform Lift. The instruction manual will help you become accustomed with your lift. • Study and become familiar with the step by step instructions. • Ensure a nominated person is also familiar with the instructions, especially with the operating procedures in the event of a breakdown. -
Page 4: Safety Precautions
The Stannah Lowriser User Handbook Safety Precautions • Children Children should be supervised when the lift is in use. Children should not be allowed to tamper or play with the lift. • Autohoming The lift Autohomes to the ground floor, approximately one minute after the threshold gate closes. -
Page 5: Standard Features
Standard Features Finish To complement this product the paint finish on the Lowriser range, is a high quality architectural powder coating. It is a highly durable, attractive finish with superb resistance to corrosion, heat, impact, abrasion and fading. The standard colour is Grey –White RAL. Beneath the paint finish, all steel parts are Nitro-Carburised. -
Page 6: Optional Features
The Stannah Lowriser User Handbook Optional Features Manual Self-Closing Gate Upper Gate The gate is self-closing with an electrical interlock and an electro-mechanical lock. 2-way Key Switching Key switches are available on either or both landing control stations. The lift controls can be switched on or off from either level. -
Page 7: Operating Instructions
The Stannah Lowriser User Handbook Operating Instructions Call Station Standard Controls Press and hold the top of the rocker switch to call or send the lift up. Press and hold the bottom of the rocker switch to call or send the lift down. - Page 8 The Stannah Lowriser User Handbook Operating Instructions In Car Standard Controls Down Direction Up Direction Emergency Stop Press and hold the LH side of the Press and hold the To stop the lift in the event of an rocker switch to send the lift down.
- Page 9 The Stannah Lowriser User Handbook Operating Instructions Lift Functions Entering The Lift at the Ground Floor With the lift at the ground floor the ramp will normally be in the lowered position. The ramp can be set to automatically fold up. To...
- Page 10 The Stannah Lowriser User Handbook Operating Instructions Lift Functions Exiting The Lift at the Ground Floor Enter the lift and position yourself centrally on the platform. Ensure the gate is fully closed and locked. To go down to the lower level, press and hold the down direction side of the rocker switch/down button.
-
Page 11: Emergency Lowering
The Stannah Lowriser User Handbook Operating Instructions Lift Functions Safety Features – Ramp Sensing If there is an obstruction beneath the ramp when it deploys, the ramp will stop. Press and hold the up direction side of the rocker switch/up button to raise the ramp and allow the obstruction to be cleared. -
Page 12: Manually Releasing The Ramp
The Stannah Lowriser User Handbook Operating Instructions Lift Functions Emergency Lowering Manual Lowering In the event of mains power and battery failure, the lift can be simply lowered to the ground floor. Ensure power to the lift is turned off, and the emergency stop button is pressed before executing this procedure. -
Page 13: Manually Releasing The Upper Gate
The Stannah Lowriser User Handbook Operating Instructions Lift Functions Manual Release Of Upper Level Gate WARNING! Ensure the lift is at the upper level before manually opening the gate. Remove the rubber grommet on the lock side of the gate frame. -
Page 14: Operating Difficulties/Faultfinding
The Stannah Lowriser User Handbook Operating Instructions Lift Functions Powered Gate (Optional) CAUTION! Ensure the area where the gate opens into is kept clear of obstructions at all times. Children must be kept away from the area of the gate and lift when in use. -
Page 15: Emergency Breakdown Service
The Stannah Lowriser User Handbook Operating Difficulties and Fault finding If you believe there is a problem please check the points below. If the problem cannot be rectified after carrying out the checks listed, switch off the unit at the mains electricity supply spur (adjacent to the lift), press the emergency stop button and contact your service company. -
Page 16: Service And Inspection
The Stannah Lowriser User Handbook Emergency Breakdown Service For information on breakdown cover and servicing please contact your service company. Service and Inspection Your Lifting Platform has been inspected and tested for quality and reliability. It should give you many years of trouble free operation. -
Page 17: Warranty
The Stannah Lowriser User Handbook Manufacturers Warranty The standard manufacturers warranty is 12 months. Parts Labour Planned Services Anti-Corrosion Supply only 12 mths See price list 60 mths Supply & Install 12 mths 12 mths See price list 60 mths Additional service and extended warranty packages are available upon request. -
Page 18: Manufacturer Information
The Stannah Lowriser User Handbook Manufacturer Information Model: Lowriser Lifting Platform Serial Number: Manufacturer: Stannah Lifts Ltd Address: Anton Mill Andover Hampshire SP10 2NX Telephone Number: 01264 339090 Fax Number: 01264 333050 E-Mail: liftsales@stannah.co.uk Website: www.stannahlifts.co.uk 220811/L:\Tech documents\Lowriser\Lowriser user manual 220811.doc Lowriser user Manual1 (stannah).doc...
