- Page 1 Stratum Homelift User Manual ENG Original instructions...
-
Page 3: Table Of Contents
CONTENTS Description General Dos and Don’ts Controls and Operation Smoke Alarms Emergency Procedures Fault Finding Changing Call Station Batteries Lift Disassembly / Safe Disposal of Hazardous Materials Service History Record Declaration of Conformity Lift Specification... -
Page 4: Description
DESCRIPTION The Stratum Homelift is an inter floor lift that is designed for use by persons with impaired mobility travelling between fixed floor levels in private dwellings. With a maximum carrying capacity of one person, with or without a wheelchair (or 250kg), this lift is not intended for use as a means of transporting goods. -
Page 5: General Dos And Don'ts
GENERAL DOS AND DON’TS • Never switch off the power supply to the lift, even when you go away. The lift control circuits are fed by a battery, which must be kept on constant charge. • The lift should always be returned to the lower level when not in use. - Page 6 • Users with wheelchairs should apply the brakes on their chair and all other users should ensure they are using the seat provided before moving the lift. Do not travel in the lift unless seated. • Safety related components should only be adjusted and reset by a competent person.
-
Page 7: Controls And Operation
CONTROLS AND OPERATION There are two wall mounted call stations, one at each level (Figure 2) and a similar control station fitted in the lift car. The lift can be isolated by using the optional remote isolate fob (Figure 3). When the lift is isolated, none of the control stations will function. - Page 8 General operation Call the lift by pressing the up arrow or down arrow button on either call station and wait for it to stop. The door will automatically open. Enter the lift and press and release the door button to close it. Then press and release UP or DOWN on the control station.
-
Page 9: Smoke Alarms
SMOKE ALARM A smoke detection system has been installed on your lift. It has been designed to provide adherence to British Standard BS5900 2012 Section 9.13 “Behaviour of homelift in the event of fire”. The system utilises two smoke alarms one upper level, one lower level, which are wirelessly connected to the main circuit board on the lift (Figure 6). - Page 10 When the Lift is stationary at either level If smoke is detected, the alarm will sound. After a period of time, all other smoke alarms connected to the system will then start to sound and the lift deactivates. When the Lift is travelling between levels If smoke is detected, the alarm will sound.
-
Page 11: Emergency Procedures
EMERGENCY PROCEDURES In the event of a mains failure during travel, the battery backed control system of the lift will only allow normal operation in the down direction without loss of any safety features. This allows the user to exit the car at the lower level in the normal way. Emergency Manual Lowering IMPORTANT: During emergency manual lowering, the normal safety features... - Page 12 • Swivel the metal cover plate on the front face of the housing to reveal an access hole (Figure 7) • The red cord revealed in the access hole now needs to be pulled continuously to lower the lift car slowly. •...
- Page 13 Remove the black rubber grommet by the door Insert the black emergency door release key into the square hole behind the grommet Turn the key to release the mechanism This should release the catch. The door can be opened from the outside in the same way.
-
Page 14: Fault Finding
FAULT FINDING The most likely causes of your lift failing to operate are: The door not being fully closed • Something obstructing the travel of the car or infill panel safe • edge causing one or more of the sensors or safe edges (Figure 1) to operate and therefore preventing travel in the appropriate direction. - Page 15 Lift Malfunction Fault Indication Cause Remedy Lift will not travel in No lights on car Door not shut or Press door button either direction panel remote fob off Press a button on Flat batteries in Replace smoke smoke alarms alarm batteries Lift will not go up One green off on Car safe edge...
-
Page 16: Changing Call Station Batteries
CHANGING CALL STATION BATTERIES 1. The call station can be removed from the wall by sliding the case upwards. 2. Remove the four screws in the back with a posi-drive screwdriver. 3. Using a screw driver, gently Figure 9. push the battery out a short way and then pull using fingers. -
Page 17: Lift Disassembly / Safe Disposal Of Hazardous
LIFT DISASSEMBLY/SAFE DISPOSAL OF HAZARDOUS MATERIALS This lift must be disassembled by a competent person who has been fully trained in the installation of this lift and is qualified to provide safe disconnection of the lift to the mains terminal. Batteries &... -
Page 18: Service History Record
SERVICE HISTORY RECORD An entry should be added to the following table every time the lift is serviced Date Engineer Company Comments... -
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY Machinery Description: Stratum Homelift This lift was manufactured by TERRY GROUP Ltd., who declare that this lift fulfils all the relevant provisions of the following Directives: 2014/30/EU Electromagnetic Compatibility Directive 2006/42/EC Machinery Directive This lift also fulfils all the relevant provisions of the following Standards: BSEN 12015:2014 Electromagnetic compatibility. -
Page 20: Lift Specification
LIFT SPECIFICATION Address of manufacturer:- Terry Group Ltd. Unit 1 Longridge Trading Estate Knutsford Cheshire England WA16 8PR Lift serial No: Year of manufacture: Safe working load 250kg Maximum travel 3.6 metres Duty cycle 10 cycles per hr with max load Average noise level 65 dBA Power supply... - Page 24 For technical help, sales or service enquiry telephone: Stannah Homelifts Watt Close, East Portway, Andover, Hampshire, SP10 3SD t: 0800 715 482 e: webenquires@stannah.co.uk www.stannahhomelifts.co.uk Ref: ED00053...
