Setting of preset pressure [Preset input type only]
No
①
Unlock keys (refer to P9)
②
Press S-key
③ Set P_1 by using the △ and ▽ keys.
④
Press S-key
⑤ Set P_2 by using the △ and ▽ keys.
⑥
Press S-key
⑦ Set P_3 by using the △ and ▽ keys.
⑧
Press S-key
⑨ Set P_4 by using the △ and ▽ keys.
⑩
Press S-key
⑪
Lock keys (refer to P9)
(Note1): P_1 to P_4 are adjustable in a range from 0% to 100% of the rated value.
(Note2): For safety reasons, it is recommended that one of the preset pressures be set to 0 MPa.
(Note3): Preset pressures are set based on the minimum unit for output display.
unit
The range of the
LED pressure display
Reset function
Reset method
No
①
Unlock keys (refer to P9)
Press the △ and ▽ keys simultaneously for
②
3 seconds or more.
③
The settings are reset and returned to the condition before power was applied.
④
(Key locked)
Reset content
Item
F_1
F_2
P_1、P_2
P_1～P_4
(Note) Gain (GL) is not reset.
Key operation
MPa
0.00 to 2.40
Key operation
Reset content
0%F.S.
100%F.S.
100%F.S.
0%F.S.
⇔
⇔
⇔
⇔
Return to (current) pressure display.
2
kgf/cm
0.0 to 24.0
(Current) pressure is displayed
is displayed for approx. 1 second
Application model
Current / Voltage input type
Current / Voltage input type
Switch output type
Preset input type
- 12 -
LED Display
(displayed alternately)
(displayed alternately)
(displayed alternately)
(displayed alternately)
(Default value: 0%)
bar psi
0.0 to 24.0 0 to 348
LED Display
