Delfield Enodis 6100XL Specifications

Delfield
™
®
6100XL
Solid Door Reach-in Freezer
Models
• 6125XL-S Single section full height doors
• 6151XL-S Two section full height doors
• 6176XL-S Three section full height doors
• 6125XL-SR Remote full height doors
• 6151XL-SR Remote full height doors
• 6176XL-SR Remote full height doors
6125XL-SH

Specifications

Exterior: Top and bottom are constructed of 24-gauge
galvanized steel. Exterior sides are 0.032 aluminum. Front
housing is 22-gauge stainless steel.
Doors: Unit is provided with hinged solid front door(s). Door
exterior is constructed of 22-gauge stainless steel. Interior
door liner is ABS. Doors are provided with locks, magnetic
gaskets, self-closing, edgemount hinges; and quick grip long
length door handle(s). Doors are field reversible with no
drilling required.
Interior: Liner is constructed of seamless, one piece ABS
material with 15 molded shelf supports spaced 3.00" (7.6cm)
apart. Three epoxy coated wire shelves, rated at 250 lb. load
capacity each, are provided per section. Shelf supports are
also capable of holding two 12" x 20" pans (by others) or one
18" x 26" pan (by others) per level. Liner comes with a limited
lifetime warranty.
Units are completely insulated with a minimum of 2.00"
(5.08cm) high density foamed in place polyurethane.
Interior is lighted by one 40-watt incandescent light (by
others) on one and two door models, and two 40-watt
incandescent lights (by others) on three door models. Lights
are located outside of the food zone. Door activated switches
control the lights.
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
Standard Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Refrigeration system: All components are mounted to
the exterior cabinet ceiling, outside the food zone and are
assembled as one piece and can be removed as one piece.
Environmentally friendly R404A refrigerant is used. System
has the capability of maintaining between -5˚F and 0˚F in
heavy use food service operations. Refrigerant is metered
using a highly responsive thermostatic expansion valve. On
demand, evaporator defrost is automatic using a temperature
initiated/temperature terminated system with electric heaters.
System is controlled using Delfield's ACT-Advanced Control
Technology electronic temperature control, which provides
improved pull down times, reducing compressor cycling and
longer compressor life with lower energy consumption.
Evaporator condensate is eliminated using an energy
efficient hot gas system.
Others: Unit is supplied standard with a 10' cord and plug,
attached. 4" diameter casters with an overall height of 5"
are mounted on the unit from the factory on self-contained
models ( 2&3 section units only).
Remote units are standard with legs. Legs are constructed
of painted metal and are 6" high with 1" adjustability to
compensate for installation location factors.
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
• 6125XL-SH Single section half height door
• 6151XL-SH Two section half height door
• 6176XL-SH Three section half height door
• 6125XL-SHR Remote half height door
• 6151XL-SHR Remote half height door
• 6176XL-SHR Remote half height door
Stainless steel doors and front shroud
Aluminum sides
Seamless, Delrite® ABS interior liner
Top mounted refrigeration system
High performance Delflow refrigeration,
designed to maintain -5˚F to 0˚F
Ships with casters mounted from factory
(2&3 section units only)
Easy to adjust epoxy shelves (three per section)
Easy to read digital thermometer with visual
high/low temp alarm
10' cord and plug attached
Edgemount door hinges
All doors are fully field rehingable
Environmentally friendly R404a refrigerant
One year parts and labor, 5 year compressor
warranty, limited lifetime liner warranty
Accepts 18" x 26" sheet pans
Self closing doors with stay open feature at
120˚
Ergonomically correct, easy grip door handles
www.delfield.com
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
Options &
Accessories
o Extra shelves
o Non standard hinging
o Legs in lieu of casters
