Description
PRO900-G1-MF-150-BME
CHARVET
1170, rue Principale – BP 3 38850
Charavines – France
Tel.: +33 (0)4 76 06 64 22
Fax: +33 (0)4 76 55 78 75
Email:
info@charvet-sa.fr
Email:
sav@charvet-sa.fr
AUTHENTIC COOKING EQUIPMENT
INSTALLATION MANUAL
WATER-JACKETED BOILING
PAN
GAS-POWERED – 150 LITRES
Code
V03199
INSTALLATION MANUAL
PRO900-G1-MF-150-BME
REVISION INDEX: C
Date created: 06/06/2018
Date of the revision: 15/10/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO 900 and is the answer not in the manual?

Questions and answers

Related Manuals for Charvet PRO 900

Summary of Contents for Charvet PRO 900

  • Page 1 AUTHENTIC COOKING EQUIPMENT INSTALLATION MANUAL WATER-JACKETED BOILING GAS-POWERED – 150 LITRES Description Code PRO900-G1-MF-150-BME V03199 CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 38850 REVISION INDEX: C Charavines – France Date created: 06/06/2018 Tel.: +33 (0)4 76 06 64 22...

  • Page 3: Table Of Contents

    PAGE 10 Gas circuit diagram PAGE 11 Water circuit diagram PAGE 11 List of emergency parts PAGE 12 CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 38850 REVISION INDEX: C Charavines – France Date created: 06/06/2018 Tel.: +33 (0)4 76 06 64 22...

  • Page 4: Scope Of Application Of The Manual

    INTRODUCTION FOREWORD Thank you for choosing Charvet equipment for your installation. Our equipment is designed and manufactured in France by our teams who are committed to meeting five targets: ROBUSTNESS PERFORMANCE HYGIENE ERGONOMICS SAFETY If, however, despite our commitment and effort, you encounter a problem with one of our products, please get in touch with our After-sales service.

  • Page 5: 1170, Rue Principale - Bp 3 38850 Charavines - France Tel.: +33 (0)4 76 06 64

    WEEE placed on the market after 13/08/2005 or when replacing such equipment with equipment that is the equivalent or performs the same function. As such, the CHARVET company is a member of ECOLOGIC, an eco- organisation approved by the State. The equipment should be palletised and ready for loading in a place that is accessible by the carrier.

  • Page 6: Installation

    WARNING use in force in the country of installation. DATA PLATE Each appliance has a data plate. Fig. 1 – Data plate location CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 REVISION INDEX: C 38850 Charavines – France Date created: 06/06/2018 Tel.: +33 (0)4 76 06 64 22...

  • Page 7: Electrical Connection

    IEC 60417-5021(2002-10) symbol 3.1.3 Checks after connection After connection, check: That the appliance is correctly earthed The insulation of the electrical equipment CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 REVISION INDEX: C 38850 Charavines – France Date created: 06/06/2018 Tel.: +33 (0)4 76 06 64 22...

  • Page 8: Gas Connection

    Its length must also not exceed 1.50m. 3.2.3 Checks after connection After connecting, check the tightness of the gas circuit up to the supply connection. CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 REVISION INDEX: C 38850 Charavines –...

  • Page 9: Burner Conversion

    Step No.2 – Remove the gas hose and the insulation Disconnect the gas supply pipe (see opposite). Unscrew the insulation plate (one screw, see opposite). CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 38850 REVISION INDEX: C Charavines – France Tel.: +33 (0)4...
  • Page 10 Note: When reassembling the injection on the burner kit, make sure the injectors are oriented in the axis of the corresponding burners. CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 38850 REVISION INDEX: C Charavines – France Tel.: +33 (0)4...
  • Page 11 To increase the pressure, turn the adjusting screw (Fig.5 – Item 2) clockwise. Turn off the appliance, refit the screw(Fig.5– Item 1). Fig. 5– View of ignition control box CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 38850 REVISION INDEX: C Charavines –...

  • Page 12: Maintenance & Servicing

    Gas valve 173305 Boiling pan manifold 175188 Ignition spark plug 175188 Flame detection spark plug CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 38850 REVISION INDEX: C Charavines – France Tel.: +33 (0)4 Date created: 06/06/2018 76 06 64 22...

  • Page 13: Water Circuit Diagram

    Jacket filling Pressure gauge Pressure switch LIST OF EMERGENCY PARTS Thermostat 230V meter Switch CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 38850 REVISION INDEX: C Charavines – France Tel.: +33 (0)4 Date created: 06/06/2018 76 06 64 22...
  • Page 14 Code Code Code 02655 A 05405 A 02681 A CHARVET INSTALLATION MANUAL PRO900-G1-MF-150-BME 1170, rue Principale – BP 3 38850 REVISION INDEX: C Charavines – France Tel.: +33 (0)4 Date created: 06/06/2018 76 06 64 22 Date of the revision: 15/10/2018...

  • Page 15: Pro900-G1-Mf-150-Bme

    AUTHENTIC COOKING EQUIPMENT USER MANUAL GAS-POWERED WATER- JACKETED BOILING PAN – 150 LITRES Description Code PRO900-G1-MF-150-BME V03199 CHARVET USER MANUAL PRO900-G1-MF- 150-BME REVISION INDEX: C 1170, rue Principale – BP 3 38850 Date created: 06/06/2018 Charavines – France Date of the revision: Tel.: +33 (0)4 76 06 64 22...
  • Page 17 Cleaning the outer surfaces PAGE 6 Cleaning the pan PAGE 6 Cleaning the burner PAGE 6 List of emergency parts PAGE 7 CHARVET USER MANUAL PRO900-G1-MF- 150-BME REVISION INDEX: C 1170, rue Principale – BP 3 38850 Date created: 06/06/2018 Charavines – France Date of the revision: 15/10/2018 Tel.: +33 (0)4 76 06 64 22...

  • Page 18: Foreword

    INTRODUCTION FOREWORD Thank you for choosing Charvet equipment for your installation. Our equipment is designed and manufactured in France by our teams who are committed to meeting five targets: ROBUSTNESS PERFORMANCE HYGIENE ERGONOMICS SAFETY If, however, despite our commitment and effort, you encounter a problem with one of our products, please get in touch with our After-sales service.

  • Page 19: Electronic Components

    WEEE placed on the market after 13/08/2005 or when replacing such equipment with equipment that is the equivalent or performs the same function. As such, the CHARVET company is a member of ECOLOGIC, an eco- organisation approved by the State. The equipment should be palletised and ready for loading in a place that is accessible by the carrier.

  • Page 20: Control Panel

    Description Heating indicator light Energy meter Burner ignition indicator light On/Off switch ‘Gas valve shut-off’ fault warning light Gas valve reset button CHARVET USER MANUAL PRO900-G1- MF-150-BME REVISION INDEX: C 1170, rue Principale – BP 3 Date created: 06/06/2018 38850 Charavines – France Date of the revision: 15/10/2018 Tel.: +33 (0)4 76 06 64 22...

  • Page 21: Starting Up

    CAUTION In such a case, Charvet cannot be held responsible. Prolonged use of the pan when empty and without supervision may damage the appliance. When opening the lid during ‘wet’ cooking, be careful of steam escaping as you pass your arm over the pan because there is a risk of burning.

  • Page 22: Cleaning The Outer Surfaces

    BURNER CLEANING THE Please call your installer for any work on the burner. You must not clean the burner with water CHARVET USER MANUAL PRO900-G1- MF-150-BME REVISION INDEX: C 1170, rue Principale –...

  • Page 23: List Of Emergency Parts

    Water solenoid controller valve Code Code Code 02655 A 05405 A 02681 A CHARVET USER MANUAL PRO900-G1-MF- 150-BME REVISION INDEX: C 1170, rue Principale – BP 3 Date created: 06/06/2018 38850 Charavines – France Date of the revision: 15/10/2018 Tel.: +33 (0)4 76 06 64 22...
