Charvet PRO 800 Installation Manual

Open burners / solid top on electric oven
Hide thumbs Also See for PRO 800:
Table of Contents

Advertisement

Quick Links

Download this manual
Description
M3FN/PL
M3PL/FN
CHARVET
38850 – CHARAVINES
Tél. : +33 4 76 06 64 22
Fax: +33 4 76 55 78 75
Email :
info@charvet.fr
OPEN BURNERS / SOLID TOP
ON ELECTRIC OVEN
PRO 800
V01588
V01592
PRO 900
V01464
V01468
INSTALLATION MANUAL
MANUAL: EN 800-900 M3FNPL
Ind. A – Created on: 21/10/2010
Updated on:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO 800 and is the answer not in the manual?

Questions and answers

Related Manuals for Charvet PRO 800

Summary of Contents for Charvet PRO 800

  • Page 1 OPEN BURNERS / SOLID TOP ON ELECTRIC OVEN Description PRO 800 PRO 900 M3FN/PL V01588 V01464 M3PL/FN V01592 V01468 INSTALLATION MANUAL CHARVET 38850 – CHARAVINES MANUAL: EN 800-900 M3FNPL Tél. : +33 4 76 06 64 22 Ind. A – Created on: 21/10/2010...

  • Page 2: Table Of Contents

    Open burners / solid top on electric oven SUMMARY INSTALLATION MANUAL INSTALLATION 1.1. ENERAL POINTS 1.2. ANDLING 1.3. NSTALLATION 1.4. IXING THE FLUE 1.5. AS CONNECTIONS 1.6. OWER CONNECTION CONVERSION TO OTHER TYPES OF GAS 2.1. HANGING THE INJECTORS 2.1.1. PEN BURNER Ø...

  • Page 3: Installation

    Open burners / solid top on electric oven INSTALLATION General points 1.1. Installation must be undertaken in compliance with the following instructions and with local codes and bylaws. Ensure you have a suitable and sufficient risk assessment in place. The user's manual must be given to the user after installation. Handling 1.2.

  • Page 4: Fixing The Flue

    Open burners / solid top on electric oven Fixing the flue 1.4. Unscrew the screws to lower the fixing tabs, Help yourself with an appropriate tool to push the fixing tabs. Tighten the screws of the flue cover. Gas connections 1.5.

  • Page 5: Conversion To Other Types Of Gas

    Open burners / solid top on electric oven • Before connection : Check that the supply voltage is compatible with the voltage of the appliance (see data plate). Check that the electric network is equipped with all-pole circuit breakers having a cross section of 3.5 mm, and complies with the European Standard EN 60335-1 dated of May 2003.

  • Page 6: Solid Top Plate

    Open burners / solid top on electric oven Solid top plate 2.1.3. Gas type Mark Nominal & operating pressure engraved adjustmen calorific output kW d (mm) injector G20: Pn = 20 mbar G 25: Pn = 20 mbar G 25: Pn = 25 mbar G 30: Pn = 29 mbar G 30: Pn = 50 mbar G 31: Pn = 37 mbar...

  • Page 7: Adjusting The Air

    Open burners / solid top on electric oven Adjusting the air 2.2. Open burners Remove the cast-iron pan supports, Remove the burners' caps, Remove the spillage tray, You can reach the air ring and injectors. Unlock the air ring (nut/ring) and push back the air ring to reach the injector.
  • Page 8 Open burners / solid top on electric oven • Connections: *GAS Threaded tube M 1/2“ Remove the left side panel. Two lower fitting screws: pull the bottom of the control panel, then pull it down to disengage its top. Connect the appliance to the gas mains using a ½“ M tube.

  • Page 9: Servicing

    Open burners / solid top on electric oven *WIRING DIAGRAMS Option Voltage Wiring diagrams # Electric ignition 1 ~ 230 V + E SE0001/ 00 Sequential regulation 1 ~ 230 V + E SE0033 / 00 Electric oven 3 ~ 400 V + E SE0011 / 00 SERVICING Any technical action on an appliance must be undertaken by a qualified technician.

  • Page 10: Basic Spare Parts List

    Open burners / solid top on electric oven BASIC SPARE PARTS LIST Description Code Photograph Description Code Photograph Pilot injector for 3-flame pilot 00177A solid top light Propane 01157A Natural 06430A Injectors for Pilot light solid top injectors for open burners Ø...
  • Page 11 Open burners / solid top on electric oven Electric ignition 03967A Red indicator 07136A push button Thermostat 01990A Oven switch 00831A 300°C Heating 02063A element 2500W 400V...
  • Page 12 Open burners / solid top on electric oven ELECTRIC IGNITION: 4 BURNERS 01 Terminals 02 Push button 03 Transformer 04 Electrode 05 High-voltage cable 1 ~ 230V + PE SE0001 / 00...
  • Page 13 Open burners / solid top on electric oven Sequential régulation 1 ~ 220 V + T SE0032 / 00 NOMENCLATURE: SEQUENTIAL REGULATION (wiring diagram: SE0033 / 00) Mark Code Description Quantity 02468A 10 mm² terminal (brand : Viking) 07069A Blue terminal Vicking 03575A 6 mm²...
  • Page 14 Open burners / solid top on electric oven OVEN VAULT MILD STEEL BASE VAULT MILD STEEL BASE BROWN BLACK 3 ~ 400 V + PE P = 5 kW SE0011 / 00 NOMENCLATURE: ELECTRIC OVEN (wiring diagram: SE0011 / 00) Mark Code Description...
  • Page 15 OPEN BURNERS / SOLID TOP ON ELECTRIC OVEN Description PRO 800 PRO 900 M3FN/PL V01588 V01464 M3PL/FN V01592 V01468 USER’S INSTRUCTIONS CHARVET 38850 – CHARAVINES MANUAL: EN 800-900 M3FNPL Tél. : +33 4 76 06 64 22 Ind. A – Created on: 21/10/2010...
  • Page 16 Open burners / solid top on electric oven SUMMARY USER’S INSTRUCTIONS INTRODUCTION PRIOR TO STARTING UP STARTING UP 3.1. PEN BURNERS FIGURE 3.2. OLID TOP PLATE 3.3. SWITCHING OFF MAINTENANCE 5.1. LEANING OF THE STAINLESS STEEL SURFACES 5.2. LEANING THE OPEN BURNERS 5.3.

  • Page 17: Introduction

    Open burners / solid top on electric oven INTRODUCTION A) Our equipment is for professional use only and must be used by qualified staff. B) The equipment must be installed in compliance with local codes and bylaws. It must be installed in a kitchen equipped with an adequately sized mechanical extraction system.

  • Page 18: Prior To Starting Up

    Open burners / solid top on electric oven Electric oven GN2/1 Dimensions: - Length: 530 mm - Depth: 650 mm - Height: 300 mm. Mild steel base and vault: Heating elements rated 5 kW in total - 3 ~ 400V+ E. 8-position switch: ‘vault - 0 –...

  • Page 19: Solid Top Plate

    Open burners / solid top on electric oven Solid top plate 3.2. - Take off the central ring. - Push and turn the control knob of desired burner counter-clockwise and up to the spark symbol. - Keep pushing thoroughly while presenting a flame or pressing the ignition push button (if fitted). - Keep the control knob pressed for 5 to 15 sec.

  • Page 20: Switching Off

    Open burners / solid top on electric oven Select the aperture of the air-inlet (located above the oven door) to evacuate cooking steams. OPEN CLOSED Do not forget to place a drip pan when cooking directly on the oven shelf. The shelf runners allow the dishes to be levelled and centred.

  • Page 21: Cleaning The Open Burners

    Open burners / solid top on electric oven Cleaning the open burners 5.2. a) Remove the pan supports, the caps, and the dip tray. b) Clean, rinse and dry these parts carefully. c) Refit the parts in reverse order; ensure that the burners' bodies are well in place. Cleaning the solid top plate 5.3.

  • Page 22: Breakdown

    Open burners / solid top on electric oven BREAKDOWN UNSATISFACTORY HEATING: Probable causes - Clogging of the burners, injectors, etc. - Incorrect gas pressure; - Incorrect grading of the injectors; - Clogging of the rear internal flue box (solid top plate). The indicators are alight but the oven doesn't heat: .

  • Page 23: Data Plate

    Open burners / solid top on electric oven DATA PLATE TRANSFER below the information written on the DATA PLATE of your apparatus. This will ease the communication between you and your installer, and will help you with maintenance problems and spare parts.
