ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA
DESCRIPTION
GMC0121
GMC0124
GMC0125
GMC0128
CHARVET Paul s.a.
F-38850 – CHARAVINES
Tel.: +33 (0) 476 066 422
Fax: +33 (0) 476 557 875
Email:
info@charvet.fr
Email:
sav@charvet-sa.fr
MODULE GMC 850
EXTEND CONCEPT
MODULE 850
INSTALLATION MANUAL
MANUAL: EN - GMC 850 ELECT. CHR. STEEL/CAST IRON PLANCHA
Index A; Created on: 01/10/2009
Updated on:
Advertisement
Chapters
Table of Contents
Related Manuals for Charvet GMC 850
Summary of Contents for Charvet GMC 850
- Page 1 GMC0125 GMC0128 INSTALLATION MANUAL CHARVET Paul s.a. F-38850 – CHARAVINES MANUAL: EN - GMC 850 ELECT. CHR. STEEL/CAST IRON PLANCHA Tel.: +33 (0) 476 066 422 Index A; Created on: 01/10/2009 Fax: +33 (0) 476 557 875 Updated on: Email: info@charvet.fr...
-
Page 2: Table Of Contents
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA SUMMARY 1. INSTALLATION ----------------------------------------------------------------------------------------------------------- 3 1.1. G ------------------------------------------------------------------------------------------------------ 3 ENERAL POINTS 1.2. H --------------------------------------------------------------------------------------------------------------- 3 ANDLING 1.3. I ---------------------------------------------------------------------------------------------------------- 3 NSTALLATION 1.4. D ------------------------------------------------------------------------------------------------------------ 4 ATA PLATE 2. POWER CONNECTION ------------------------------------------------------------------------------------------------- 4 2.1. C... -
Page 3: Installation
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA INSTALLATION General points 1.1. Installation must be undertaken in compliance with the following instructions and with local codes and bylaws. Ensure you have a suitable and sufficient risk assessment in place. The user’s manual must be given to the user after installation. -
Page 4: Data Plate
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA Data plate 1.4. Each appliance has is own data plate. Transfer all the information written on the data plate to the part of the user’s manual reserved for it. This will ease the communication between you and your client for better service. -
Page 5: Checks Before Connection
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA Checks before connection 2.1. Check that: • The electrical voltage of the supply is compatible with the voltage of the apparatus (see data plate and § 5). • The cable is fixed properly, •... -
Page 6: Connecting The Appliance To The Electric Network
Remove the control knobs (1) fixed with screws, • Unscrew the 2 screws (2) located under the Charvet’s logo. Unscrew (3) and pull the bottom of the panel up and out. Note: the technical space is behind the control panel. -
Page 7: Connecting The Water Flushing
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA CONNECTING THE WATER FLUSHING Checks before connection 3.1. • Purge the supply water pipe and clean the filter, • Check that both siphon and waste pipe are free of obstructions. Connecting the appliance to the water mains 3.2. -
Page 8: Wiring Diagrams
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA WIRING DIAGRAMS NOMENCLATURE: Electric chromium steel / cast iron plancha + thermostat _3~400V+E TR0040 Mark Code Description Quantity 02468A Terminal Vicking, 10mm² 03575A Earth terminal Vicking ELE1651 ON indicator 400V 00080A Contactor (for regulation) - Page 9 GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA Hot cupboard 2/1 Hot cupboard 1/1 1~230V + T = TR0038 NOMENCLATURE: Hot cupboard – single phase 230 V Mark Code Description Quantity ELE0304 Regulation thermostat ELE0434 230V heating indicator ELE0231 Heating element 230V 600W...
- Page 10 GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA TR0101 Wiring diagram valid for switches having a rod with meplat up (set at 0). For switches having a rod with meplat down below (set at 0), reverse: - 107 and 108 - 109 and 110...
-
Page 11: Basic Spare Parts List
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA BASIC SPARE PARTS LIST Description / Code Description / Code Photograph Photograph Electric oven heating Plate element Chrome steel Mild steel base 501042 1200W Cast iron 502632 07458A Vault 1800W 502637 Hot cupboard... -
Page 12: Maintenance
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA MAINTENANCE Electric oven: Removing the heating elements 6.1. Fixing screws • Removing the heating elements - Open the oven door, - Remove the enameled vaults (A), - Remove the grids (B) then the mild steel bases (C), - Unscrew the fixing screws (2) and (3) of the heating element, vault and mild steel base. -
Page 13: Changing The Solenoid Valve
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA Changing the solenoid valve 6.3. • Changing the solenoid valve - Unscrew the nut (A) and pull the copper pipe (B) to the left very carefully, - Unscrew the nut (C) and swivel (D), - Unscrew the nut (E) to remove the solenoid valve. - Page 14 MODULE 850 GMC0054 GMC0089 USER’S INSTRUCTIONS CHARVET Paul s.a. F-38850 – CHARAVINES MANUAL: EN - GMC 850 ELECT. CHR.STEEL/CAST IRON PLANCHA Tel.: +33 (0) 476 066 422 Index A; Created on: 01/10/2009 Fax: +33 (0) 476 557 875 Updated on: Email: info@charvet.fr...
- Page 15 GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA SUMMARY 1. INTRODUCTION ---------------------------------------------------------------------------------------------------------- 3 2. PRIOR TO STARTING UP---------------------------------------------------------------------------------------------- 3 3. STARTING UP ------------------------------------------------------------------------------------------------------------- 3 3.1. E ------------------------------------------------------------- 3 LECTRIC CHROMIUM STEEL CAST IRON PLANCHA 3.2. E -------------------------------------------------------------------------------------------------------- 4 LECTRIC OVEN 3.3. E...
-
Page 16: Introduction
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA INTRODUCTION Our equipment is for professional use only and must be used by qualified staff. The equipment must be installed in compliance with local codes and bylaws. It must be installed in a kitchen equipped with an adequately sized mechanical extraction system. -
Page 17: Electric Oven
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA Electric oven 3.2. sole voûte • Turn control knob to the desired position (vault/vault-mild steel base/mild steel base); the heating indicator is alight. voûte +sole • Turn thermostat to the desired temperature; the heating indicator is illuminated. -
Page 18: Starting The Water Flushing
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA Starting the water flushing 3.4. Strainer Sluice gate - Before use, check the sluice gate is in place (fig. I and - Open the water tap: the water is running through the strainer. -
Page 19: Cleaning The Oven
GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA Cleaning the oven 5.2. To avoid fumes due to greases, stains and food particles, we recommend you to clean all the oven internal sides every day. • The mild steel base can be removed to be cleaned. - Page 20 GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA Electric hot cupboard 5.4. • Cleaning the electric hot cupboard - Open the door and remove the removable shelves (A), - Push them up before pulling them to the middle (B), - Clean the parts in hot soapy water.
- Page 21 GMC 850 ELECTRIC CHROMIUM STEEL/CAST IRON PLANCHA TRANSFER below the information written on the DATA PLATE of your apparatus. This will ease the communication between you and your supplier, and will help you with maintenance problems and spare parts.
