CDN DTW450 Manual

FOR GENERAL PURPOSE COOKING
AND COMMERCIAL DISHWASHERS
• NSF Certified
®
• 6 second response
• 1.5 mm thin tip
• 4.5"/11.4 cm stem
• Field calibration
• Waterproof (IPX7)
• Safe for commercial dishwashers
• Shatterproof
• High heat
• Hold
• Max/min mode
• Big digit
• Food-safe ABS plastic with BioCote
• Stainless steel stem
• On/off button
• Auto-off after 15 minutes
• 3-way mounting: pocket clip/magnet/loop
• One LR44 alkaline button battery included
Note:
Remove label from display before initial use.
®
Tel 800 338-5594 Fax 800 879-2364 Web CDNmeasurement.com
DISHWASHER THIN TIP THERMOMETER
Note:
In the following instructions, names of the control
buttons are shown in CAPS. Function information that
appears on the display is shown in BOLD CAPS.
BATTERY INSTALLATION
The battery is installed. Replace battery when LCD
becomes dim.
1. Remove battery cover on the back with a small
Phillips screwdriver.
2. Install one LR44 battery with positive (+) side up.
3. Replace the battery cover.
OPERATING INSTRUCTIONS
A. Temperature Measurement
1. Press the POWER (ÉNERGIE) button to turn
the DTW450 on.
2. After use, press the POWER button to turn
the DTW450 off and conserve battery life.
B. Temperature Scale
Press the °C/°F button to select temperature
reading in Fahrenheit or Celsius.
C. Hold
Before withdrawing the DTW450 from the food,
press the HOLD button. This will "hold" the reading
until pressed again.
corner of the display.
D. Max/Min Mode
Max/Min Mode is always working behind the
scenes, continually storing the highest and lowest
temperatures.
1. Before using Max/Min Mode clear the stored
MAX/MIN values by pressing the CLEAR
button while in the Max or Min mode.
2. Press the MAX/MIN button to display
the highest temperature.
the display.
3. Press the MAX/MIN button twice to display
the lowest temperature.
the display.
4. The display automatically returns to
the temperature mode after
a few seconds.
5. Press the CLEAR button in Max
or Min mode to clear the respective
stored MAX/MIN value.
Model: DTW450
-40 to +450°F/-40 to +230°C
H appears in the upper right
MAX appears on
MIN appears on
