SDD
Series
Dehumidifying Dryers
Date: Oct, 2010
Version: V4.0 (English)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDD-20U/30H and is the answer not in the manual?

Questions and answers

Related Manuals for Shini SDD-20U/30H

Summary of Contents for Shini SDD-20U/30H

  • Page 1 Series Dehumidifying Dryers Date: Oct, 2010 Version: V4.0 (English)

  • Page 3: Table Of Contents

    Contents General Description................... 3 1.1 Feature ....................3 1.2 Technical Specifications ............... 3 1.2.1 Specifications................3 1.2.2 Outline Drawing ................3 1.2.3 Drying Capacity................3 1.3 Safety Regulations ................3 1.3.1 Safety Regulations for the Blowers ..........3 1.3.2 Safety Signs and Labels ............. 3 1.3.3 Transportation and Storage of the Machine ........
  • Page 4 2.8.8 Control Circuit (PLC) ..............3 2.8.9 Thermocouple Wiring Diagram (PLC) ......... 3 2.8.10 Components Layout (PLC)............3 2.8.11 Electrical Components List (PLC) ..........3 2.8.12 Main Electrical Components Description........3 2.9 Operation Procedures ................3 2.9.1 Operation Regulations ..............3 2.9.2 Description of Touch Screen............
  • Page 5 Table 1-2：Drying Capacity 1 ................3 Table 1-3：Drying Capacity 2 ................3 Table 2-1：Hygrometric Equivalents..............3 Table 2-2：Parts List (SDD-20U/30H~80U/50H) ..........3 Table 2-3：Parts List (SDD-120U/50H~160U/120H) .......... 3 Table 2-4：Parts List (SDD-230U/120H~300U/200H) ........3 Table 2-5：Parts List (SDD-450U/200H~600U/300H) ........3 Table 2-6：Parts List (SDD-600U/400H~900U/500H) ........
  • Page 6 Table 2-18：Electrical Components List (PCB) (SDD-750U/900U-500H) ..3 Table 2-19：Electrical Components List (PCB) (SDD-900U/1200U-700H) ..3 Table 2-20：Electrical Components List (PLC) (SDD-20U/30H) ......3 Table 2-21：Electrical Components List (PLC) (SDD-40U/30H) ......3 Table 2-22：Electrical Components List (PLC) (SDD-40U/50H) ......3 Table 2-23：Electrical Components List (PLC) (SDD-80U/50H) ......
  • Page 7 Picture 2-7：Main Circuit 1 (PCB)............... 3 Picture 2-8：Main Circuit 2(PCB)................ 3 Picture 2-9：Control Circuit (PCB)..............3 Picture 2-10：Thermocouple Wiring Diagram (PCB) .......... 3 Picture 2-11：Components Layout (PCB) ............3 Picture 2-12：Main Circuit 1 (PLC) ..............3 Picture 2-13：Main Circuit 2 (PLC) ..............3 Picture 2-14：Control Circuit (PLC) ..............
  • Page 8 Picture 4-3：Intermittent running setup 2............3 Picture 4-4：Intermittent running setup 3............3 Picture 4-5：Weekly Time Start Setup 1............. 3 Picture 4-6：Weekly Time Start Setup 2............. 3 Picture 4-7：Weekly Time Start Setup 3............. 3 Picture 4-8：Weekly Time Start Setup 4............. 3 Picture 4-9：Weekly Time Start Setup 5.............

  • Page 9: General Description

    1. General Description Please read through this operation manual before using the machine to prevent damages of the machine or personal injuries. SDD series dehumidifying dryers combine dehumidifying and drying systems into a single unit. They have many applications in processing plastic materials, such as PA, PC, PBT, PET etc.

  • Page 10: Feature

    Chapter 6, which contains service instructions intended for service engineers. Other chapters contain instructions for the daily operator. Any modifications of the machine must be approved by SHINI in order to avoid personal injury and damage to machine. We shall not be liable for any damage caused by unauthorized change of the machine.

  • Page 11: Technical Specifications

    1.2 Technical Specifications 1.2.1 Specifications Table 1-1：Specifications Regen. Process Process Regen. blower Insulated Dry air Capacity Dimensions (mm) Weight Model Heater Blower Heater (kW) Hopper /hr)(50/60Hz) H×W×D (kg) (kW) (kW)(50/60Hz) (kW) (50/60Hz) 0.18 / 0.2 0.2 / 0.2 30 / 35 1240×875×810 20U/30H 0.18 / 0.2...

  • Page 12: Outline Drawing

    1.2.2 Outline Drawing Picture 1-1：Outline Drawing 12(136)

  • Page 13: Drying Capacity

    1.2.3 Drying Capacity Table 1-2：Drying Capacity 1 Drying Drying Drying Capacity (kg/hr) Material Temp. Time 120U 160U 160U 230U 230U 300U 300U 450U (℃) (hr) /30H /30H /50H /50H /80H /80H /120H /120H /150H /150H /200H /200H PMMA IONOMER PA6/6.6/6.10 PA11 PA12 PETG...
  • Page 14 Table 1-3：Drying Capacity 2 Drying Drying Capacity (kg/hr) Drying Material Time 450U 600U 600U 750U 750U 900U 900U 1200U Temp. (℃) (hr) /300H /300H /400H /400H /500H /500H /700H /700H PMMA IONOMER PA6/6.6/6.10 PA11 PA12 1062 PETG PMMA PS(GP) SAN(AS) Note! Please refer to above drying capacity of SCD machine, select the right model according to material usage of processing machine.

  • Page 15: Safety Regulations

    1.3 Safety Regulations Warning! Electrical installation should be done by qualified technician only. Before connecting to AC Power Source, turn power switch to OFF position. While AC power source is connected, make sure specifications and overload protection rating of the power switch are suitable and reliable. When the machine is under care or maintenance status, turn both power switch and automatic operation switch to off.

  • Page 16: Safety Signs And Labels

    Picture 1-2：Safety Regulations for the Blowers 1.3.2 Safety Signs and Labels Danger! High voltage danger! This label is stuck on the electrical boxes. Attention! This label means that this area should be taken care! Warning! High temperature, take care of hands! This label should be stick to the shell of heater.

  • Page 17: Transportation And Storage Of The Machine

    Picture 1-3：Safety Signs and Labels 1.3.3 Transportation and Storage of the Machine Transportation 1) SDD series dehumidifying dryers are packed in crates or plywood cases with wooden pallet at the bottom, suitable for quick positioning by fork lift. 2) After unpacked, castors equipped on the machine can be used for ease of movement.
  • Page 18 2) On a wet floor or when it is exposed to rain to avoid electrical shock. 3) If it has been dropped or damaged until it is checked or fixed by a qualified serviceman. 4) This equipment works normally in the environment with altitude within 3000m. 5) At least a clearance of 1m surrounding the equipment is required during operation.

  • Page 19: Structure Characteristics And Working Principle

    2. Structure Characteristics and Working Principle 2.1 Working Principle In the process of material treating, SDD de-moisture and drying group integrates drying and de-moisture functions into one unit, mainly used for drying the plastics with strong hygroscopic characters, such as PA, PC, PBT, PET, etc. Its basic principle is to blow out the hot and moisture air from the dry hopper drum.

  • Page 20: Working Principle

    lower which accelerates the moisture transferring from the plastic granules to the dry air. 2.4 Working Principle Picture 2-1：Working Principle 2.5 Hygrometric Equivalents Table 2-1：Hygrometric Equivalents Dew-point Relative Moisture content (℃) humidity (%) 23,072 2.307 52.5 12,117 1.212 26.10 6,027 0.603 11.20 2,574...

  • Page 21: Comparison Of Air Dew-Point

    2.6 Comparison of Air Dew-point Picture 2-2：Comparison of Air Dew-point 21(136)

  • Page 22: Drawing And Parts List

    2.7 Drawing and Parts List Structural Drawing 2.7.1 Parts name: 1. Return air outlet 2. Insulated hopper 3. Sight-glass window (or material clearance door for hopper capacity more than 80U) 4. Floor stand 5. Dry air outlet 6. Return air inlet 7.

  • Page 23: Assembly Drawing

    2.7.2 Assembly Drawing Remarks: Please refer to material list 2.7.3 for specific explanation of the Arabic numbers in parts drawing. Picture 2-4：Assembly Drawing 23(136)

  • Page 24: Parts List

    2.7.3 Parts List Table 2-2：Parts List (SDD-20U/30H~80U/50H) Part No. Description 20U/30H 40U/30H 40U/50H 80U/50H Castor (red) YW03000300200 YW03000300200 YW03000300200 YW03000300200 Bottom plate Castor brake YW03000300000 YW03000300000 YW03000300000 YW03000300000 Condenser BW88030500020 BW88030500020 BW88030500020 BW88030500020 Front pole Side plate Blower * BM30012500050...
  • Page 25 Part No. Description 20U/30H 40U/30H 40U/50H 80U/50H Outer fastener Outer hopper cone Material hopper Hopper tank cover Down-blowing pipe Hopper top Door frame Sight glass window Butterfly nut YW09051600000 YW09051600000 YW09051600000 YW09051600000 Stand plate Stand fixer Castor fixer Control box BH34405000250 BH34405000250 BH34405000250...
  • Page 26 Table 2-3：Parts List (SDD-120U/50H~160U/120H) Part No. Description 120U/80H 160U/80H 160U/120H Castor (red) YW03000300200 YW03000300200 YW03000300200 Bottom plate Castor brake YW03000300000 YW03000300000 YW03000300000 Condenser BW88081200020 BW88081200020 BW88081200020 Front pole Side plate Blower * BM30031000150 BM30031000150 BM30031000150 Side middle beam Terminal board YE61250000000 YE61250000000 YE61250000000...
  • Page 27 Part No. Description 120U/80H 160U/80H 160U/120H Material hopper Hopper tank cover Down-blowing pipe Hopper top Door frame Sight glass window Butterfly nut YW09051600000 YW09051600000 YW09051600000 Stand plate Stand fixer Castor fixer Control box BH34012000450 BH34168000350 BH34016000350 Upper door plate Door lock YW00000600000 YW00000600000 YW00000600000...
  • Page 28 Table 2-4：Parts List (SDD-230U/120H~300U/200H) Part No. Description 230U/120H 230U/150H 300U/150H 300U/200H Castor (red) YW03000300200 YW03000300200 YW03000300200 YW03000300200 Bottom plate Castor brake YW03000300000 YW03000300000 YW03000300000 YW03000300000 Condenser BW88152000020 BW88152000020 BW88152000020 BW88152000020 Front pole Side plate Blower * BM30012500050 BM30020500050 BM30020500050 BM30020500050 Side middle beam Terminal board YE61250000000...
  • Page 29 Part No. Description 230U/120H 230U/150H 300U/150H 300U/200H Hopper tank cover Down-blowing pipe Hopper top Door frame Sight glass window Butterfly nut YW09051600000 YW09051600000 YW09051600000 YW09051600000 Stand plate Stand fixer Castor fixer Control box BH34231200250 BH34231500250 BH34231500250 BH34302000250 Upper door plate Door lock YW00000600000 YW00000600000...
  • Page 30 Table 2-5：Parts List (SDD-450U/200H~600U/300H) Part No. Description 450U/200H 450U/300H 600U/300H Castor (red) YW03000300200 YW03000300200 YW03000400200 Bottom plate Castor brake YW03000300000 YW03000300000 YW03000400000 Condenser BW88152000020 BW88304000020 BW88304000020 Front pole Side plate Blower * BM30020500050 BM30031000150 BM30031000150 Side middle beam Terminal board YE61250000000 YE61250000000 YE61250000000...
  • Page 31 Part No. Description 450U/200H 450U/300H 600U/300H Material hopper Hopper tank cover Down-blowing pipe Hopper top Door frame Sight glass window Butterfly nut YW09051600000 YW09051600000 YW09001000000 Stand plate Stand fixer Castor fixer Control box BH34452000350 BH34453000250 BH34603000250 Upper door plate Door lock YW00000600000 YW00000600000 YW00000600000...
  • Page 32 Table 2-6：Parts List (SDD-600U/400H~900U/500H) Part No. Description 600U/400H 750U/400H 750U/500H Castor (red) YW03000400000 YW03000400000 YW03000400000 Bottom plate Castor brake YW03000400000 YW03000400000 YW03000400000 Condenser BW88304000020 BW88304000020 YR30010400000 Front pole Side plate Blower * BM30031000150 BM30031000150 BM30042000050 Side middle beam Terminal board YE61250000000 YE61250000000 YE61250000000...
  • Page 33 Part No. Description 600U/400H 750U/400H 750U/500H Material hopper Hopper tank cover Down-blowing pipe Hopper top Door frame Sight glass window Butterfly nut YW09051600000 YW09051600000 YW09051600000 Stand plate Stand fixer Castor fixer Control box BH34604000150 BH34754000150 BH34755000150 Upper door plate Door lock YW00000600000 YW00000600000 YW00000600000...
  • Page 34 Table 2-7：Parts List (SDD-900U/500H~1200U/700H) Part No. Description 900U/500H 900U/700H 1200U/700H Castor (red) YW03000400000 YW03000400000 YW03000400000 Bottom plate Castor brake YW03000400000 YW03000400000 YW03000400000 Condenser YR30010400000 YR30010400000 YR30010400000 Front pole Side plate Blower * BM30042000050 BM30042000050 BM30042000050 Side middle beam Terminal board YE61250000000 YE61250000000 YE61250000000...
  • Page 35 Part No. Description 900U/500H 900U/700H 1200U/700H Material hopper Hopper tank cover Down-blowing pipe Hopper top Door frame Sight glass window Butterfly nut YW09051600000 YW09051600000 YW09051600000 Stand plate Stand fixer Castor fixer Control box BH34905000250 BH34907000150 BH34120000150 Upper door plate Door lock YW00000600000 YW00000600000 YW00000600000...

  • Page 36: Pipe Heaters

    2.7.4 Pipe Heaters Names of Parts： 1. Electric wood cover 2. Pipe heater 3. Heating bucket 4. Outer covering board 5. Fixer Picture 2-5：Pipe Heaters 36(136)

  • Page 37: Honeycomb Rotor

    2.7.5 Honeycomb Rotor Names of Parts： 1. Transmission belt 2. Micro-switch 3. Honeycomb rotor 4. Spring 5. Rotor top cover 6. Double-headed screw bolt 7. Belt tension regulator 8. Transmission wheel 9. Rotor bottom cover 10.Gearmotor Picture 2-6：Honeycomb Rotor 37(136)

  • Page 38: Electrical Diagram

    2.8 Electrical Diagram 2.8.1 Electrical Diagram Table 2-8：Electrical Diagram 1 Model SDD-20U/30H 1-1.6 SDD-40U/30H 1-1.6 SDD-40U/50H 1-1.6 SDD-80U/50H 1-1.6 SDD-120U/80H 2-3.2 0.75 SDD-160U/80H 2-3.2 0.75 SDD-160U/120H 2-3.2 0.75 SDD-230U/120H 2-3.2 0.75 SDD-230U/150H 2-3.2 SDD-300U/150H 2-3.2 SDD-300U/200H 2-3.2 SDD-450U/200H 2-3.2 SDD-450U/300H...
  • Page 39 Table 2-9：Electrical Diagram 2 Model SCD-20U/30H 1-1.6 SCD-40U/30H 1-1.6 SCD-40U/50H 1-1.6 SCD-80U/50H 1-1.6 SCD-120U/80H 1-1.6 SCD-160U/80H 1-1.6 SCD-160U/120H 1-1.6 SCD-230U/120H 1-1.6 SCD-230U/150H 1-1.6 10.8 SCD-300U/150H 1-1.6 10.8 SCD-300U/200H 1-1.6 12.0 18.0 SCD-450U/200H 1-1.6 12.0 18.0 SCD-450U/300H 2-3.2 0.75 15.0 22.5 10.8 SCD-600U/300H 2-3.2...

  • Page 40: Main Circuit (Pcb)

    2.8.2 Main Circuit (PCB) Picture 2-7：Main Circuit 1 (PCB) 40(136)
  • Page 41 Picture 2-8：Main Circuit 2(PCB) 41(136)

  • Page 42: Control Circuit (Pcb)

    2.8.3 Control Circuit (PCB) Picture 2-9：Control Circuit (PCB) 42(136)

  • Page 43: Thermocouple Wiring Diagram (Pcb)

    2.8.4 Thermocouple Wiring Diagram (PCB) Picture 2-10：Thermocouple Wiring Diagram (PCB) 43(136)

  • Page 44: Components Layout (Pcb)

    2.8.5 Components Layout (PCB) Picture 2-11：Components Layout (PCB) 44(136)

  • Page 45: Electrical Components List (Pcb)

    2.8.6 Electrical Components List (PCB) Table 2-10：Electrical Components List (PCB) (SDD-20U/40U-30H) Symbol Name Specifications Part No. Main switch* YE10200300000 Circuit breakers YE40601600000 Excitation break away 220VA-240VA YE40000900000 Circuit breakers* YE40603000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00300000000 Contactors** 230V 50Hz...
  • Page 46 Table 2-11：Electrical Components List (PCB) (SDD-40U/80U-50H) Symbol Name Specifications Part No. Main switch* YE10200300000 Circuit breakers YE40601600000 Excitation break away 220VA-240VA YE40000900000 Circuit breakers* YE40603000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00300000000 Contactors** 230V 50Hz YE00300000000 Temperature controller 230V 50Hz...
  • Page 47 Table 2-12：Electrical Components List (PCB) (SDD-120U/160U-80H) Symbol Name Specifications Part No. Main switch* YE10200300000 Circuit breakers YE40602000100 Excitation break away 220VA-240VA YE40000900000 Circuit breakers* YE40603000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00300000000 Contactors** 230V 50Hz YE00300000000 Temperature controller 230V 50Hz...
  • Page 48 Table 2-13：Electrical Components List (PCB) (SDD-160U/230U-120H) Symbol Name Specifications Part No. Main switch* YE10200300000 Circuit breakers YE40602000100 Excitation break away 220VA-240VA YE40000900000 Circuit breakers* YE40603000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00300000000 Contactors** 230V 50Hz YE00300000000 Temperature controller 230V 50Hz...
  • Page 49 Table 2-14：Electrical Components List (PCB) (SDD-230U/300U-150H) Symbol Name Specifications Part No. Main switch* YE41104000000 Circuit breakers 25A 400V 3P YE40632500000 Excitation break away 220VAC-240VAC YE40000900000 Circuit breakers* 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00320000000 Contactors** 230V 50Hz YE00300000000 Contactors** 230V 50Hz...
  • Page 50 Table 2-15：Electrical Components List (PCB) (SDD-300U/450U-200H) Symbol Name Specifications Part No. Main switch* YE41104000000 Circuit breakers 25A 400V 3P YE40632500000 Excitation break away 220VAC-240VAC YE40000900000 Circuit breakers* 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00320000000 Contactors** 230V 50Hz YE00300000000 Contactors** 230V 50Hz...
  • Page 51 Table 2-16：Electrical Components List (PCB) (SDD-450U/600U-300H) Symbol Name Specifications Part No. Main switch* YE40636300000 Circuit breakers 40A 400V 3P YE40634000000 Excitation break away YE40000900000 Circuit breakers* 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00340000000 Contactors** 230V 50Hz YE00320000000 Contactors** 230V 50Hz...
  • Page 52 Table 2-17：Electrical Components List (PCB) (SDD-600U/750U-400H) Symbol Name Specifications Part No. Main switch* YE40636300000 Circuit breakers 50A 400V 3P YE40635000000 Excitation break away YE40000900000 Circuit breakers* 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00340000000 Contactors** 230V 50Hz YE00320000000 Contactors** 230V 50Hz...
  • Page 53 Table 2-18：Electrical Components List (PCB) (SDD-750U/900U-500H) Symbol Name Specifications Part No. Main switch* YE41109000000 Circuit breakers 63A 400V 3P YE40636300000 Excitation break away YE40000900000 Circuit breakers* 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00340000000 Contactors** 230V 50Hz YE00320000000 Contactors** 230V 50Hz...
  • Page 54 Table 2-19：Electrical Components List (PCB) (SDD-900U/1200U-700H) Symbol Name Specifications Part No. Main switch* 100A YE41110000000 Circuit breakers 63A 400V 3P YE40636300000 Excitation break away YE40000900000 Circuit breakers* 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00301000000 Contactors** 230V 50Hz YE00340000000 Contactors** 230V 50Hz YE00320000000 Contactors** 230V 50Hz...

  • Page 55: Main Circuit (Plc)

    2.8.7 Main Circuit (PLC) Picture 2-12：Main Circuit 1 (PLC) 55(136)
  • Page 56 Picture 2-13：Main Circuit 2 (PLC) 56(136)
  • Page 57 2.8.8 Control Circuit (PLC) Picture 2-14：Control Circuit (PLC) 57(136)
  • Page 58 2.8.9 Thermocouple Wiring Diagram (PLC) Picture 2-15：Thermocouple Wiring Diagram (PLC) 58(136)
  • Page 59 2.8.10 Components Layout (PLC) Picture 2-16：Components Layout (PLC) 59(136)
  • Page 60 2.8.11 Electrical Components List (PLC) Table 2-20：Electrical Components List (PLC) (SDD-20U/30H) SDD-20U/30H Symbol Name Specifications Part No. Main switch* YE10200300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40601600000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000...
  • Page 61 SDD-20U/30H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 1.8kW BH70160600150 Heater** 220-240V/380-415V 1.8kW BH70300300050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 62 Table 2-21：Electrical Components List (PLC) (SDD-40U/30H) SDD-40U/30H Symbol Name Specifications Part No. Main switch* YE10200300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40601600000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 63 SDD-40U/30H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 2.0kW BH70300300050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 64 Table 2-22：Electrical Components List (PLC) (SDD-40U/50H) SDD-40U/50H Symbol Name Specifications Part No. Main switch* YE10200300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40601600000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 65 SDD-40U/50H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 2.0kW BH70300300050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 66 Table 2-23：Electrical Components List (PLC) (SDD-80U/50H) SDD-80U/50H Symbol Name Specifications Part No. Main switch* YE10210300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40601600000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 67 SDD-80U/50H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 2.8kW BH70500300050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 68 Table 2-24：Electrical Components List (PLC) (SDD-120U/80H) SDD-120U/80H Symbol Name Specifications Part No. Main switch* YE10210300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40602000100 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 69 SDD-120U/80H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 3.5kW BH70800300050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 70 Table 2-25：Electrical Components List (PLC) (SDD-160U/80H) SDD-160U/80H Symbol Name Specifications Part No. Main switch* YE10210300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40602000100 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 71 SDD-160U/80H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 3.5kW BH70800300050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 72 Table 2-26：Electrical Components List (PLC) (SDD-160U/120H) SDD-160U/120H Symbol Name Specifications Part No. Main switch* YE10210300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40632500000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 73 SDD-160U/120H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 3.5kW BH70800300050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 74 Table 2-27：Electrical Components List (PLC) (SDD-230U/120H) SDD-230U/120H Symbol Name Specifications Part No. Main switch* YE10220300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40632500000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 75 SDD-230U/120H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 3.5kW BH70800300050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 76 Table 2-28：Electrical Components List (PLC) (SDD-230U/150H) SDD-230U/150H Symbol Name Specifications Part No. Main switch* YE10220300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40633200000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 77 SDD-230U/150H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 4.0kW BH70150400050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 78 Table 2-29：Electrical Components List (PLC) (SDD-300U/150H) SDD-300U/150H Symbol Name Specifications Part No. Main switch* YE10220300000 Circuit-breaker YE40000900000 Circuit-breaker* YE40634000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00341100000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 79 SDD-300U/150H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 3.5kW BH70150400050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 80 Table 2-30：Electrical Components List (PLC) (SDD-300U/200H) SDD-300U/200H Symbol Name Specifications Part No. Main switch* YE10250400000 Circuit-breaker YE40000900000 Circuit-breaker* YE40634000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00341100000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 81 SDD-300U/200H Symbol Name Specifications Part No. Blower** 220-240V/380-415V 1.9kW BM30042000050 Blower** 220-240V/380-415V 0.4kW BM30020500050 Motor* 200-240VAC 0.006 kW YM50616400100 Heater** 220-240V/380-415V 15kW BH70200400050 Heater** 220-240V/380-415V 5.4kW BH70451200150 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 82 Table 2-31：Electrical Components List (PLC) (SDD-450U/300H) SDD-450U/300H Symbol Name Specifications Part No. Main switch* YE10250400000 Circuit-breaker YE40303000000 Circuit-breaker* YE40305000000 Contactor** 230VAC 50Hz Contactor** 230VAC 50Hz YE00311000000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000 100-230VAC 50/60Hz...
  • Page 83 SDD-450U/300H Symbol Name Specifications Part No. Blower** 220-240V/380-415V 0.75kW BM30031000150 Motor* 200-240VAC 0.006 kW YM50616400100 Heater** 220-240V/380-415V 15kW BH70307200250 Heater** 220-240V/380-415V 7.2kW BH70601500150 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 84 Table 2-32：Electrical Components List (PLC) (SDD-600U/300H) SDD-600U/300H Symbol Name Specifications Part No. Main switch* YE10250400000 Circuit-breaker YE40000900000 Circuit-breaker* YE40636300000 Contactor** 230VAC 50Hz YE00351100100 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 85 SDD-600U/300H Symbol Name Specifications Part No. Blower** 220-240V/380-415V 0.75kW BM30031000150 Motor* 200-240VAC 0.006 kW YM50616400100 Heater** 220-240V/380-415V 18kW BH70307200250 Heater** 220-240V/380-415V 7.2kW BH70601500150 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 86 Table 2-33：Electrical Components List (PLC) (SDD-600U/400H) SDD-600U/400H Symbol Name Specifications Part No. Main switch* YE10250400000 Circuit-breaker YE40000900000 Circuit-breaker* YE40636300000 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00331100000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 87 SDD-600U/400H Symbol Name Specifications Part No. Blower** 220-240V/380-415V 0.75kW BM30031000150 Motor* 200-240VAC 0.015 kW YM50616400100 Heater** 220-240V/380-415V 18kW BH70100000050 Heater** 220-240V/380-415V 7.2kW BH70601500150 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 88 Table 2-34：Electrical Components List (PLC) (SDD-750U/400H) SDD-750U/400H Symbol Name Specifications Part No. Main switch* YE10250400000 Circuit-breaker YE40000900000 Circuit-breaker* YE40636300000 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00331100000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 89 SDD-750U/400H Symbol Name Specifications Part No. Blower** 220-240V/380-415V 0.75kW BM30031000150 Motor* 200-240VAC 0.015 kW YM50616400100 Heater** 220-240V/380-415V 18kW BH70100000050 Heater** 220-240V/380-415V 7.2kW BH70751800150 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 90 Table 2-35：Electrical Components List (PLC) (SDD-750U/500H) SDD-750U/500H Symbol Name Specifications Part No. Main switch* YE40601500000 Circuit-breaker YE40000900000 Circuit-breaker* YE40636300000 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00331100000 Contactor** 230VAC 50Hz YE00331100000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 91 SDD-750U/500H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 10.5kW BH70902100150 Heater** 220-240V/380-415V 10kW BH70501000050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 92 Table 2-36：Electrical Components List (PLC) (SDD-900U/500H) SDD-900U/500H Symbol Name Specifications Part No. Main switch* YE40601500000 Circuit-breaker YE40000900000 Circuit-breaker* YE40636300000 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00331100000 Contactor** 230VAC 50Hz YE00331100000 Contactor** 230VAC 50Hz YE00301000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 93 SDD-900U/500H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 10.5kW BH70902100150 Heater** 220-240V/380-415V 10kW BH70501000050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 94 Table 2-37：Electrical Components List (PLC) (SDD-900U/700H) SDD-900U/700H Symbol Name Specifications Part No. Main switch* YE40601500000 Circuit-breaker YE40636300000 Circuit-breaker* YE40602500000 Contactor** 230VAC 50Hz YE00320000000 Contactor** 230VAC 50Hz YE00330000000 Contactor** 230VAC 50Hz YE00330000000 Contactor** 230VAC 50Hz YE00330000000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A YE03270700000...
  • Page 95 SDD-900U/700H Symbol Name Specifications Part No. Heater** 220-240V/380-415V 1.5kW BM30042000050 Heater** 200-240VAC 0.015 kW YM50616400100 Main switch* 220-240V/380-415V 12kW BH70122400150 Circuit-breaker 220-240V/380-415V 10kW BH70501000050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 96 Table 2-38：Electrical Components List (PLC) (SDD-1200U/700H) SDD-1200U/700H Symbol Name Specifications Part No. Main switch* 100A YE40601500000 Circuit-breaker YE40636300000 Circuit-breaker* YE40602500000 Contactor** 230VAC 50Hz YE00321100000 Contactor** 230VAC 50Hz YE00301000000 Contactor** 230VAC 50Hz YE00341100000 Contactor** 230VAC 50Hz YE00331100000 Phase protector 230VAC 50Hz YE03103800000 Relay 230VAC 50Hz 12A...
  • Page 97 SDD-1200U/700H Symbol Name Specifications Part No. Blower** 220-240V/380-415V 1.5kW BM30042000050 Motor* 200-240VAC 0.015 kW YM50616400100 Heater** 220-240V/380-415V 12kW BH70122400150 Heater** 220-240V/380-415V 10kW BH70501000050 * means possible broken parts. ** means easy broken part. and spare backup is suggested. Please confirm the version of manual before placing the purchase order to guarantee that the item number of the spare part is in accordance with the real object.
  • Page 98 2.8.12 Main Electrical Components Description Overload Relay At delivery, the overload relay is set for manual reset. (the reset button pointing to H). Manually reset the relay at the tripping of the switch. When motor overload occurs, stop the machine, then check and solve the problem. After that open the door of control box, press down the reset button of overload relay (if you can not press down the reset button, wait for one minute.) ⑥...

  • Page 99: Operation Procedures

    2.9 Operation Procedures Before connecting electrical power source, the main power switch must be turned to OFF position. After the machine connected with power source, turn the main power switch to ON position. According to your applications, operate drying and loading system respectively. 2.9.1 Operation Regulations Picture 2-18：Operation Regulations 1) Do not use keen-edged object instead of hands to operate the touch screen,...
  • Page 100 Picture 2-19：Description of Touch Screen A：Display B：Touch panel C：LED status indicator 2.9.3 Touch Panel Appear Error Table 2-39：Touch panel information XBT GT State indicator light Green (light) Work welled Orange (light) Backlight lamp burning Orange (shine) During software startup Red (light) Power status No shine Power break off...
  • Page 101 Picture 2-20：Screen Operation Flow Table 4. Explanation of the Menus 1) Initial menu Please refer to the following initial menu. Press “English” or “Chinese” to select a language. Then enter drying process menu. Picture 2-21：System Default System 101(136)
  • Page 102 2) Drying process menu. Drying process menu as shown below: Drying process switch Title bar Drying hopper 1 setting key Process blower indicator Th e actual value of the drying hopper 1 Re generating blower indica tor Drying hopper 2 setting key Process heater 1 indicator Th e actual value of...
  • Page 103 Press this button to enter help menu. 3) Temperature parameters menu Touch parameter setting button. Input user name: Shini, Input passwords 3588 Press "ENTER" button to confirm, and then "RETURN" key Return " dry monitor screen." Again by "parameter settings" button, you can enter the parameter settings.
  • Page 104 Picture 2-24：Temperature Parameters Setting 2 A. Process temp. Parameters setting Touch Process PID. , then the following menu appears. It includes proportion, integral, and derivative time. Picture 2-25：Process temp. Parameters setting 1 When need to change one of the parameters, touch corresponding area, then a keypad appears.
  • Page 105 Picture 2-26：Process temp. Parameters setting 2 Max. and Min. on the key-pad shows the Max. and Min. value of current parameter. If it is out of the limits, input value could not be confirmed by pressing ENTER. If the system can not control the temp. Accurately, reset P.I.D parameters to gain more accurate temperature control.
  • Page 106 Table 2-42：Adjustment of Differential Time (D) B. Regenerating temp. Setting Refer to the same setting procedures as for the "Process Temperature Control Parameter" by touching the Regen. P.I.D. 4) Rotor Speed Setting By touching Rotor Parameter button at the button of Parameter Setting screen. The rotor speed parameter setting screen prompts as shown below: In SV field, can set "Rotor Speed Motoring Time".
  • Page 107 Picture 2-28：Time Setting Note！ The screen shows time 1 auto-start time only when delayed start-up function is enabled, and the screen shows time 2 extended cooling time only when the system is turned off. Picture 2-29：Time Setting 2 Touch parameter setting menu. A numeric keypad will appears. Input each parameter and then press OK, a new setting come into effect.
  • Page 108 Picture 2-30：Alarm Fault Records 1. When alarm fault records are more than displaying space, by touching "Up" or "Down" keys to review more records. 2. Touching record content, a help message is prompted. According to help message, the operator could get the troubleshooting information. 3.
  • Page 109 Alarm message Results Possible reasons Dryer and dehumidifier stop working, Return air over-heat Cooling water circulation problems. and flickering of red alarm light. Thermocouple is not connected or Drying thermocouple Dryer and dehumidifier stop working, poor connection or wrongly break and flickering of red alarm light.
  • Page 110 7) Help menu Touch the help button to enter help menu. Press relative button to display details of each item. Picture 2-31：Help menu Press on the temp. controller for at least 3 seconds to enter into initial setting screen. Press until it displays SL-H（temp.
  • Page 111 2.9.4 Dew-point Monitor 1. Embedded Dew-point Monitor Picture 2-32：Embedded Dew-point Monitor 2. Detachable Dew-point Monitor Picture 2-33：Detachable Dew-point Monitor 111(136)

  • Page 112: Installation Testing

    3. Installation Testing 3.1 Attention 1) Make sure voltage and frequency of the power source comply with those indicated on the manufacturer nameplate, which is attached to the machine. 2) Power cable and earth connections should conform to your local regulations. 3) Use independent power cable and ON/OFF switch.
  • Page 113 3.2 Honeycomb-rotor 3.2.1 What is Honeycomb-rotor The main body of the honeycomb-rotor is a honeycomb, made by ceramic fibre and organic additives, sintered under high temperature with molecular sieve and silica gel, to be strongly bonded together and form a solid and hard surface. Not like common molecular sieve, which will produce dusts and fines to pollute raw materials when aging or become saturated requiring regular replacement, honeycomb-rotor offer unlimited long life and can be cleaned when it is polluted.

  • Page 114: Heater Assemblies

    9) Install both the transmission belt (Fig. 13) and belt tension regulator (Fig. 14). 10) Install micro-switch and fixed board firmly (Fig. 10). Picture 3-3：Installation of the Rotor 3.3 Heater Assemblies 1) Install the heating pipe in the heater. 2) Fix the heater into the housing. (See right picture) Warning! Hot surfaces could burn hands.
  • Page 115 Picture 3-4：Heater Assemblies 3.3.1 EGO The EGO value has been setting before out factory, Don't modify it. Picture 3-5：EGO 115(136)

  • Page 116: Control Panel

    4. Operating 4.1 Control Panel Picture 4-1：Control Panel Table 4-1：Control Panel Table Name Function description Remarks Green light on indicates Indicates the working status of blower working status Running indicating and heater Green light off indicates stop status Red light on indicates fault Fault indicating Indicates current alarm message occurs...

  • Page 117: Panel Operation

    4.2 Panel Operation 1) Open the main switch. 2) Press "RUN/STOP" key to start loading. 4.3 Temperature Setup 1) The setup number will flicker after pressing "SET" key, add or decrease temperature by pressing key. 2) Press "ENTER" key to confirm the input value. 4.4 PID Auto-tuning Setting 1) Press “SET”...
  • Page 118 stop time. Press key to add or decrease time value of "SV/setup value". Each press of can add or decrease 15 mins set time. 3) Press "ENTER" to confirm the input time value and enter into "0-OFF" time setup items, then repeat step 2. Picture 4-3：Intermittent running setup 2 Note：If set 0-ON as 04:00, 0-OFF as 05:00, which means drying periods is 4 hours stop time is 5 hours，then working for 4 hours and being stopped...
  • Page 119 Picture 4-5：Weekly Time Start Setup 1 2) Press key to add or decrease the time value in "SV/setup value " from "1-OFF" . Press "ENTER" to confirm the input value and comes into the time setup items of "2-ON""TUE-ON". Picture 4-6：Weekly Time Start Setup 2 3) Do the same setup again and again to setup the ON/OFF time from Monday to Sunday.
  • Page 120 1. F-20 functions as an password lock，hold on"SET"till the"PV"displays F-20. 2. Press key and only after input 0021 in the SV，can you press "ENTER"to come into F-03 and other settings，so F-20 functions as an passwordlock for entering into next parameters setup, which prevents the modification from unprofessionals.
  • Page 121 4.7 Present Time Modification 1) Repeat the above steps until PV displays "TIME" to stand for present time. 2) Press key to add or decrease time. 3) Press "ENTER" key and PV displays "DAY" to stand for week days. 4) Press key to add or decrease days.
  • Page 122 delivery. 4. F-09 stands for differential time of heating side (D); it is a preset value before delivery. 5. F-10 stands for switch cycle of heating side; its preset value is 15 sec. 6. F-16 stands for power deliver delay time of heater, it is adjustable, the unit is Sec..
  • Page 123 Picture 4-10：Hole Site 2) Check if there are complete parts for dewpoint monitor including: Dew-point monitor Dew-point transmitter assembly (dew-point detector, detection cable, washer and installation guide) Copper joint, installation seat for dew-point monitor Picture 4-11：Parts of Dew-point Monitor 3) Dismantle the copper joint of original machine and replace it with installation seat for dew-point monitor.
  • Page 124 Picture 4-12：Copper Joint Assembly of Original Machine Picture 4-13：Installation Seat 4) Install dew-point transmitter assembly to copper joint. Picture 4-14：Installation for Transmitter 5) Connect signal wire. Particular shape of signal wire joint would avoid the wrong insert and connection. 124(136)
  • Page 125 Picture 4-15：Connection of Signal Wire 6) Match dew-point monitor with holes on the panel and fix the installation. Picture 4-16：Installation for Dew-point Monitor 7) Connect signal wires of the transmitter and power lines of dew-point monitor with the according terminals. Connet contact No.1 and No.2 with power, supply is 220VAC.
  • Page 126 Picture 4-17：Connection of Dew-point Monitor 126(136)

  • Page 127: Troubleshooting

    5. Trouble-shooting Symptom Possible causes Actions taken 1. Does not connect through power 1. Connect through power supply. Main power supply. 2. Replace main power switch. indicator does not 2. Main power switch problems. 3. Check electrical wires. shine after turn on 3.
  • Page 128 6. Maintenance and Repair 6.1 Honeycomb-rotor 6.1.1 H Model of Honeycomb-rotor (Final material moisture content can be as low as 0.004% or less) 1) Put the rotor in a ventilated space and let it cold down to normal temperature naturally. 2) Use compressed air to clean the dust inside the rotor.
  • Page 129 6.2 Filter Please periodically clean the dust on the air filters, once per week. Cleaning steps： 1) Take out the air filter carefully. 2) Blow off the dust on the air filter screen and the cover with pressure air. 3) Wipe off the barrel wall of air filter with dishcloth. 4) After cleaning, place all parts in reversed order carefully.
  • Page 130 6.3 Cooler Clear Step 1) Disassemble the cooler's pipe and screw, and remove the cooler out of the chiller. 2) Release the fixed screw on the upper and lower cover of cooler and disassemble the cover. 3) Use brushes, compress ed air or low pressure water to clean the dust and sundries on the cooler fan and copper pipe.

  • Page 131: Maintenance Schedule

    6.4 Maintenance Schedule 6.4.1 General Machine Information Model Manufacture date Voltage Ф Frequency Power 6.4.2 Check After Installation Check that the conveying pipes are tightly locked. Check that the material clearance door is firmly closed. Check that the conveying pipes are correctly connected. Check if there are damages of honeycomb-rotor.

  • Page 132: Daily Checking

    6.4.3 Daily Checking Check the switch of the machine. Check the switch of the machine. Check auto start-up of the machine. Check auto start-up of the machine. Check the switch of the machine. Check the switch of the machine. Check auto start-up of the machine. Check auto start-up of the machine.

  • Page 133: Weekly Checking

    6.4.4 Weekly Checking Check the switches of the machine Check all the electrical wires Check if there are loose electrical connections Check and clean air filter Check and maintain compressed-air filter and regulator Check solenoid valve Check motor overload relay and anti-phase function Check the switches of the machine Check all the electrical wires Check if there are loose electrical connections...
  • Page 134 Check the switches of the machine Check all the electrical wires Check if there are loose electrical connections Check and clean air filter Check and maintain compressed-air filter and regulator Check solenoid valve Check motor overload relay and anti-phase function Check the switches of the machine Check all the electrical wires Check if there are loose electrical connections...

  • Page 135: Monthly Checking

    6.4.5 Monthly Checking Check if transmission belt is loose or not Check the status of gear motor performance Check if there is leakage in the rotor Check if transmission belt is loose or not Check the status of gear motor performance Check if there is leakage in the rotor Check if transmission belt is loose or not Check the status of gear motor performance...

  • Page 136: Half-Yearly Checking

    6.4.6 Half-yearly Checking Check if there are damages of conveying pipe Check the pipe heater Check regenerating/conveying blower and fans of the motor Check if there are damages of conveying pipe Check the pipe heater Check regenerating/conveying blower and fans of the motor Check if there are damages of conveying pipe Check the pipe heater Check regenerating/conveying blower and fans of the motor...
