- Page 1 Assembly Instructions Seminar Tables with 4-Wire Power System January 2023...
- Page 2 125 PSF. Note: If any other flooring types exist that are Note: KI is not responisble not shown, please provide you KI contact for how flooring is secured. with the detailed floor specifications. See applied loads.
- Page 3 Note: Warranty null and void if • ” Hilti KH-EZ x 2 ” • Tape measure KI product is installed on flooring • Max torque: 18 ft/lbs • C-clamps not meeting minimum structural • Four screw assemblies required •...
- Page 4 All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury. Seminar Table Base & Top Installation Note: When installing Seminar Tables equipped with the...
- Page 5 (not included). Locate base over pre-drilled holes and drive in (do not tighten) mounting fasteners. Shim Seminar Table Base & Top under base flange with steel Installation (cont.) washer(s) as needed to level or 3. Refer to the space-planning layout compensate for floor variances.
- Page 6 Failure to assemble properly, or to secure parts electrically connected furnishings must may result in assembly failure and personal injury. also be mechanically connected. Seminar Table Base & Top 9. Per the space-planning layout, Installation (cont.) secure the required number of / ”...
- Page 7 All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury. Seminar Table Base & Top tabletop Installation (cont.) 10. With tabletops joined together...
- Page 8 Seminar Tables with 4-Wire Power System - Receptacles Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 9 Seminar Tables with 4-Wire Power System - Single-Direction Power Infeed & Jumpers Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 10 Seminar Tables with 4-Wire Power System - Single-Direction Receptacle Hub Shrouds Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 11 Seminar Tables with 4-Wire Power System - Two-Direction Power Infeed & Jumpers Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 12 Seminar Tables with 4-Wire Power System - Two-Direction Receptacle Hub Shrouds Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 13 All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury. Seminar Tables with 4-Wire Power System (cont.) receptacle hub Note: 4-Wire Power System jumper...
- Page 14 Seminar Tables with 4-Wire Power System - Power Modules Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 15 Seminar Tables with 4-Wire Power System - Power Modules Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 16 Seminar Tables with 4-Wire Power System - Power Modules Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 17 Seminar Tables with 4-Wire Power System - Excess Cord Covers Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 18 Seminar Tables with 4-Wire Power System - Power Infeed Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 19 Seminar Tables with 4-Wire Power System - Modesty Panels Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 20 Seminar Tables with 4-Wire Power System - Modesty Panels Assembly Instructions tabletop Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
- Page 21 Seminar Tables with 4-Wire Power System - Modesty Panels modesty panel Assembly Instructions modesty panel #10 x / ” bracket screws (12.0110.XX) #14 x 1” #10-24 keps nut screws (12.0023.TM) (12.0275) Assemble units as described herein only. To do otherwise may result in instability.
- Page 22 Seminar Tables with 4-Wire Power System - Modesty Panels Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 23 Seminar Tables with 4-Wire Power System - Modesty Panels Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
- Page 24 Failure to assemble properly, or to secure parts may result in assembly failure and personal injury. Specifying Power on Seminar Tables Specifics of the 4-wire system - 4-wire, 2 circuit system includes: WARNING: Risk of fire or electrical shock.
- Page 25 Seminar Tables with 4-Wire Power System Assembly Instructions...
- Page 26 Seminar Tables with 4-Wire Power System Assembly Instructions...
- Page 27 Seminar Tables with 4-Wire Power System Assembly Instructions...
- Page 28 1330 Bellevue Street P .O. Box 8100 Green Bay, Wisconsin 54308-8100 1-800-424-2432 www.ki.com KI is a registered trademark of Krueger International, Inc. © 2023 Krueger International, Inc. All Rights Reserved Code KI-AI-000073R2/KI/PDF/0123...
