Razer NARI ULTIMATE - Gaming Headset for XBOX ONE Manual

WHAT'S INSIDE / WHAT'S NEEDED

WHAT'S INSIDE

• Razer Nari Ultimate for Xbox One gaming headset
• 3 m Charging cable
• Important Product Information Guide

WHAT'S NEEDED

• Xbox One / Xbox One S / Xbox One X
• PC(Windows 10 or higher)*

*May require Xbox Wireless Adapter for Windows 10 (not included)

SAFETY STATEMENT
Before using the Xbox One with this product, read the Xbox One instruction manual for safety, health, and other information regarding the use of the Xbox One.

LET'S GET YOU COVERED

You've got a great device in your hands, complete with a 2-year limited warranty coverage. Now maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com

Your product's serial number can be found underneath the ear cushion, as shown here.

Got a question? Ask the Razer Support Team at support.razer.com

TECHNICAL SPECIFICATIONS

AT-A-GLANCE

• Razer HyperSense with Intensity Adjuster
• Direct Xbox One Wireless Connectivity
• Cooling Gel-Infused Cushions
• Auto-Adjusting Headband with Swiveling Earcups
• Game/Chat Balance

HEADPHONES

• Frequency response: 20 Hz - 20 kHz
• Impedance: 32Ω at 1 kHz
• Sensitivity: 108 dB
• Drivers: 50 mm, with Neodymium magnets
• Inner ear cup diameter: Width 56 mm / Length 67 mm
• Oval ear cushions: Designed for full-ear coverage with cooling gel, perfect for long-wearing comfort
• Connection type: Direct to Xbox / Via Xbox Wireless Adapter for Windows 10
• Wireless range: 10 m / 30 ft
• Wireless frequency: 2.4 GHz / 5 GHz
• Battery life: 6 hours with lighting and HyperSense / 20 hours without HyperSense

MICROPHONE

• Frequency response: 100 Hz -10 kHz
• Signal-to-noise ratio: ≥ 60 dB
• Sensitivity (@1 kHz): -54 ± 3 dB
• Pick-up pattern: Unidirectional

LOFELT HAPTIC DRIVERS

• 1 in each ear cup
• Frequency Response: 20 - 200 Hz
• Maximum Generated Force: 4.3 G

COMPATIBILITY

• Wireless: Direct to Xbox One, PC with Microsoft Wireless Adapter for Windows 10

EXPLORING YOUR PRODUCT

1. Auto-adjusting headband
2. Cooling gel-infused ear cushions
3. 50mm drivers with HyperSense Technology
4. Razer logo backlighting
5. Mic mute indicator
6. Retractable mic
7. Slider switch
   1. HyperSense Intensity
   2. Audio volume
8. Intensity / volume control
9. Charging port
10. Power button
11. Status indicator
12. Game/Chat balance
13. Charging cable

SETTING UP YOUR DEVICE

CHARGING YOUR UNIT

Connect your Razer Nari Ultimate for Xbox One to a powered USB port using the charging cable.

For best results, please fully charge the headset before using it for the first time. A depleted unit will fully charge in about 4 hours.

Understanding the Status Indicator
The status indicator on the headset will send out notifications depending on its current battery or charging status.

LED NOTIFICATION	SOUND	STATUS
Static red	None	Charging
Static green	None	Fully charged
Slow blinking red	Warning tone	Battery is low (25%)
Rapid blinking red	Warning tone	Battery is critically low (10%)

PAIRING YOUR UNIT TO YOUR XBOX ONEZ

Make sure to power on your Xbox One and log into your Xbox Live account before connecting your Razer Nari Ultimate for Xbox One.

1. Press the connect button on your console.

2. While in power off state, press and hold the headset power button until the Razer logo starts blinking rapidly.

3. Wait until the Razer logo becomes static green to notify that the headset is paired.


NOTIFICATION	STATUS
Blinking slowly	Connecting
Blinking rapidly	Pairing
Static	Connected/Paired

PAIRING YOUR UNIT TO YOUR PC

Make sure that your Xbox WirelessAdapter for Windows 10is up-to-date Some systems have Xbox Wireless built in which allows you to pair your headset by using Add a devicein Settings.

1. Connect your Xbox Wireless Adapter for Windows* to your PC,and then press the connect button.

2. While in power off state, press and hold the headset power button until the Razer logo starts blinking rapidly.

3. Wait until the Razer logo becomes static green to notify that the headset is paired.


NOTIFICATION	STATUS
Blinking slowly	Connecting
Blinking rapidly	Pairing
Static	Connected/ Paired

USING YOUR DEVICE

POWER ON

Press and hold the head set power button until you hear the ON tone, the status indicator until the Razer logo starts blinking slowly.

POWER OFF

Press and hold the head set power button until you hear the OFF tone, the status indicator until the Razer logo is turned off.

ENABLING/DISABLING THE RAZER LOGO LIGHTING

Press the headset power button to enable or disable the Razer logo lighting.

ADJUSTING THE HYPERSENSE INTENSITY / AUDIO VOLUME

Use the Slider switch to determine whether you'll be adjusting the HyperSense Intensity ( ) or the audio volume ( ) setting of your headset.

With the preferred setting selected in the Slider switch, rotate the Intensity / volume control to increase or decrease the selected setting.

Press the Intensity/volume control to mute or unmute the selected setting.

USING THE GAME/CHAT BALANCE CONTROL

Rotate the Game/Chat balance control to increase the in-game volume and decrease the voice chat volume or vice versa. By default, the notch on the wheel is set to the middle to indicate 50% chat and 50% game volume.

USING THE RETRACTABLE MIC

Pull the tip of the mic until it is fully extended.

Bend the mic until it is parallel to your mouth, then adjust the length as preferred. Make sure the mic diaphragm is in front and the air vent is facing away from your mouth.

Press the Game/Chat balance to mute or unmute the mic. The mic mute indicator will light up when muted.

Press and hold the Game/Chat balance until you hear a tone to enable or disable mic monitoring.

EXTENDING YOUR PRODUCT'S LIFESPAN

We recommend stretching the headset gently apart before placing them over your head to minimize headband stress. However, please avoid overstretching the headset beyond its technical limits.

SAFETY AND MAINTENANCE

SAFETY GUIDELINES

In order to achieve maximum safety while using your Razer Nari Ultimate for Xbox One, we suggest that you adopt the following guidelines:
Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to support.razer.com for assistance.
Do not take apart the device (doing so will void your warranty) and do not attempt to operate it under abnormal current loads.
Keep the device away from liquid, humidity or moisture. Operate the device only within the specific temperature range of 0°C(32°F) to 40°C (104°F).Should the temperature exceed this range, unplug and/or switch off the device in order to let the temperature stabilize to an optimal level.
The device isolates external ambient sounds even at low volumes, resulting in lowered awareness of your external surroundings. Please remove the device when engaging in any activities that requires active awareness of your surroundings.
Listening to excessively loud volumes over extended periods of time can damage your hearing. Furthermore, legislation of certain countries permits a maximum sound level of 86dB to affect your hearing for 8 hours a day. We therefore recommend that you reduce the volume to a comfortable level when listening for prolonged periods of time. Please, take good care of your hearing.

MAINTENANCE AND USE

The Razer Nari Ultimate for Xbox One requires minimum maintenance to keep it in optimum condition. Once a month we recommend you power off or unplug the device from the computer and clean it using a soft cloth or cotton swab to prevent dirt buildup. Do not use soap or harsh cleaning agents.
