Razer THRESHER Manual

INTRODUCTION

The Razer Thresher for Xbox One is the complete dongle-free wireless audio solution. On top of delivering lag-free audio immersion, this premium headset also focuses on undisputable comfort. Lined with leatherette, the lightweight memory foam ear cushions rest perfectly against your head, giving you a natural feel that is second to none, The in-built quick control buttons and a retractable digital microphone provide you with instant access to game and voice balance as well as volume even in the heat of battle.

PACKAGE CONTENTS / SYSTEM REQUIREMENTS

PACKAGE CONTENTS

• Razer Thresher gaming headset for Xbox One
• USB to Micro-USB cable
• Important Product Information Guide

SYSTEM REQUIREMENTS

• Xbox One / Xbox One S / Xbox One X
  OR
• PC(Windows 10 or higher)*

*May require Xbox Wireless Adapter for Windows (not included)

SAFETY STATEMENT
Before using the Xbox One with this product, read the Xbox One instruction manual for safety, health, and other information regarding the use of the Xbox One.

REGISTRATION / TECHNICAL SUPPORT

REGISTRATION
Register your product online at razerzone.com/registration for real-time information on your product's warranty.
If you don't have a Razer ID yet, register now at razerzone.com/razer-id for access to a wide range of Razer benefits.

TECHNICAL SUPPORT

• 1 year limited manufacturer's warranty
• Free online technical support at razersupport.com

DEVICE LAYOUT

1. Adjustable padded headband
2. Circumaural, leatherette ear cushions
3. Microphone LED
4. Retractable microphone
5. Razer logo backlighting
6. LED indicator
7. Headset power button
8. Micro-USB charging port
9. Game/chat balance control
10. Audio volume control
11. USB to Micro-USB cable

SETTING UP YOUR DEVICE

PAIRING YOUR UNIT TO YOUR XBOX ONE

Note: Make sure to power on your Xbox One and log into your Xbox Live account before connecting your Razer Thresher.

1. Press the connect button on your console.

2. While in power off state, press and hold the headset power button until the Razer logo starts blinking rapidly.

3. Wait until the Razer logo becomes static green to notify that the headset is paired.


PAIRING YOUR UNIT TO YOUR PC

Note: Make sure that your Xbox WirelessAdapter for Windows is up-to-date. Somesystems have Xbox Wirelessbuilt in which allows vou to pair your headset bv using Add a device in Settings.

1. Connect your Xbox Wireless Adapter for Windows* to your PC,and then press the connect button.

2. While in power off state, press and hold the headset power button until the Razer logo starts blinking.

3. Wait until the Razer logo becomes static green to notify that the headset is paired.


DEVICE NOTIFICATIONS

The headset will display notifications depending on its current status, as shown here:

NOTIFICATION	STATUS
Blinking slowly	Connecting
Blinking rapidly	Pairing
Static	Connected/Paired

USING YOUR DEVICE

CHARGING YOUR UNIT

Plug your Razer Thresher to a powered USB port using the Micro-USB to USB cable.

For best results, please fully charge the headset before using it for the first time. A depleted unit will fully charge in about 4 hours.

Understanding The Charging Notifications
The LED indicator on the headset will send out notifications depending on its current charging status, as shown here:

LED NOTIFICATION	SOUND NOTIFICATION	STATUS
Static red	None	Charging
Static green	None	Charged
Blinking red	Warning tone	Low battery

POWER ON

Press and hold the headset power button until you hear the ON tone, the LED indicator is lit, or until the Razer logo starts blinking slowly.

POWER OFF

Press and hold the headset power button until you hear the OFF tone, the LED indicator is off, or until the Razer logo is turned off.

USING THE AUDIO VOLUME CONTROL

Rotate the audio volume control to increase or decrease the volume. You will hear a short beep when you reach the minimum or maximum volume.

Press the audio mute button to mute or unmute the in-game audio.

USING THE RETRACTABLE MICROPHONE

Pull the tip of the microphone until it is fully extended.

Bend the microphone until it is in front of your mouth, then adjust the length as preferred.

USING THE GAME/CHAT BALANCE CONTROL

Rotate the game/chat balance control to increase the in-game volume and decrease the voice chat volume or vice versa. You will hear a short beep when you reach the maximum for either the ingame or voice chat volume.

Press the game/chat balance control to mute or unmute the microphone. The microphone LED will light up when muted.

Press and hold the mic volume button until you hear a tone to enable or disable mic monitoring.

EXTENDING YOUR PRODUCT'S LIFESPAN

We recommend stretching the headset gently apart before placing them over your head to minimize headband stress. However, please avoid overstretching the headset beyond its technical limits.

SAFETY AND MAINTENANCE

SAFETY GUIDELINES

In order to achieve maximum safety while using your Razer Thresher, we suggest that you adopt the following guidelines:
Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to razersupport.com for support. Do not attempt to service or fix the device yourself at any time.
Do not take apart the device (doing so will void your warranty) and do not attempt to operate it under abnormal current loads.
Keep the device away from liquid, humidity or moisture. Operate the device only within the specific temperature range of 0°(32°F) to 40°C (104°F).Should the temperature exceed this range, unplug and/or switch off the device in order to let the temperature stabilize to an optimal level.
The device isolates external ambient sounds even at low volumes, resulting in lowered awareness of your external surroundings. Please remove the device when engaging in any activity that requires active awareness of your surroundings.
Listening to excessively loud volume over an extended period of time can damage your hearing. Furthermore, legislation of certain countries permits only a maximum sound level of 86db for 8 hours a day. We therefore recommend that you reduce the volume to a comfortable level when listening for prolonged periods of time. Please, take good care of your hearing.

MAINTENANCE AND USE

The Razer Thresher requires minimum maintenance to keep it in optimum condition. Once a month we recommend you unplug the device from the computer and clean it using a soft cloth or cotton swab to prevent dirt buildup. Do not use soap or harsh cleaning agents.

Documents / Resources

References

• Razer ID
• http://razersupport.com

Download manual

Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.

Download Razer THRESHER Manual
