- Page 1 PANTHER EX Installation, use and maintenance Manuale di Installazione, uso e manutenzione Installazione, uso e manutenzione Installation, use and maintenance manual BULLETIN M0709 EN_ BULLETIN M0725 ITEN_...
- Page 2 Installation, use and maintenance ENGLISH Bulletin M0725 24 / 48 24 / 48 M0725...
-
Page 3: Table Of Contents
PROBLEMS AND SOLUTIONS DEMOLITION AND DISPOSAL DIMENSIONS AND EXPLODED VIEWS 17.1 FEET ASSEMBLY EXPLODED VIEW (where required by model). 25 / 48 25 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. -
Page 4: Machine And Manufacturer Identification
Installation, use and maintenance MACHINE AND MANUFACTURER IDENTIFICATION ELECTRIC FUEL PUMP Suzzara (MN) TYPE PANTHER EX 56 Italy EX db h IIA T4 Gb L.N. 09488 II 2G IECEx ULD 24.0012 X Date UL 24 ATEX 3210 X 230 V 50 Hz 2.3 A... -
Page 5: Conformity
27 / 48 27 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. -
Page 6: Ignition Hazards And Protective Means Implemented
Installation, use and maintenance ZONE 22 Place where it is improbable that an explosive atmosphere, in the form of a cloud of combustible powders in the air, occurs during normal operation but which, if it does occur, only persists for a short time. Note: This zone can comprise, among others, places near appliances, protection systems and components containing powder, out of which the powder may leak with the formation of powder deposits (e.g., milling salt, where the powder comes... -
Page 7: Intended Use
The pumps are carefully packed before dispatch. Check the packing when receiving the material and store in a dry place. 29 / 48 29 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. -
Page 8: General Warnings
This manual belongs to Piusi S.p.A., which is the sole proprietor of all Reproduction rights indicated by applicable laws, including, by way of example, laws rights on copyrights. -
Page 9: First Aid Rules
To prevent electric shock and detonation of sparks, the entire pumping system must have proper grounding, including tank and any accessories. 31 / 48 31 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. - Page 10 Installation, use and maintenance Enforce regulations for electrical installation. WARNING All wiring and electrical connections must be performed by authorized and suitably trained personnel. Never touch the electric plug or socket with wet hands. Do not switch the dispensing system on if the network connection cable or important parts of the apparatus are damaged, such as the inlet/outlet pipe, nozzle or safety devices.
-
Page 11: Technical Data
The temperature limits shown apply to the pump components and must be respected to avoid possible damage or malfunction. 33 / 48 33 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. -
Page 12: Electrical Power Supply
Installation, use and maintenance ELECTRICAL POWER SUPPLY NOTE The pump must be powered by AC line, the nominal values of which are indicated on the table in the paragraph "TECHNICAL DATA". The maximum acceptable variations from the electrical parameters are: Voltage: +/- 5% of the nominal value Frequency: +/- 2% of the nominal value WARNING... -
Page 13: Installation
To maximise performance and prevent damage that could affect pump operation, always demand original accessories. 35 / 48 35 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. -
Page 14: Notes On Suction And Delivery Lines
Installation, use and maintenance NOTES ON SUCTION AND DELIVERY LINES DELIVERY The selection of the pump model must be made taking into account the characteristics of the system. The combination of: the length of the pipe, the diameter of the pipe, the flow rate, as well as the accessories installed, could create back pressures that are greater than the maximum predicted pressure, thereby causing the pump's electronic controls to intervene and reducing the dispensed flow considerably. -
Page 15: Connections
Failure to observe the above mentioned rules can cause serious accidents. Always provide a disconnect switch upstream of the electrical system. 37 / 48 37 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. - Page 16 Installation, use and maintenance CONNECTION DIAGRAM RIGID CONDUIT MOTOR 3/4” - 14 NPT CABLE NO. COLOUR SECTION CABLE GROUP Green 16 AWG (1.5 mm) Power Supply White 16 AWG (1.5 mm) Cable Black 16 AWG (1.5 mm) Black 18 AWG (1 mm) MOT (L) MOTOR Motor Cable...
-
Page 17: 10.2 Piping Connections
- that the delivery back pressure does not exceed the maximum back pressure for the pump. 39 / 48 39 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. -
Page 18: Everyday Use
Installation, use and maintenance EVERYDAY USE If flexible pipes are used, attach the ends of the pipings to the tanks. In the PROCEDURE absence of an appropriate slot, solidly grasp the delivery pipe before beginning dispensing. Before starting the pump make sure that the delivery valve is closed (dispensing nozzle or line valve). -
Page 19: Maintenance
Under normal operating conditions, noise emission of all models does not exceed 74 dB at a distance of 1 m from the electric pump. 41 / 48 41 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. -
Page 20: Problems And Solutions
Installation, use and maintenance PROBLEMS AND SOLUTIONS For any problems contact the authorized dealer nearest to you. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Lack of electric power. Check the electrical connections and the safety systems. THE MOTOR IS Rotor jammed. Check possible damage NOT TURNING... -
Page 21: Demolition And Disposal
Other components, such as pipes, rubber gaskets, plastic parts and wires, must be miscellaneous disposed of by companies specializing in the disposal of industrial waste. parts 43 / 48 43 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. -
Page 22: Dimensions And Exploded Views
Installation, use and maintenance DIMENSIONS AND EXPLODED VIEWS N.4 M6 SCREWS CLASS 8.8 (ISO 898-1) 44 / 48 44 / 48 M0725... -
Page 23: Feet Assembly Exploded View (Where Required By Model)
FEET ASSEMBLY EXPLODED VIEW (where required by model) NO.4 M5 NUTS N.4 M5 SCREWS CLASS 8.8 (ISO 898-1) 45 / 48 45 / 48 This manual is the property of PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden. - Page 24 ES ¡Descarga el manual en tu idioma! Lataa käsikirja omalla kielelläsi! FR Téléchargez le manuel dans votre langue! NL Download de handleiding in uw taal! PL Pobierz instrukcję w swoim języku! PT Baixe o manual em seu idioma! RU Загрузите руководство на вашем языке https://www.piusi.com/support/search-manuals BULLETIN M0725 ITEN_ 10.2024...
