Piusi Panther 72 Manual

ENGLISH
A INDEX
A Index H2 Preliminary Inspection
B Machine and Manufacturer Identification H3 Positioning the Pump
C Declaration of Incorporation H4 Connecting the Tubing
D Machine Description H5 Considerations Regarding
E Technical Specifications Delivery and Suction Lines
E1 Performance Specifications H6 Line Accessories
E2 Electrical Specifications H7 Electrical Connections
F Operating Conditions I Initial Start-Up
F1 Environmental Conditions L Daily Use
F2 Electrical Power Supply M Problems and Solutions
F3 Working Cycle N Maintenance
F4 Fluids Permitted / Fluids Not Permitted O Noise Level
G Moving and Transport P Disposal
H Installation Q Exploded Diagrams and Spare Parts
H1 Disposing of the Packing Material R Dimensions and Weights
B MACHINE AND MANUFACTURER IDENTIFCATION
Available Models:
• PANTHER 56 400V/50HZ
• PANTHER 56 230V/50HZ
• PANTHER 56 230V/60HZ • PANTHER 56 400V/60HZ
• PANTHER 72 230V/50HZ • PANTHER 72 400V/50HZ
MANUFACTURER: PIUSI SPA
VIA PACINOTTI - Z.I. RANGAVINO
46029 SUZZARA (MN)
IDENTIFICATION PLATE (EXAMPLE WITH THE FIELDS IDENTIFIED):
PRODUCT
CODE
PRODUCTION
YEAR
MODEL
TECHNICAL
DATA
MANUAL
ATTENTION
Always check that the revision level of this manual coincides with what is shown on the identification plate.
C DECLARATION OF INCORPORATION
DECLARATION OF INCORPORATION
The undersigned PIUSI S.p.A.
Via Pacinotti, Z.I. Rangavino
46029 Suzzara (Mantova) – Italy
Declares under its own responsibility that the machine:
PANTHER 56 - PANTHER 72
described below: Machine designed for the transfer of diesel fuel
is manufactured to be incorporated into a machine or to be assembled with other machinery to
build a machine according to the Machine Directive 98/37/CE.
Moreover, we declare that the machinery cannot be put into operation until the machine in
which it will be incorporated and of which it will become a component, has been identified and
its compliance with the Machine Directive 98/37/CE has been declared.
Suzzara 01.01.2006
________________________
OTTO VARINI, Chairman
D MACHINE DESCRIPTION
PUMP: Self-Priming, volumetric, rotating electric vane pump, equipped with by-pass valve.
MOTOR: Asynchronous motor, single-phase and three-phase, 2 pole, closed type
(protection class IP55 in conformance with EN 60034-5-86 regulations)
self-ventilated, directly flanged to the pump body.
FILTER: Inspectable suction filter.
E TECHNICAL SPECIFICATIONS
E1 PERFORMANCE SPECIFICATIONS
The performance diagram shows flow rate as a function of back pressure.
Typical Delivery Configuration
Functioning Flow Back
Model
Point Rate Pressure
• •
Panther 56 60 0.6
• •
Panther 72 80 0.5
A
Panther 56 • •
75 0.5
(Maximum
60Hz
Flow Rate)
Panther 56 • •
45 0.5
100/110-50Hz
Panther 56
• •
54 0.5
100/110-60Hz
• • •
Panther 56 56 1.5
• • •
Panther 72 72 1.3
B
Panther 56 • • •
(Maximum
98 1.4
60Hz
Back
Pressure) Panther 56 • • •
42 1.4
100/110-50Hz
Panther 56 • • •
50 1.4
100/110-60Hz
Panther 56 0 2.7
Panther 72 0 2.8
C
Panther 56
0 2.8 Delivery Closed
60Hz
(Bypass)
Panther 56
0 2.7
100/110-50Hz
Panther 56
0 2.8
100/110-60Hz
A
B
C
O Back Pressure
ENGLISH
ATTENTION
The curve refers to the following operating conditions:
Fluid Diesel Fuel
Temperature 20°C
Suction Conditions The tube and the pump position relative to the fluid level is such
that a pressure of 0.3 bar is generated at the nominal flow rate.
Under different suction conditions higher pressure values can be created that reduce the
flow rate compared to the same back pressure values.
To obtain the best performance, it is very important to reduce loss of suction pressure as
much as possible by following these instructions:
• Shorten the suction tube as much as possible
• Avoid useless elbows or throttling in the tubes
• Keep the suction filter clean
• Use a tube with a diameter equal to, or greater than, indicated (see Installation)
The burst pressure of the pump is of 20bar.
E2 ELECTRICAL SPECIFICATIONS
ELECTRICAL POWER POWER CURRENT
PUMP MODEL
Voltage Frequency Nominal (*) Maximum (*)
Current
(V) (Hz) (Watt) (Amp)
PANTHER 56 230V/50HZ AC 230 50 370 2.2
PANTHER 56 230V/60HZ AC 230 60 370 2.2
PANTHER 72 230V/50HZ AC 230 50 550 3.3
PANTHER 56 400V/50HZ AC 400 50 370 0.9
PANTHER 56 400V/60HZ AC 400 60 370 0.9
PANTHER 72 400V/50HZ AC 400 50 550 1.3
PANTHER 56 110V/50HZ AC 110 50 500 5.5
PANTHER 56 110V/60HZ AC 110 60 700 7.5
PANTHER 56 100V/50HZ AC 100 50 550 6.5
PANTHER 56 100V/60HZ AC 100 60 600 7.8
(*) Refers to functioning with maximum back pressure.
F OPERATING CONDITIONS
F1 ENVIRONMENTAL CONDITIONS
TEMPERATURE: RELATIVE HUMIDITY:
o o
min. -20 C / max +60 C max. 90%
ATTENTION
The temperature limits shown apply to the pump components and must be respected to
avoid possible damage or malfunction.
F2 ELECTRICAL POWER SUPPLY
Depending on the model, the pump must be The maximum acceptable variations from the
supplied by a single-phase alternating current electrical parameters are:
line whose nominal values are shown in the table voltage: +/- 5% of the nominal value
in Paragraph E2 - ELETRICAL SPECIFICATIONS. frequency: +/- 2% of the nominal value
ATTENTION
Power from lines with values outside the indicated limits can damage the electrical
components.
F3 WORKING CYCLE
The pumps are designed for continuous use under conditions of maximum back pressure.
ATTENTION
Functioning under by-pass conditions is only allowed for brief periods of time (2-3
minutes maximum).
F4 FLUIDS PERMITTED / FLUIDS NOT PERMITTED
PERMITTED:
• Diesel fuel at a viscosity of from 2 to 5.35 cSt (at a temperature of 37.8 o C)
Minimum Flash Point (PM): 55 o C
NOT PERMITTED: RELATED DANGERS:
• GASOLINE • FIRE - EXPLOSION
• INFLAMMABLE LIQUIDS WITH PM < 55 O C • FIRE - EXPLOSION
• LIQUIDS WITH VISCOSITY > 20 cSt • MOTOR OVERLOAD
• WATER • PUMP OXIDATION
• FOOD LIQUIDS • CONTAMINATION OF THE SAME
• CORROSIVE CHEMICAL PRODUCTS • PUMP CORROSION
• INJURY TO PERSONS
• SOLVENTS • FIRE - EXPLOSION
• DAMAGE TO GASKET SEALS
G MOVING AND TRANSPORT
Given the limited weight and size of the The pumps were carefully packed before
pumps (see overall dimensions), moving the shipment.
pumps does not require the use of lifting Check the packing material on delivery and
devices. store in a dry place.
H INSTALLATION
H1 DISPOSING OF THE PACKING MATERIAL
The packing material does not require spe- any way dangerous or polluting.
cial precautions for its disposal, not being in Refer to local regulations for its disposal.
H2 PRELIMINARY INSPECTION
• Check that the machine has not suffered • Make sure that the motor shaft turns
any damage during transport or storage. freely.
• Clean the inlet and outlet openings, • Check that the electrical specifications
removing any dust or residual packing correspond to those shown on the identi-
material. fication plate.
H3 POSITIONING THE PUMP
• The pump can be installed in any position holes provided in the base of the pump
(pump axis vertical or horizontal) (see the section "OVERALL
• Attach the pump using screws of DIMENSIONS" for their position and
adequate diameter for the attachment dimension).
ATTENTION
THE MOTORS ARE NOT OF AN ANTI-EXPLOSIVE TYPE.
Do not install them where inflammable vapors can be present.
H4 CONNECTING THE TUBING
• Before connection, make sure that the partially fill the pump body with diesel fuel
tubing and the suction tank are free of dirt to facilitate priming.
and thread residue that could damage the
pump and its accessories. • Do not use conical threaded joints that
could damage the threaded pump
• Before connecting the delivery tube, openings if excessively tightened.
SUCTION TUBING:
- Minimum recommended nominal diameter: 1-1/4"
- Nominal recommended pressure: 10 bar
- Use tubing suitable for functioning under suction pressure
DELIVERY TUBING
- Minimum recommended nominal diameter: 1"
- Nominal recommended pressure: 10 bar
ENGLISH
ATTENTION
It is the installer's responsibility to use tubing with adequate characteristics.
The use of tubing unsuitable for use with Diesel fuel can damage the pump, injure
persons and cause pollution.
Loosening of the connections (threaded connections, flanging, gasket seals) can cause
serious ecological and safety problems.
Check all the connections after the initial installation and on a daily basis after that.
Tighten the connections, if necessary.
H5 CONSIDERATIONS REGARDING DELIVERY AND SUCTION LINES
DELIVERY (partial) opening of the pump by-pass with
the consequent noticeable reduction of the
The choice of pump model must be made keeping flow rate supplied.
the characteristics of the system in mind.
In such cases, to allow correct functioning
The combination of the length of the tubing, of the pump, it is necessary to reduce
the diameter of the tubing, the flow rate of the system resistance, using shorter tubing
diesel fuel and the line accessories installed and/or of wider diameter and line accesso-
can create back pressure greater than the ries with less resistance (e.g., an automatic
maximums anticipated such as to cause the dispensing nozzle for greater flow rates).
SUCTION work with pressure at the inlet as high as 0.5 bar,
beyond which cavitation phenomena can
Panther 56 and Panther 72 pumps are self-priming begin, with a consequent loss of flow rate and
and characterized by good suction capacity. increase of system noise.
As we have said up to this point, it is important
During the start-up phase, with an empty to guarantee low suction pressure by using
suction tube and the pump wetted with fluid, the short tubing of a diameter equal to or larger than
electric pump unit is capable of suctioning the recommended, reducing curves to a minimum
liquid with a maximum difference in height of 2 and using suction filters of wide cross-section
meters. It is important to point out that the and foot valves with the lowest possible
priming time can be as long as one minute and resistance.
the presence of an automatic dispensing nozzle It is very important to keep the suction filters
on the delivery line prevents the evacuation of clean because, once clogged, they increase
air from the installation, and, therefore, prevents system resistance.
proper priming. The difference in height between the pump and
For this reason, it is always advisable to prime the fluid level must be kept as small as possible
the pump without an automatic delivery nozzle, and, at any rate, within the 2 meters anticipated
verifying the proper wetting of the pump. The for the priming phase.
installation of a foot valve is recommended to If this height is exceeded, it will always be
prevent the emptying of the suction tube and necessary to install a foot valve to allow for the
keep the pump wet. In this way, the pump will filling of the suction tube and provide tubing of
subsequently always start up immediately.
wider diameter. It is recommended that the
pump not be installed at a difference in height
When the system is functioning, the pump can greater than 3 meters.
ATTENTION
In the case that the suction tank is higher than the pump, it is advisable to install an anti-
siphon valve to prevent accidental diesel fuel leaks.
Dimension the installation in order to control the back pressures due to water hammering.
H6 LINE ACCESSORIES
The pumps are furnished without line accessories. sories whose use is compatible with the proper
Following is a list of the most common line acces- functioning of the pumps.
DELIVERY SUCTION
Automatic dispensing nozzle Foot valve with filter
Manual dispensing nozzle Rigid and flexible tubing
Meter
Flexible tubing
ATTENTION
It is the installer's responsibility to provide the line accessories necessary for the safe
and proper functioning of the pump.
The use of accessories unsuitable for use with diesel fuel can damage the pump, injure
persons and cause pollution.
H7 ELECTRICAL CONNECTIONS
SINGLE-PHASE MOTORS To change the cable, open the terminal strip
Single-phase motors are supplied with a cover and connect the line according to the
pre-existing 2-meter cable with electric plug. following diagram:
THREE PHASE SINGLE
A.C. LINE PHASE
TO MOTOR
TO
MOTOR
Single-phase motors are supplied with a on the identification plate for each pump model.
bipolar switch and capacitor wired and
installed inside the terminal strip box (see The switch has the sole function of star-
diagram). ting/stopping the pump and cannot in any
way substitute for the main circuit breaker
The characteristics of the capacitor are shown provided for in the applicable regulations.
THREE-PHASE MOTORS
Three-phase motors are supplied with a power line, open the terminal strip cover
terminal strip box and terminal strip. and connect the cables according to the
To connect the electric motor to the electric diagram.
ATTENTION
Verify that the terminal strip blades are positioned according to the diagram provided for the
available power supply voltage. Verify the correct direction of rotation of the motor (see the
paragraph overall dimensions), and, if not correct, invert the connection of the two cables in
the power supply plug or on the terminal strip.
The pumps are supplied without electrical safety equipment such as fuses, motor protectors,
systems to prevent accidental restarting after power failures or others. It is indispensable to
install an electric panel, upstream from the pump's power supply line, equipped with an
appropriate residual current operated circuit breaker.
It is the installer's responsibility to perform the electrical connections with respect for the
applicable regulations.
Respect the following (not exhaustive) instructions to ensure a proper electrical installation:
• During installation and maintenance, make direction of rotation (see Paragraph R -
sure that the electric supply lines are not live DIMENSIONS AND WEIGHTS)
• Use cables characterized by the • All motors are equipped with a ground
minimum cross-sections, nominal terminal to connect to the ground line of
voltages and wiring-type adequate to the the electrical network.
characteristics shown in Paragraph E2 -
ELECTRICAL SPECIFICATIONS and the • Always close the cover of the terminal strip
installation environment. box before supplying electrical power, after
ascertaining the integrity of the gasket seals
• In three-phase motors verify the correct that ensure protection grade IP 55.
I INITIAL START-UP
• Check that the quantity of diesel fuel in • Do not run the pump dry.
the suction tank is greater than the This can cause serious damage to its
amount you wish to transfer. components.
• Make sure that the residual capacity of • Make sure that the tubing and line accesso-
the delivery tank is greater than the ries are in good condition. Diesel fuel leaks
quantity you wish to transfer. can damage objects and injure persons.
ENGLISH
• Never start or stop the pump by inserting damage the skin. The use of glasses and
or removing any plugs. gloves is recommended.
• Do not operate switches with wet hands.
• Single-phase motors are provided with an
• Prolonged contact with diesel fuel can automatic thermal protection switch.
ATTENTION
Extreme operating conditions can raise the motor temperature and, consequently,
cause the thermal protection switch to stop it.
Turn off the pump and wait for it to cool before resuming use.
The thermal protection automatically turns off when the motor is sufficiently cool.
In the priming phase the pump must blow the Therefore it is necessary to keep the outlet
air initially present in the entire installation open to permit the evacuation of the air.
out of the delivery line.
ATTENTION
If an automatic type dispensing nozzle is installed on the end of the delivery line, the
evacuation of the air will be difficult because of the automatic stopping device that keeps the
valve closed when the line pressure is too low. It is recommended that the automatic
dispensing nozzle be temporarily disconnected during the initial start-up phase.
The priming phase can last from several seconds to a few minutes, as a function of the cha-
racteristics of the system. If this phase is prolonged, stop the pump and verify:
• That the pump is not running completely • That the suction height is not greater than
dry; 2 meters (if the height is greater than 2
• That the suction tubing is not allowing air meters, fill the suction tube with fluid);
to seep in; • That the delivery tube is allowing the
• That the suction filter is not clogged; evacuation of the air.
When priming has occurred, verify that the pump is operating within the anticipated range, in
particular:
• That under conditions of maximum back than 0.5 bar;
pressure, the power absorption of the • That the back pressure in the delivery line
motor stays within the values shown on is not greater than the maximum back
the identification plate; pressure anticipated for the pump.
• That the suction pressure is not greater
L DAILY USE
a. If using flexible tubing, attach the ends of by-pass valve allows functioning with the
the tubing to the tanks. In the absence of an delivery closed for only brief periods.
appropriate slot, solidly grasp the delivery
d. Open the delivery valve, solidly grasping
tube before beginning dispensing.
the end of the tubing.
b. Before starting the pump make sure that
e. Close the delivery valve to stop dispen-
the delivery valve is closed (dispensing
sing.
nozzle or line valve).
f. When dispensing is finished, turn off the
c. Turn the ON/OFF switch to ON. The pump.
ATTENTION
Functioning with the delivery closed is only allowed for brief periods (2-3 minutes maximum).
After use, make sure the pump is turned off.
LACK OF ELECTRIC POWER:
A lack of electric power, with the consequent accidental stopping of the pump, can be caused
by:
- A safety device tripping
- A drop in line voltage
In either case, act as follows: Resume operations as described in
a. Close the delivery valve Paragraph L - DAILY USE, after determining
b. Attach the end of the delivery to the slot the cause of the stoppage.
provided on the tank
c. Turn the ON/OFF switch to the OFF position.
M PROBLEMS AND SOLUTIONS
Problem Possible Cause Correttive Action
Check the electrical connec-
Lack of electric power
tions and the safety systems
Check for possible damage or
Rotor jammed
obstruction of the rotating
components
THE MOTOR IS NOT
TURNING Wait for the motor to cool,
The motor protecting thermal verify that it restarts, and
research the cause of the
switch has tripped
overheating
Motor problems Contact the Service Department
THE MOTOR TURNS
Low voltage in the electric Bring the voltage back within
SLOWLY WHEN
power line the anticipated limits
STARTING
Low level in the suction tank Refill the tank
Foot valve blocked Clean and/or replace the valve
Filter clogged Clean the filter
Lower the pump with respect to
Excessive suction pressure the level of the tank or increase
the cross-section of the tubing
High loss of head in the circuit Use shorter tubing or of greater
(working with the by-pass open) diameter
Dismantle the valve, clean
LOW OR NO FLOW
By-pass valve blocked
and/or replace it
RATE
Air entering the pump or the Check the seals of the
suction tubing connections
Use tubing suitable for working
A narrowing in the suction tubing
under suction pressure
Check the voltage at the pump.
Low rotation speed Adjust the voltage and/or use
cables of greater cross-section
The suction tubing is resting
Raise the tubing
on the bottom of the tank
Cavitation occurring Reduce suction pressure
Irregular functioning of the Dispense until the air is
INCREASED PUMP
by-pass purged from the circuit
NOISE
Air present in the diesel fuel Verify the suction connections
LEAKAGE FROM THE Check and replace the
Seal damaged
PUMP BODY mechanical seal
N MAINTENANCE
Panther 56 and Panther 72 pumps are designed and constructed to require a minimum of maintenance.
• On a weekly basis, check that the tubing • On a monthly basis, check and keep the
joints have not loosened, to avoid any pump filter clean and any other filters
leakage. installed.
• On a monthly basis, check the pump • On a monthly basis, check that the electric
body and keep it clean of any impurities. power supply cables are in good condition.
O NOISE LEVEL
Under normal working conditions the noise the value of 70 db at a distance of 1 meter
emission from all models does not exceed from the electric pump.
P DISPOSAL
The components must be given to companies that specialise in the disposal and recycling of
industrial waste and, in particular, the DISPOSAL OF PACKAGING.
The packaging consists of biodegradable cardboard which can be delivered to companies for
normal recycling of cellulose.
DISPOSAL OF METAL COMPONENTS
The metal components, both painted and stainless steel, are usually recycled by companies
that are specialised in the metal-scrapping industry.
DISPOSAL OF ELECTRIC AND ELECTRONIC COMPONENTS:
these have to be disposed by companies that are specialised in the disposal of electronic com-
ponents, in accordance with the instructions of 2002/96/EC (see text of Directive below).
ENVIRONMENTAL INFORMATION FOR CUSTOMERS IN THE EUROPEAN UNION
European Directive 2002/96/EC requires that the equipement bearing this sym-
bol on the product and/or its packaging must not be disposed of with unsorted
municipal waste. The symbol indicates that this product should be disposed of
separately from regular household waste streams.It is your responsibility to
dispose of this and other electric and electronic equipment via designated col-
lection facilities appointed by the government or local authorities.
DISPOSAL OF OTHER PARTS:
The disposal of other parts such as pipes, rubber seals, plastic components and cables should
be entrusted to companies that special in the disposal of industrial wate.
Bulletin
M0042A
Rev. 1
MANUALE
D'USO E
ITALIANO
MANUTENZIONE
USE AND
MAINTENANCE
ENGLISH
MANUAL
Bulletin M0042A Rev.1 Copyright
