Philips HQ8170 User Manual

Philips HQ8170 User Manual

Philips hq8170 electric shaver: user guide
Hide thumbs Also See for HQ8170:
Table of Contents

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Quick Links

Download this manual
ENGLISH 4
17
31
47
61
74
88
101
ROMÂNĂ 114
128
141
155
168
182
195
210

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HQ8170 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips HQ8170

Summary of Contents for Philips HQ8170

  • Page 1 ENGLISH 4 ROMÂNĂ 114...
  • Page 2 ENGLISH Important Read these instructions for use carefully before using the appliance and save them for future reference. Only use the powerplug supplied. The powerplug transforms 100-240 volts to a safe low voltage of less than 24 volts. The powerplug contains a transformer. Do not cut off the powerplug to replace it with another plug, as this will cause a hazardous situation.
  • Page 3 ENGLISH Do not immerse the shaver in water. Water may leak from the socket at the bottom of the appliance, when you rinse it. This is normal and not dangerous because all electronics are enclosed in a sealed shell inside the shaver. Noise level: Lc = 60 dB [A] Charging Make sure the appliance is switched off before...

  • Page 4: Battery Fully Charged

    ENGLISH Battery fully charged When the battery has been fully charged, all green lights are on. A few hours after charging, all lights go out. Remaining battery capacity The amount of power left in the battery is indicated by the number of lights that are on. The battery capacity is only shown when you switch the shaver on or off.

  • Page 5: Using The Appliance

    ENGLISH Put the powerplug in the wall socket. Remove the powerplug from the wall socket and pull the appliance plug out of the shaver when the battery has been fully charged. Charging stand You can also charge the appliance by placing it in the charging stand, if provided.
  • Page 6 - Shaving on a dry face gives the best results. - Your skin may need 2 or 3 weeks to get accustomed to the Philips shaving system. Switch the shaver off by pressing the on/off button once. The blue light ring around the on/off button goes out.
  • Page 7 ENGLISH Cleaning and maintenance The light above the tap symbol starts blinking after every shave to remind you that the shaver needs to be cleaned (except when the bottom light burns red). Regular cleaning guarantees better shaving performance. The normal way to clean the appliance is to rinse the shaving unit and the hair chamber with hot water every time you have used the shaver.
  • Page 8 ENGLISH Make sure you clean the inside as well as the outside of the shaving unit. Close the shaving unit and shake off excess water. Never dry the shaving unit with a towel or tissue as this may damage the shaving heads. Open the shaving unit again and leave it open to let the appliance dry completely.
  • Page 9 ENGLISH Close the shaving unit. Trimmer Clean the trimmer every time you have used it. Switch the shaver off, remove the powerplug from the wall socket and pull the appliance plug out of the shaver. Clean the trimmer with the brush supplied.
  • Page 10 Replace the shaving heads as soon as the light above the shaving unit symbol starts blinking. Replace damaged or worn shaving heads with HQ9 Philips shaving heads only. Do not mix up the cutters and the guards to guarantee optimal shaving performance.
  • Page 11 Dispose of the battery at an official collection point for batteries. If you have trouble removing the battery, you can also take the appliance to a Philips service centre, which will remove the battery for you and will dispose of it in an environmentally safe way.
  • Page 12 ENGLISH Remove the powerplug from the wall socket and pull the appliance plug out of the shaver. Let the shaver run until it stops and undo the two screws at the back of the shaver. Undo the two screws in the hair chamber. Undo the three screws in the power unit.

  • Page 13: Troubleshooting

    If you need information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Customer Care Centre in your country (you will find its phone number in the worldwide guarantee leaflet). If there is no...
  • Page 14 ENGLISH Replace the shaving heads. See chapter 'Replacement'. The shaver does not work when the on/off button is pressed. Cause 1: the battery is empty. Recharge the battery. See chapter 'Charging'. Cause 2: the appliance is not connected to the mains.
  • Page 112 ROMÂNĂ Important...
  • Page 113 ROMÂNĂ Încărcare Încărcare Baterie complet încărcată...
  • Page 114 ROMÂNĂ Capacitate rămasă Baterie descărcată...
  • Page 115 ROMÂNĂ Utilizarea aparatului Atunci când porniţi aparatul, se vor aprinde toate ledurile şi timp de câteva secunde se va afişa capacitatea rămasă a bateriei.
  • Page 116 ROMÂNĂ...
  • Page 117 ROMÂNĂ Curăţare şi întreţinere Atunci când clătiţi aparatul, este posibil ca apa să curgă prin partea inferioară. Acest lucru este normal şi nepericulos.
  • Page 118 ROMÂNĂ...
  • Page 119 ROMÂNĂ...
  • Page 120 ROMÂNĂ Depozitarea Înlocuirea Nu amestecaţi cuţitele şi sitele de protecţie, pentru a asigura performanţe optime.
  • Page 121 ROMÂNĂ Accesorii Protejarea mediului...
  • Page 122 ROMÂNĂ...
  • Page 123 ROMÂNĂ Garanţie şi service...
  • Page 124 ROMÂNĂ Depanare Cauza 1: Capetele de bărbierire sunt murdare. Aparatul nu a fost clătit de foarte mult timp sau apa pentru clătire nu a fost suficient de caldă. Cauza 2: Fire lungi de păr blochează capetele de bărbierire. Cauza 3: Capetele de bărbierire sunt deteriorate sau uzate.
  • Page 125 ROMÂNĂ Unitatea de bărbierire nu a fost corect poziţionată.
  • Page 224 4222 002 48161...
