OPERATION, MAINTENANCE,
AND INSTALLATION MANUAL
FOR
RJ-88SC, RJ-250SC,
and RJ-250SC Ultra
with Solar Power Unit
Includes HT (Hydraulic Tailgate) Units and
SL (Streamline, Liquid Removal) Units
SELF-CONTAINED
COMPACTOR CONTAINER
Marathon Equipment Company
OMI Manual No. 0018-S, Revision Date: June 2010
www.marathonequipment.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the marathon RAMJET RJ-88SC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dover marathon RAMJET RJ-88SC

  • Page 1 OPERATION, MAINTENANCE, AND INSTALLATION MANUAL RJ-88SC, RJ-250SC, and RJ-250SC Ultra with Solar Power Unit Includes HT (Hydraulic Tailgate) Units and SL (Streamline, Liquid Removal) Units SELF-CONTAINED COMPACTOR CONTAINER Marathon Equipment Company OMI Manual No. 0018-S, Revision Date: June 2010 www.marathonequipment.com...
  • Page 2 Table of Contents OPERATION  � ��������������������������������������������������������������������������������������������������������� Introduction ������������������������������������������������������������������������������������������������������� Specifications  � ��������������������������������������������������������������������������������� Pre-Operation Instructions  � ������������������������������������������������������������������������������������������������������� Control Panel  � �������������������������������������������������������� Operating Instructions (Standard Models) ����������������������������� Operating Instructions (Photoelectric Cycle Control Model) ������������������������������������������������������������������������������������������������� Optional Controls ������������������������������������������������������������������������������������������������������������������� Decals �������������������������������������������������������������������������������������������������� Decal Placement �����������������������������������������������������������������������������������������������������...
  • Page 3 SOLAR POWER UNIT  � ����������������������������������������������������������������������� Solar Power Unit - Specifications ����������������������������������������������������������������������������� Solar Power Unit - Schematic  � ����������������������������������������������������������������������������������������� Battery Specifications ������������������������������������������������������������������������������� Solar Power Unit - Parts List ����������������������������������������������������������������������������� Solar Power Unit - Wire Sizes ����������������������������������������������������������� Solar Power Unit - Periodic Maintenance �������������������������������������������������...
  • Page 4: Operation

    OPERATION Introduction Thank you for purchasing a Marathon Self-Contained Compactor/ Container. This compactor is designed to give you reliable and superior performance for many years to come. The purpose of this manual is to provide the owner and operator(s) the necessary information to properly and safely install, operate, and maintain your self-contained compactor.
  • Page 5: Specifications

    Specifications “B” Fire Port - “A”, Clear Top Opening Each Side SIDE VIEW “D” COMPACTOR CONTAINER “C” “E” 88SC 250SC 250SC Ultra 250SC HT “A”, Clear Top Opening 30 1/2 x 48 41 1/2 x 60 41 1/2 x 60 41 1/2 x 60 (L x W) (inches) “B”...
  • Page 6 Pre-Operation Instructions Federal regulation prohibits the use of this equipment by anyone under 18 years of age. --------------------------------------------------------------------------------------------------- DANGER STAY CLEAR OF ALL INTERNAL PARTS OF THE SELF-CONTAINED COMPACTOR/CONTAINER DO NOT DURING OPERATION. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH! ENTER --------------------------------------------------------------------------------------------------- NEVER ENTER ANY PART OF THE COMPACTOR UNLESS THE DISCON-...
  • Page 7: Control Panel

    Control Panel • START/FORWARD - This switch controls the compactor operation mode, automatic or manual (automatic is photocell mode). EMERGENCY STOP - When pressed, this pushbutton stops all powered oper- • ation of the compactor. • REVERSE - This pushbutton reverses the compaction ram. The motor must be running for this button to operate.
  • Page 8: In Case Of Emergency

    Operating Instructions (Standard Models) 1. First, place the material to be discarded into the DANGER compactor. Note: If you are loading the compactor through a door or gate, close it before starting the com- DO NOT pactor. Refer to “Decal Placement for Optional ENTER Loading Configurations”...
  • Page 9: Audible Alarm

    Operating Instructions (Photoelectric Cycle Control Model) NOTE: This compactor features an ANSI Z245.21 - 5.12.1 compliant start-up alarm that is both audible and visible during the activation of the AUTOMATIC mode. ---------------------------------------------------------------------------------------------------- Operating Instructions (AUTOMATIC mode) 1. Place the material to be discarded into the DANGER compactor.
  • Page 10: Optional Controls

    Optional Controls 1. SUSTAINED MANUAL PRESSURE CONTROL BUTTON (Hold-To-Run, Release-To-Stop) - This option requires the compactor operator to remain at the pushbutton station while the compactor is in use. Actuation requires depressing the “Hold-To-Run” and “Start” buttons. After the unit has started, the “Start”...
  • Page 11 Decals Warning Decal Requirements When your compactor leaves the factory, several warning decals are installed for your protection. These labels are subject to wear and abuse due to the nature of operation. The FOLLOWING DECALS MUST BE MAINTAINED. Additional decals may be purchased through your distributor or from Marathon Equipment Company by either calling the parts department at 1-800-633-8974 or going to www.parts1stop.com to place an order online.
  • Page 12: Decal Placement

    Decal Placement Match reference numbers to the chart on the previous page. The next page shows the decal images. 10** * Installed on both sides of compactor in same location. **Also installed on remote power pack. Operation1-9...
  • Page 13 Decal Images 06-0039 06-0040 06-0038 06-0002 06-0052 06-0057 06-0067 06-0072 06-0104 06-0093 06-0094 06-0105 06-0364 06-0121 06-0124 06-0249 06-3123 06-1839 06-3231 06-3661 06-3660 Operation1-10...
  • Page 14 Decal Placement for Optional Loading Configurations Match reference numbers to “Decals” on page 1-8 when ordering replacement decals. THRU-THE-WALL SECURITY CHUTE DOGHOUSE 2 & 17 DOCK ACCESS GATE & HOPPER * Located on each outside wall. Operation1-11...
  • Page 15: Side View

    Decals For Hydraulic Tailgate (HT) Units In addition to the decals and their placement specified on the previous pages, the self-contained units with the hydraulic tailgate option require the following decals located as shown below. HYDRAULIC COUPLING BOTH SIDES SIDE VIEW REAR VIEW Operation1-12...
  • Page 16: Maintenance

    MAINTENANCE Lock-Out & Tag-Out Instructions WARNING: This machine contains mul- tiple lockouts (1 for the AC circuit and 2 each for the DC circuits). All must be locked out before service or maintenance can be performed. Before entering any part of the compac- tor, be sure that all sources of energy have been shut off, all potential hazards have been eliminated, and the compactor is...
  • Page 17: Power Unit

    HYDRAULIC: Stored hydraulic energy must be removed from the compactor hydraulic circuit for Solenoid Valve complete lock-out and tag-out. Make sure that this Valve Pin energy has been relieved by manually depressing the solenoid valve pin located in the center of the coil end of the directional control valve.
  • Page 18 Procedures for Hydraulic System Pressure Check Pressure Settings When the hydraulic cylinders used in the RamJet Self-Contained compactor are fully extended or retracted, they bypass internally. This makes it impossible for the hydraulic system to reach relief pressure. Follow the recommendations below for proper pressure setting.
  • Page 19: Principles Of Operation

    Principles of Operation Standard System Operating Characteristics (1-1/2 HP) The system uses special cylinders to move the ram and a PLC (programmable logic controller) to control the operation of the ram. When the hydraulic cylin- ders used in the self-contained compactors are fully extended or retracted, they bypass internally.
  • Page 20 Tailgate Seal Replacement When the door/tailgate seal becomes damaged or worn, replace the seal. WARNING: For units with hydraulic tailgates, before performing any inspection or maintenance on the seal, support the raised tailgate with a crane, forklift, or other positive maintenance prop. •...
  • Page 21 Typical Panel Box Configuration This diagram represents a typical panel box configuration for the self-contained compactors. The panel box on your compactor may differ depending on the model and/or optional equipment/controls. To order replacement parts, please call our Parts Department at 1-800-633-8974 or order online by logging on www.parts1stop.com.
  • Page 22 Power Unit - Standard 1.5 HP Match the reference numbers with the following chart to identify components. For replacement part ordering, call our parts department at 1-800-633-8974 or log on to www.parts1stop.com to quickly place your order online. Ref. # Part # Description 03-2649...
  • Page 23: Troubleshooting Chart

    Troubleshooting Chart Problem Possible Cause Solution UNIT WILL NOT (1) No electrical power to unit (1A) Turn on main disconnect. START (1B) Replace fuses/reset breakers (2) No electrical power to control (2A) Check primary and secondary circuit sides of transformer. (2B) Check for correct voltage.
  • Page 24 Problem Possible Cause Solution UNIT WILL NOT (1) Solenoid valve is in-operative (1A) Check coil in solenoid valve REVERSE (2) Reverse button in-operative (2A) Check reverse button contacts. PUMP MAKES (1) Partly clogged intake strainer (1A) Pump must receive intake fluid NOISE-SOUNDS or restricted intake pipe freely or cavitation results.
  • Page 25: Installation

    INSTALLATION Concrete Pad Requirements CAUTION: Review this manual before making the installation. Study the job site and installation requirements carefully to be certain all necessary safeguards and or safety devices are provided to protect all personnel and equipment during the installation and as a completed system.
  • Page 26 Steel Installation Procedures Dock Installation If the appropriate accessories are ordered from Marathon Equipment Co., the com- pactor/container will be furnished with either a four-sided hopper or a three-sided hopper with a hinged gate. These accessories should not be altered as they are manufactured in accordance with those standards which prevail at the time of manufacture.
  • Page 27 Electrical and Hydraulic Installation DANGER The motor control panel contains high voltage com- ponents. Only authorized service personnel should be allowed inside. See “Lock-Out & Tag-Out Instructions” on page 2-1 in the Maintenance section. Volts A lockable fused disconnect switch (customer furnished) must be installed and be within sight of the compactor motor control panel location, not to exceed 50’0”...
  • Page 28: Electrical Connections

    Electrical & Hydraulic Installation (cont.) Pushbutton Control Panel If a remote operator station is furnished, it will be factory wired using Sealtite. If it is necessary to disconnect it from the wires (to install the operator station inside a building), exercise care that these wires are reconnected as originally fur- nished.
  • Page 29 Through-the-Wall Power Unit Installation If the remote power unit is to be mounted through-the-wall, the following list of material and diagram is the suggested method. List of Material Item Description Hydraulic Hose, Hi-Pressure (sized to power unit*), 36” long Pipe, Sch 80 (sized to power unit*), 36” long Hydraulic Hose, Hi-Pressure (sized to power unit*), 48”...
  • Page 30 HAULER INFORMATION General Hauler Instructions Before hauling to the landfill: 1. Disconnect all hoses and electrical connections (if applicable) between the power unit and the compactor. Make sure they are placed in an area where they will not get damaged. 2.
  • Page 31 Door/Latch Operation CONTAINER LATCH ASSEMBLY ACTUATED BY RATCHET DOOR LATCH SIDE VIEW OF CONTAINER AUTO RELATCH SAFETY CHAIN - Always fasten chain in keyhole when door is closed. Ratchet for opening and closing the latch When the door is assembly open, secure the chain in the keyhole on the hinge side of...
  • Page 32 Hydraulic Tailgate Operation (For Optional HT Units) The truck hoist must have a hydraulic selector valve, with 1500 psi minimum, to operate the hydraulic tailgate. The hydraulic tailgate is supplied with one 1/2” NPTF male quick disconnect mounted on the drivers side of the unit. A 1/2” female quick disconnect is supplied for use on the truck hoist valve plumbing.
  • Page 33 --------------------------------------------------------------------------------------------------- WARNING: NEVER PLACE ANY PART OF YOUR BODY BETWEEN THE TAILGATE AND THE CONTAINER. --------------------------------------------------------------------------------------------------- Instructions for Using the Maintenance Bar 1. Lower tailgate approximately 24” between the container bottom and compactor tailgate. 2. Remove locking pin from maintenance bar and slide bar toward compactor. 3.
  • Page 34 Liquid Removal (For Optional SL Units) The RamJet Self-Contained Streamline compactor/containers are designed with an internal drain system for liquid removal, ported to each corner of the machine. The unit comes standard with one ball valve. This valve can be moved to any of the four drain outlets on the machine. The valve should be located at the lowest outlet on the machine for proper drainage.
  • Page 35: Solar Power Unit

    SOLAR POWER UNIT Solar Power Unit - Specifications Compactor Model Self-Contained/Stationary (Qty) Motor - 120 VAC, 1.5 HP, 3 GPM HiLo motor/pump combination Batteries - sealed AGM deep-cycle lead acid 12 volt, 110 amp hours 140 Watt Solar Panel OR 100 Watt Solar Panel Solar Power Unit - Schematic For further information, refer to...
  • Page 36: Battery Specifications

    Battery Specifications Specifications & Characteristics Nominal Voltage Rated Capacity 110 Ah/20HR 331 mm Dimensions 173 mm Total H. 243 mm Weight Approx. 33 kg(72.75lbs) 110 Ah 20 HR 5.5 A 100 Ah 10 HR 10.0A Capacity 20ºC 90 Ah 5 HR 18 A (68ºF) 87.7 Ah 4 HR...
  • Page 37: Solar Panel

    Solar Power Unit - Parts List Part # Description PANEL BOX 03-5552 & 03-5553 Panel Box 03-5630 Inverter 03-5631 Reversing Contactor 03-4732 Power Supply 03-4448 Fuse 2 Amp 03-4480 Fuse 1 Amp 03-5634 Voltage Relay 03-5638 03-5633 Solar Controller 03-5637 Motor Starter PPK (Power Unit) 02-0050...
  • Page 38 Solar Power Unit - Wire Sizes 100 Watts (1 x 100 Watt Panel) Distance Wire Size Wire Diameter Conduit Size (Feet) (Gauge) (Inches) (Inches) < 3/16 < 3/16 < 3/16 < 1/4 < 1/4 < 1/4 > 5/16 > 5/16 >...
  • Page 39 300 Watts (3 x 100 Watt Panel) Distance Wire Size Wire Diameter Conduit Size (Feet) (Gauge) (Inches) (Inches) < 3/8 > 3/8 > 7/16 1-1/4 > 7/16 1-1/4 < 1/2 1-1/4 > 1/2 1-1/2 > 1/2 1-1/2 > 9/16 1-1/2 >...
  • Page 40 Solar Power Unit - Typical Electrical Schematic Drawing Number: E-8811-A SolarPowerUnit5-6...
  • Page 41 Typical Electrical Schematic Drawing Number: E-8811-B SolarPowerUnit5-7...
  • Page 42 Solar Power Unit - Typical Hydraulic Schematic Drawing Number: E-0647 Ref. # Description 1(1), 1(2) Motor 2(1), 2(2) Pump 3(1), 3(2) Strainer Check Valve Pressure Control Valve Relief Valve Pressure Gauge Direction Valve Hydraulic Cylinder SolarPowerUnit5-8...
  • Page 43: General Installation Requirements

    General Installation Requirements CAUTION: The panel box contains high voltage components. Only authorized service personnel should be allowed inside. See “Lock-Out & Tag-Out Instructions” on page 2-1. ---------------------------------------------------------------------------------------------------- Anchoring The power unit should be anchored to the concrete pad using a minimum of four 1/2”...
  • Page 44 Assembling the Solar Panel Stand The following instructions describe the assembly process for the standard solar panel stand, which can then be mounted on top of the power unit, roof, or other applicable horizontal surface. The components and assembly process for pole- mounted or wall-mounted stands may vary.
  • Page 45: Pole Mount Installation

    Mounting the Solar Panel Stand NOTE: Before choosing where to mount the solar panel stand, read the “Orienta- tion of the Solar Panel” recommendations on the next page. The solar panel and stand can be mounted on either the top of the power unit, a wall, roof, or on a pole located within 100 feet of the power unit and connected to the solar charger controller with an S.O.
  • Page 46 Connecting and Orienting the Solar Panel After mounting the solar panel, connect the cord to the plug in on the power unit. Orientation of the Solar Panel In the northern hemisphere, it is best for the solar panels to face southward. In the southern hemisphere, it is best that they face northward.
  • Page 47 INDEX ANSI 1-1, Operating Instructions Automatic Mode (Photoelectric) Manual Override Concrete Pad Requirements Optional Controls Controls Pre-Operation Emergency Stop Principles of Operation Power On Standard Models Reverse OSHA 1-1, Start/Forward Cylinder Removal Instructions Parts List Decals Decals Panel Box Hydraulic Tailgate (HT) Units 1-12 Power Unit Images...
