Summary of Contents for Dakota Alert MURS Alert
- Page 1 Dakota Alert WIRELESS SECURITY EQUIPMENT MURS Alert Transmitter Long range driveway alarm USER GUIDE www.dakotaalert.com...
- Page 2 MURS products: The M538-BS is a Base Station MURS transceiver that receives alert signals from the MURS Alert transmitters. It can also be used for two way communication between other MURS Transceivers. In addition, the M538-BS is equipped with a normally open (N/O) relay output.
- Page 3 2. This device must accept any interference, including interference that may cause undesired operation. The MURS Alert Transmitter is a passive infrared (PIR) motion detector that can be used to detect people, vehicles or large animals at selected locations. The PIR sensor will detect movement of objects up to 80 feet in front of the transmitter box.
- Page 4 Remove the antenna and screw it onto the antenna jack on the top of the exterior case. (Figure 2) Power Supply: The MURS Alert Transmitter is powered by 6 AA batteries. For best results, we recommend that you use good quality alkaline batteries. When replacing...
-
Page 5: Installation
20 feet back from the area to be monitored and 3 - 4 feet off the ground. Alert Signal: The MURS Alert Transmitter has 4 dif- ferent alert signals. The alert signal will repeat the location of the transmitter. The signal will be a voice saying “Alert zone one,...”, “Alert zone two,...”, “Alert... - Page 6 PIR Settings: To adjust the settings of the PIR motion RANGE LED FILTER RESET detector, remove the lens cover of the sensor. Remove the jumpers and reinstall them on the correct pins for settings: DETECTION (RANGE) PIN POSITIONS: MEDIUM HIGH LOW Setting: Detects up to 30 feet MEDIUM Setting: Detects up to 50 feet HIGH Setting: Detects up to 80 feet...
- Page 7 LED: To turn ON: Place the jumper over the top two pins to turn the LED light on. The LED light will flash when it detects. To turn OFF: Place the jumper over the bottom two pins. The LED will not light up when it detects.
-
Page 8: Changing Zones
Changing Zones: MURS Radio Board •To access the MURS Radio Board gently push the two plastic tabs to the side and lift out the PIR and plastic backing. (See Figure 6) Channel Sub-Channel (CTCSS) Figure 6 •You will now be looking inside of the case to the Alert Zones radio transmitter (Figure 5). - Page 9 Charts. **Factory default setting is Channel 1, Sub-Channel 01. May leave these settings as is. ***The Channel and Sub/Channel on your MURS Alert Transmitter must match the Channel and Sub-Channel of your M538-BS or M538-HT Transceiver for them to communicate.
-
Page 10: Frequency Charts
Frequency Charts: Sub Code (CTCSS) Frequency Frequency Chart Frequency Code Frequency Code Frequency Code Channel Channel Frequency Power (Hz) (Hz) (Hz) Type (MHz) (Watts) 00.0 103.5 162.2 MURS 151.820 167.9 67.0 107.2 MURS 151.880 71.9 110.9 173.8 MURS 151.940 74.4 114.8 179.9 MURS... -
Page 11: Low Battery Alert
(Cental Standard Time). We will be happy to answer your questions and help you in any way we can. Warranty: Dakota Alert warrants this product to be free of defects in material and workmanship for a period of one year from the date of purchase. The warranty does not cover damage resulting from accident, abuse, act of God or improper operation. - Page 12 Dakota Alert, Inc. www.dakotaalert.com Phone: (605)356-2772 Dakota Alert Fax: (605)356-3662 Address: 32556 477th Ave. WIRELESS SECURITY EQUIPMENT PO Box 130 Elk Point, SD 57025...
