Icom IC-3220A Instruction Manual page 15

a
BASIC OPERATION 4 Ey
usme SET MODE
Mi Frequency setting
The operating frequency can be set with the main dial
or the microphone [UP]/{[DN] switches.
1) Push IN [POWER] to turn ON power.
2) Push [BAND] to select VHF or UHF.
eWhen "L" appears or the function display, see
p. 15 regarding cancelling the dial lock function.
3) Push [V/MHz] to select VFO mode. Push [BAND] to select VHF or UHF.
eWhen the kHz digits disappear, push [V/MHz]
again. Push [V/MHz] to select VFO mode.
Push [SET] several times until "dP" appears on the
function display as shown above.
e Refer to p. 13 for SET mode details.
4) Rotate the main dial or push [UP] or [DN] on the
microphone to change the frequency.
eThe tuning step can be changed as described at
right.
e Push [V/MHz] for a 1 MHz tuning step. Rotate the main dial for the desired tuning step.
e5, 10, 12.5, 15, 20, 25 kHz steps are available.
Push any switch except [SET] and [HI/LO], or push PTT
to set the value and to exit SET mode.
NOTE: When a programmable remote control
function is activated, [UP]/[DN] switches cannot be
used for frequency setting. See p. 29 for details.
