ASROCK Rack BERGAMOD8-2L2T User Manual

Server/workstation motherboards
Hide thumbs

Advertisement

Quick Links

Download this manual
BERGAMOD8-2L2T
User Manual
Version 1.0
Published July 2023
Copyright©2023 ASRock Rack INC. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BERGAMOD8-2L2T and is the answer not in the manual?

Questions and answers

Related Manuals for ASROCK Rack BERGAMOD8-2L2T

Summary of Contents for ASROCK Rack BERGAMOD8-2L2T

  • Page 1 BERGAMOD8-2L2T User Manual Version 1.0 Published July 2023 Copyright©2023 ASRock Rack INC. All rights reserved.

  • Page 2: Copyright Notice

    In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of...
  • Page 3 ASRock Rack follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock Rack product is in line with global environmental regulations. In addition, ASRock Rack disclose the relevant in- formation based on regulation requirements.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installation of Memory Modules (DIMM) Expansion Slots (PCI Express Slots) Onboard Headers and Connectors ATX PSU Power Connections Dr.
  • Page 5 3.1.2 Navigation Keys Main Screen 3.2.1 Mother Board Information 3.2.2 Processor Information 3.2.3 Memory Information Advanced Screen 3.3.1 CPU Configuration 3.3.2 Chipset Configuration 3.3.3 Storage Configuration 3.3.4 NVMe Configuration 3.3.5 ACPI Configuration 3.3.6 USB Configuration 3.3.7 Super IO Configuration 3.3.8 Serial Port Console Redirection 3.3.9 H/W Monitor 3.3.10 PCI Subsystem Settings 3.3.11 AMD CBS...
  • Page 6 3.4.1 Key Management Server Mgmt 3.5.1 BMC Network Configuration 3.5.2 DNS Configuration 3.5.3 System Event Log 3.5.4 BMC Tools Event Logs Boot Screen 3.7.1 CSM Parameters Exit Screen Chapter 4 Software Support Download and Install Operating System Download and Install Software Drivers Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures...

  • Page 7: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. Find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com About this motherboard technical support, please visit the website for specific information http://www.asrockrack.com/support/...

  • Page 8: Specifications

    1.2 Specifications BERGAMOD8-2L2T MB Physical Status Form Factor Dimension 12" x 10.5" (304.8 x 266.7mm) Processor System Supports AMD EPYC™ 9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors Socket 1 Socket SP5 (LGA-6096) Thermal Design 400W Power (TDP)
  • Page 9 System BIOS Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM Features ASRock Rack Instant Flash, ACPI 6.4 and abouve compliance wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP) Other Internal Connectors/Headers PSU Connector 1 (4-pin, ATX PSU signal) w/ ATX 24-pin adapter cable, 3 (8-...
  • Page 10 TPM Header 1 (13-pin, SPI) SMbus PMbus IPMB Header Clear CMOS 1 (contact pads) LED Indicators Standby Power LED 1 (5VSB) 80 debug port LED Fan Fail LED BMC Heartbeat LED 1 Support OS Microsoft® Windows®: - Server 2019 (64bit) - Server 2022 (64bit) Linux®: - RedHat Enterprise Linux Server 8.6 (64bit) / Server 9.0...

  • Page 11: Unique Features

    . With this utility, press the <F6> key during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to the USB flash drive, floppy disk or hard drive, then update the BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 12: Motherboard Layout

    MCIO3 ATX12V3 CPU1 UID1 DDR5_A1 MCIO1 DDR5_B1 DDR5_C1 MCIO2 DDR5_E1 COM1 USB3_3_4 TPM_BIOS_PH1 NUT110_2 PCIE6 FAN1 X710 BAT1 CLRMOS1 FAN2 BERGAMOD8-2L2T PCIE5 NUT80_2 NUT80_1 FAN3 PCIE4 FAN4 FAN5 ASPEED AST2600 PCIE3 FAN6 FAN7 BUZZER1 PCIE2 PCIE1 M2_2 M2_1 FAN8 SATA_SGPIO2 Dr.
  • Page 13 BERGAMOD8-2L2T Description PSU SMBus Header (PSU_SMB1) ATX 12V Power Connector (ATX12V3) Mini Cool Edge IO x8 Connector (MCIO5) Mini Cool Edge IO x8 Connector (MCIO4) 2 x 288-pin DDR5 DIMM Slots (DDR5_H1, DDR5_K1)* 2 x 288-pin DDR5 DIMM Slots (DDR5_G1, DDR5_I1)*...
  • Page 14 Description System Panel Header (PANEL1) Speaker Header (SPEAKER1) Auxiliary Panel Header (AUX_PANEL1) Front LAN LED Connector (LED_LAN3_4) Backplane PCI Express Hot-Plug Connector (CPU1_HSBP1) Intelligent Platform Management Bus Header (IPMB1) BMC SMBus Header (BMC_SMB1) PCI Express 5.0 x8 Slot (PCIE1) PCI Express 5.0 x16 Slot (PCIE2) PCI Express 5.0 x8 Slot (PCIE3) PCI Express 5.0 x16 Slot (PCIE4) PCI Express 5.0 x16 Slot (PCIE5)

  • Page 15: Onboard Led Indicators

    BERGAMOD8-2L2T 1.5 Onboard LED Indicators Item Status Description LED_FAN1 FAN1 failed LED_FAN2 FAN2 failed LED_FAN3 FAN3 failed LED_FAN4 FAN4 failed LED_FAN5 FAN5 failed LED_FAN6 FAN6 failed LED_FAN7 FAN7 failed LED_FAN8 FAN8 failed SB_PWR1 Green STB PWR ready BMC_LED1 Green BMC heartbeat LED...

  • Page 16: I/O Panel

    1.6 I/O Panel No. Description No. Description VGA Port (VGA1) 1G LAN RJ-45 Port (LAN2)** USB 3.2 Gen1 Ports (USB3_1_2) 10G LAN RJ-45 Port (LAN3)*** IPMI LAN Header (IPMI_LAN1)* 10G LAN RJ-45 Port (LAN4)*** 1G LAN RJ-45 Port UID Switch (UID1) (LAN1, shared NIC)** LAN Port LED Indications *There is an LED on each side of IPMI LAN port.
  • Page 17 BERGAMOD8-2L2T **There is an LED on each side of 1G LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port 1G LAN Port LED Indications Activity / Link LED Speed LED...

  • Page 18: Block Diagram

    1.7 Block Diagram...

  • Page 19: Chapter 2 Installation

    BERGAMOD8-2L2T Chapter 2 Installation This is an CEB form factor (12” x 10.5”, 30.48 x 26.67cm) motherboard. Before installing the motherboard, study the configuration of the chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries and motherboard damages.

  • Page 20: Installing The Cpu

    2.3 Installing the CPU 1. Before inserting the CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 21 BERGAMOD8-2L2T...
  • Page 22 Carr ier Frame with CPU Rail Frame Please make sure that the carrier frame with CPU is closely attached to the rail frame while inserting it. Install the carrier frame with CPU. Don’t separate them.
  • Page 23 BERGAMOD8-2L2T...
  • Page 24 Set your torque wrench to 1.54 in-lb. One fourth a turn each time. Tighten the screws in a sequential order 1 > 2 > 3 > 4 > 5 > 6. Loosen the screws in a reverse order. 10-4 10-2 10-5 10-6 10-1...

  • Page 25: Installation Of Memory Modules (Dimm)

    BERGAMOD8-2L2T 2.4 Installation of Memory Modules (DIMM) This motherboard provides eight 288-pin DDR5 (Double Data Rate 5) DIMM slots in two groups, and supports Single Channel Memory Technology . 1. Before installing a memory module, make sure to turn off the computer and unplug the powercord from the power outlet to prevent damage to the memory module.

  • Page 27: Expansion Slots (Pci Express Slots)

    BERGAMOD8-2L2T 2.5 Expansion Slots (PCI Express Slots) There are six PCI Express slots on this motherboard. PCIE slots: PCIE1 (PCIE 5.0 x8 slot, from CPU1) is used for PCI Express x8 lane width cards. PCIE2 (PCIE 5.0 x16 slot, from CPU1) is used for PCI Express x16 lane width cards.

  • Page 28: Onboard Headers And Connectors

    2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power switch, PLED+ PLED-...
  • Page 29 BERGAMOD8-2L2T Auxiliary Panel Header This header supports multiple (18-pin AUX_PANEL1) functions on the front panel, (see p.6, No. 37) including front panel SMB, internet status indicator. A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows user to connect SMBus (System Management Bus) equipment. It can be used for communication between peripheral equipment in the system, which has slower transmission rates, and power management equipment.
  • Page 30 SPI TPM Header This connector supports SPI (13-pin TPM_BIOS_PH1) Trusted Platform Module (see p.6, No. 48) (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.
  • Page 31 BERGAMOD8-2L2T Backplane PCI Express The header is used for the hot CPU_HP_SCL Hot-Plug Connector plug feature of HDDs on the CPU_HP_SDA P0_HP_ALERT_L (5-pin CPU1_ HSBP1) backplane. (see p.6, No. 39) System Fan Connectors Please connect fan cables to (6-pin FAN1) the fan connectors and match (see p.6, No.
  • Page 32 ATX Power Connectors This motherboard provides (8-pin ATX12V1) three ATX power connectors. (see p.6, No. 8) (8-pin ATX12V2) (see p.6, No. 9) (8-pin ATX12V3) (see p.6, No. 2) Graphics 12V Power This motherboard provides Detective Pin Connector a 6-pin Graphics 12V power Right-Angle: connector.
  • Page 33 BERGAMOD8-2L2T Chassis Speaker Header Please connect the chassis DUMMY SPEAKER (4-pin SPEAKER1) speaker to this header. (see p.6, No. 36) DUMMY Front LAN LED This 4-pin connector is used LAN4_LINK LED_PWR Connector for the front LAN status (LED_LAN3_4) indicator. LAN3_LINK LED_PWR (see p.6, No.
  • Page 34 MCIO1 Pin Definition Defeinition Pin Defeinition G2_RXP7 G2_TXN7 G2_RXN7 G2_TXP7 G2_RXP6 G2_TXN6 G2_RXN6 G2_TXP6 BP_TYPE SMB_SCL WAKE# SMB_SDA RST0_L PRSNT_N G2_RXP5 G2_TXN5 G2_RXN5 G2_TXP5 G2_RXP4 G2_TXN4 G2_RXN4 G2_TXP4 G2_RXP3 G2_TXN3 G2 _ RXN3 G2_TXP3 G2_RXP2 G2_TXN2 G2_RXN2 G2_TXP2 BP_TYPE SMB_SCL WAKE# SMB_SDA RST0_L...
  • Page 35 BERGAMOD8-2L2T MCIO2 Pin Definition Defeinition Pin Defeinition G2_RXP15 G2_TXN15 G2_RXN15 G2_TXP15 G2_RXP14 G2_TXN14 G2_RXN14 G2_TXP14 BP_TYPE SMB_SCL WAKE# SMB_SDA RST0_L PRSNT_N G2_RXP13 G2_TXN13 G2_RXN13 G2_TXP13 G2_RXP12 G2_TXN12 G2_RXN12 G2_TXP12 G2_RXP11 G2_TXN11 G2 _ RXN11 G2_TXP11 G2_RXP10 G2_TXN10 G2_RXN10 G2_TXP10 BP_TYPE...
  • Page 36 MCIO3 Pin Definition Defeinition Pin Defeinition G3_RXP0 G3_TXP0 G3_RXN0 G3_TXN0 G3_RXP1 G3_TXP1 G3_RXN1 G3_TXN1 BP_TYPE SMB_SCL WAKE# SMB_SDA RST0_L PRSNT_N G3_RXP2 G3_TXP2 G3_RXN2 G3_TXN2 G3_RXP3 G3_TXP3 G3_RXN3 G3_TXN3 G3_RXP4 G3_TXP4 G3 _ RXN4 G3_TXN4 G3_RXP5 G3_TXP5 G3_RXN5 G3_TXN5 BP_TYPE SMB_SCL WAKE# SMB_SDA RST0_L...
  • Page 37 BERGAMOD8-2L2T MCIO4 Pin Definition Defeinition Pin Defeinition P3_RXN0 P3_TXP0 P3_RXP0 P3_TXN0 P3_RXN1 P3_TXP1 P3_RXP1 P3_TXN1 BP_TYPE SMB_SCL WAKE# SMB_SDA RST1_L PRSNT_N P3_RXN2 P3_TXP2 P3_RXP2 P3_TXN2 P3_RXN3 P3_TXP3 P3_RXP3 P3_TXN3 P3_RXN4 P3_TXP4 P3 _ RXP4 P3_TXN4 P3_RXN5 P3_TXP5 P3_RXP5 P3_TXN5 BP_TYPE...
  • Page 38 MCIO5 Pin Definition Defeinition Pin Defeinition P3_RXN8 P3_TXP8 P3_RXP8 P3_TXN8 P3_RXN9 P3_TXP9 P3_RXP9 P3_TXN9 BP_TYPE SMB_SCL WAKE# SMB_SDA RST1_L PRSNT_N P3_RXN10 P3_TXP10 P3_RXP10 P3_TXN10 P3_RXN11 P3_TXP11 P3_RXP11 P3_TXN11 P3_RXN12 P3_TXP12 P3 _ RXP12 P3_TXN12 P3_RXN13 P3_TXP13 P3_RXP13 P3_TXN13 BP_TYPE SMB_SCL WAKE# SMB_SDA RST1_L...

  • Page 39: Atx Psu Power Connections

    BERGAMOD8-2L2T 2.7 ATX PSU Power Connections This motherboard support ATX power input. Please refer to the table below for the required connections between the motherboard and the power supply. ATX PSU DC-IN (via a 24pin-to-4pin Converter Cable) 12V 8pin 12V 8pin...

  • Page 40: Dr. Debug

    2.8 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31 PEI_MEMORY_INSTALLED 0x32 PEI_CPU_INIT 0x33 PEI_CPU_CACHE_INIT...
  • Page 41 BERGAMOD8-2L2T 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
  • Page 42 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
  • Page 43 BERGAMOD8-2L2T 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
  • Page 44 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
  • Page 45 BERGAMOD8-2L2T 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...

  • Page 46: Identification Purpose Led/Switch

    2.9 Identification purpose LED/Switch With the UID button, user can be able to locate the server working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed, (UID1) the front/rear UID blue LED indicator will be truned on.

  • Page 47: Ssd Module Installation Guide

    BERGAMOD8-2L2T 2.10 M.2 SSD Module Installation Guide The M.2 Socket (M2_1/M2_2, Key M) supports type 2280/22110 M.2 PCI Express module up to Gen5 x4 (32GT/s x4). Installing the M.2 SSD Module Step 1 Prepare a M.2_SSD module and the screw.
  • Page 48 Step 3 Move the standoff based on the module type and length. Skip Step 3 and 4 and go straight to Step 5 if using the default nut. Otherwise, release the standoff by hand. Step 4 Peel off the yellow protective film on the nut to be used.

  • Page 49: Dual Lan And Teaming Operation Guide

    BERGAMOD8-2L2T 2.11 Dual LAN and Teaming Operation Guide Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images. Fault tolerance on the dual LAN network prevents network downtime by transferring the workload from a failed port to a working port.

  • Page 50: Chapter 3 Uefi Setup Utility

    Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure the system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. Run the UEFI SETUP UTILITY when starting up the computer. Please press <F2> or <Del> during the Power- On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...

  • Page 51: Navigation Keys

    BERGAMOD8-2L2T 3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 52: Main Screen

    3.2 Main Screen Once entering the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows user to set the system time and date.

  • Page 53: Mother Board Information

    BERGAMOD8-2L2T 3.2.1 Mother Board Information Press <Enter> to view the information of the motheboard. 3.2.2 Processor Information Press <Enter> to view the information of the processor.

  • Page 54: Memory Information

    3.2.3 Memory Information Press <Enter> to view the information of the memory.

  • Page 55: Advanced Screen

    BERGAMOD8-2L2T 3.3 Advanced Screen In this section, allows user to set the configurations for the following items: CPU Configu- ration, Chipset Configuration, Storage Configuration, NVMe Configuration, ACPI Con- figuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, PCI Subsystem Settings, AMD CBS, AMD PBS, PSP Firmware Versions, Network Stack Configuration, Driver Health, Tls Auth Configuration and Instant Flash.

  • Page 56: Cpu Configuration

    3.3.1 CPU Configuration SVM Mode Enable or disable CPU Virtualization.

  • Page 57: Chipset Configuration

    BERGAMOD8-2L2T 3.3.2 Chipset Configuration Onboard VGA Use this to enable or disable the Onboard VGA function. Onboard LAN (X710/I210-1/I210-2) Use this to enable or disable the Onboard LAN function. MCIO Mode Selection This item is for MCIO Mode Configuration. MCIO3 PCIE/SATA Mode Configure MCIO3 PCIE/SATA Mode.
  • Page 58 PCIE Link Speed This displays the PCIE Link Speed. PCIE1/PCIE2/PCIE3/PCIE4/PCIE5/PCIE6 Link Speed The default values for PCIE1/2/3/4/5/6 are [Auto]. MCIO2/MCIO1 Link Speed The default values for MCIO2 and MCIO1 are [Auto]. MCIO3 Link Speed The default value for MCIO3 is [Auto]. MCIO5/MCIO4 Link Speed The default values for MCIO5 and MCIO4 are [Auto].

  • Page 59: Storage Configuration

    BERGAMOD8-2L2T 3.3.3 Storage Configuration SATA Hot Plug Use this to enable or disable the SATA Hot Plug Function.

  • Page 60: Nvme Configuration

    3.3.4 NVMe Configuration The NVMe Configuration displays the NVMe controller and Drive information. Launch NVMe driver Select this item to enable or disable launch NVMe driver.

  • Page 61: Acpi Configuration

    BERGAMOD8-2L2T 3.3.5 ACPI Configuration PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. Ring-In Power On Allow the system to be waked up by onboard COM port modem Ring-In Singals.

  • Page 62: Usb Configuration

    3.3.6 USB Configuration This displays the USB Controllers and USB Devices information.

  • Page 63: Super Io Configuration

    BERGAMOD8-2L2T 3.3.7 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM1). Serial Port Use this item to enable or disable the serial port. Change Settings Use this item to select an optimal setting for Super IO device.

  • Page 64: Serial Port Console Redirection

    3.3.8 Serial Port Console Redirection COM1 / SOL Console Redirection Use this to enable or disable Console Redirection. If this item is set to Enabled allowing to select a COM Port to be used for Console Redirection. Console Redirection Settings Use this to configure Console Redirection Settings, and specify how the computer and the host computer to which are connected exchange information.

  • Page 65: Flow Control

    BERGAMOD8-2L2T Bits Per Second Use this to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200].
  • Page 66 Out-of-Band Mgmt Port Microsof t Windows Emergenc y Management Ser v ices (EMS) a l lows for remote management of a Windows Server OS through a serial port. Terminal Type EMS Use this to select the preferred terminal emulation type for out-of-band management. It is recommended to select [VT-UTF8].

  • Page 67: H/W Monitor

    BERGAMOD8-2L2T 3.3.9 H/W Monitor In this section, it allows user to monitor the status of the hardware on the system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 68: Pci Subsystem Settings

    3.3.10 PCI Subsystem Settings Re-Size BAR Support Enable or disable this item to Re-Size BAR supported upon the sysem has resizable BAR capable PCIe Devices. SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support.

  • Page 69: Amd Cbs

    BERGAMOD8-2L2T 3.3.11 AMD CBS CPU Common Options Use this item to configure CPU Common options. DF Common Options Use this item to configure DF Common options. UMC Common Options Use this item to configure UMC Common options. NBIO Common Options Use this item to configure NBIO Common options.

  • Page 70: Amd Pbs

    3.3.12 AMD PBS Use this item to configure AMD CPM RAS related settings. RAS Periodic SMI Control Use this to enable or disable Periodic SMI for polling [MCA Threshold] error. SMI Threshold This limits the number of [MCA Threshold and Deferred Error SMI source] per a unit time.
  • Page 71 BERGAMOD8-2L2T PCIe UnCorr GHES Notify Type This specifies the notification type for PCIe uncorrected errors. PCIe Root Port Corr Err Mask Reg Use this to initialize the PCIe AER corrected error mask register of root port. PCIe Root Port UnCorr Err Mask Reg Use this to initialize the PCIe AER uncorrected error mask register of root port.

  • Page 72: Psp Firmware Versions

    3.3.13 PSP Firmware Versions The PSP Firmware Verions displays the version information of ABL, PSP BootLoader, SMU FW, SEV FW, PHY FW, MPIO FW, TF MPDMA FW, PM MPDMA FW, GMI FW, RIB FW, SEC FW, PMU FW, EMCR FW and uCode B0.

  • Page 73: Network Stack Configuration

    BERGAMOD8-2L2T 3.3.14 Network Stack Configuration Network Stack Use this to enable or disable UEFI Network Stack. IPv4 PXE Support Use this to enable or disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available. IPv4 HTTP Support Use this to enable or disable IPv4 HTTP boot support.

  • Page 74: Media Detect Count

    Media detect count Number of times the presence of media will be checked. Use either +/- or numeric keys to set the value.

  • Page 75: Driver Health

    BERGAMOD8-2L2T 3.3.15 Driver Health Inter (R) 40GbE 4.5.05 Healthy Provides Health Status for the Drivers/Controllers.

  • Page 76: Tls Auth Configuration

    3.3.16 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert. Client Cert Configuration Press <Enter> to configure Client Cert.

  • Page 77: Instant Flash

    BERGAMOD8-2L2T 3.3.17 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI up- datetool allows user to update system UEFI without entering operating systems first like MSDOS or Windows®. Just save the new UEFI file to the USB flash drive, floppy disk or hard drive and launch this tool, then update the UEFI only in a few clicks without prepar- ing an additional floppy diskette or other complicated flash utility.

  • Page 78: Security

    3.4 Security This section allows user to set or change the supervisor/user password for the system. For the user password item is allowed user to clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.

  • Page 79: Key Management

    BERGAMOD8-2L2T 3.4.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode.
  • Page 80 Platform Key (PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed Key Exchange Keys (KEK) Enroll Factory Defaults or load certificates from a file: 1.
  • Page 81 BERGAMOD8-2L2T 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed Forbidden Signatures (dbx) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2.
  • Page 82 b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed...

  • Page 83: Server Mgmt

    BERGAMOD8-2L2T 3.5 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 255 seconds to initialize Host to BMC interfaces. FRB-2 Timer...
  • Page 84 OS Wtd Timer Policy Configure how the system should respond if the OS Boot Watchdog Timer expires. If the OS Boot Watchdog Timer is disabled, this item is not available. BMC Network Configuration Use this to configure BMC network parameters. DNS Configuration Select this item to configure DNS parameters.

  • Page 85: Bmc Network Configuration

    BERGAMOD8-2L2T 3.5.1 BMC Network Configuration Bonding Setting Select this item to enabled or disabled bonding. Please enable all lan channel first when want to enable bonding. Lan channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If using a static IP address, toggle to [Yes], and the changes take effect after the system reboots.

  • Page 86: Ipv6 Support

    The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/faq.asp VLAN Enable or disable Virtual Local Area Network.

  • Page 87: Dns Configuration

    BERGAMOD8-2L2T 3.5.2 DNS Configuration Manual DNS Configuration Select this item to manual configure DNS. If [YES] is selected, configure the items below. DNS Service Use this item to enable or disable DNS Service Configuration. Host Name Settings Use this item to automatic or manual Host Name Settings.
  • Page 88 Domain Name Server Setting This item supports Manual and Bond0 DNS Server Settings. IP Priority This item supports IPV4 and IPV6 IP Priority.

  • Page 89: System Event Log

    BERGAMOD8-2L2T 3.5.3 System Event Log SEL Components Change this to enable or disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL.

  • Page 90: Bmc Tools

    3.5.4 BMC Tools KCS Control Select this KCS interface state after POST end. If [Enabled] us selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS interface after POST stage Restore AC Power Loss This allows user to set the power state after an unexpected AC/power loss.

  • Page 91: Event Logs

    BERGAMOD8-2L2T 3.6 Event Logs Change Smbios Event Log Settings Use this item to configure the Smbios Event Log Settings. When entering the item, the screen displays following sub-items: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 92 Log EFI Status Code Enable or disable the logging of EFI Status Codes as OEM reserved type E0 (if not already converted to legacy). Convert EFI Status Codes to Standard Smbios Type Enable or disable the converting of EFI Status Codes to Standard Smbios Types (Not all may be translated).

  • Page 93: Boot Screen

    BERGAMOD8-2L2T 3.7 Boot Screen In this section, it will display the available devices on the system for user to configure the boot settings and the boot priority. Boot Option #1/#2/#3/#4/#5/#6 Use this to set the system boot order. UEFI Application Boot Priorities Specifies the Boot Device Priority sequence from available UEFI Application.

  • Page 94: Csm Parameters

    3.7.1 CSM Parameters CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable unless running a WHCK test. If using Windows 8 or later versions 64-bit UEFI and all of the devices sup- port UEFI, it may also disable CSM for faster boot speed. Launch PXE OpROM Policy Select UEFI only to run those that support UEFI option ROM only.

  • Page 95: Exit Screen

    BERGAMOD8-2L2T 3.8 Exit Screen Save Changes and Exit When selecting this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When selecting this option, the following message “Discard changes and exit setup?”...

  • Page 96: Chapter 4 Software Support

    Please download the operating system from the OS manufacturer. Please refer to the OS documentation for more instructions. * Please download the Intel® SATA Floppy Image driver from the ASRock Rack’s website (www.asrockrack.com) to the USB drive while installing OS in SATA RAID mode.

  • Page 97: Chapter 5 Troubleshooting

    BERGAMOD8-2L2T Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot the system. Always unplug the power cord before adding, removing or changing any hardware components. Failure to do so may cause physical injuries and damages to motherboard components.
  • Page 98 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether the power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to the related problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 99: Technical Support Procedures

    BERGAMOD8-2L2T 5.2 Technical Support Procedures If the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Contact information 2. Model name, BIOS version and problem type. 3. System configuration. 4. Problem description. Contact ASRock Rack’s technical support at: http://www.asrockrack.com/support/tsd.asp...
  • Page 100 Contact Information If it needs to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.asrockrack.com/tsd.asp...
